Swann 22x Zoom CCD Camera User manual

• Zoom in on a number plate 98 feet (30m) away

• High Resolution 420 line video display

• Powerful Sony Super HAD™ CCD color image sensor chip

• Strong metal body casing

• 22x zoom with adjustable and auto focusing

• Use with PTZ domes, panners & more

Mega Zoom

Security Camera

Ultimate magnification with 22x optical zoom lens

Coming Soon

High Resolution CCD Cameras

www.swannsecurity.com

Enquiries: [email protected]

Product Code:

Auto Focusing

Sony Super HAD™ Image Sensor

Technical Specifications

Image Sensor: ¼" Sony Super HAD™ CCD

System: PAL/NTSC

Sensor Size: 3.6mmx2.7mm

Resolution: PAL - 500x582

NTSC - 510x492

Frequencies: PAL - 153625KHz;50Hz

NTSC - 15.734KHz; 60Hz

TV Lines: 420

Lens: (3.9~85.8mm) F1.6

Electric Shutter: PAL - 1/50-1/100,000

NTSC - 1/60-1/100,000

Ratio: >48dB

Lux: F1.2 , 1.0Lux

Backlight: On/Off Manual

Auto Iris: EE/AI

Video Output: BNC 1.0Vp-p, 75Ohm

Mega Zoom Security Camera

Ultimate magnification with 22x optical zoom lens

www.swannsecurity.com

Please note that the information

contained within this document is

subject to change without notification.

All trademarks are

properties of their

respective owners.
