Swann SW-C-C510R User manual

• High Resolution Color CCD camera

• Plugs directly into TV, VCR, DVR, monitor or quad processor

• Ideal theft deterrent - research shows 70% reduction in crime

• Color pictures during the day, infrared night vision after dark

• Auto-Iris function (requires alternative lens)

www.swann.com.au

Enquiries: [email protected]

Product Code: SW-C-C510R

Professional CCTV Camera

C -510R

With Infra-Red

High Resolution CCD Cameras

Works with all

DVRs, VCRs,

TVs & Monitors

20m Range

1/4” Color Sharp CCD

Swann CCD Camera is the CCD all round solution

The Swann Professional CCD Camera provides you with crisp clear images when connected

to your TV, VCR, or Swann Security solution. With a C/CS inter-changeable lens system which

allows for the addition of optional lenses#, the Swann Professional CCD Camera is ideal for

Domestic to Commercial applications to suit your surveillance needs or location.

Professional CCTV Camera

C -510R

With Infra-Red

Technical Specifications

Sensor: 1/4" Sharp CCD

Pickup device: 1/4” Sharp CCD

image sensor

Number of pixels: PAL: 512(H) x 582 (V)

NTSC: 512 (H) x 492 (V)

System of signal: NTSC/PAL

Horizontal resolution: 400 TV lines

Lens Mount: C/CS

Backlight compensation: Auto

Electronic shutter: 1/50 (1/60)~1/100,000 sec

Iris control: Video/DC

White balance: Auto

S/N ratio: >48dB

Minimum Illumination: 0 Lux/F1.2

Gamma correction: >0.45

Operation temperature: 0C ~50C

32F - 122F

Sync. System: Internal

Video Output: <1.2Vp-p/75

Dimensions (mm): 119 (L) x 59 (W) x 52(H)

Weight: 236

Package Contents

Professional CCD Camera

Instruction Manual

Camera Stand

12V DC Power Adaptor

10m/33ft Cable

Fixed 4mm Lens

#Extra lenses sold separately

Please note that the information contained

within this document is subject to change

without notification.

Ideal for:

Retail Stores Offices HomeWarehouses
