Swann Professional CCTV Camera User manual

• Night vision up to 20m / 66ft

• High resolution CCD with 420TVL

• Easy to install & operate

• Robust metal weatherproof casing

• Simply connect to any TV / Monitor, VCR, DVR, or Quad Processor

www.swannsecurity.com

Enquiries: [email protected]

Product Code: SW-C-NWBW

Night Watch - Black & White

Professional CCTV Camera

With Night Vision

High Resolution CCD Cameras

Works with all

DVRs, VCRs,

TVs & Monitors

Night Watch - Black & White

Professional CCTV Camera

With Night Vision

Technical Specifications

Pickup Device: 1/3" Samsung CCD

Image Sensor

Number of Pixels: PAL: 512(H) x 582

NTSC: 512(H) x 492(V)

System of Signal: NTSC (USA) PAL (AU, UK, EU)

Horizontal Resolution: 420 TV Lines

Minimum Illumination: 0Lux/F1.2

Lens: 6mm (Included)

8mm/12mm (Available)

Backlight Compensation: Auto

Electronic Shutter: 1/50(1/60)~1/100,000sec

White Balance: Auto

S/N Ratio: >48dB

Gamma Correction: >0.45

Operation Temperature: 0°C~50°C

Sync. System Internal

Video Output: 1.0V p-p/75Ohm

Power Supply: DC12V

Dimensions(mm): 64(D)x104(L) excluding bracket

Weight(g): 330

IR View Distance: 20-25m (65-82ft)

Package Contents

NightWatch Cam with 10m/33ft fixed cable

Power adaptor

Manual

BNC Adapter

www.swannsecurity.com

Please note that the information

contained within this document is

subject to change without notification.

This manual suits for next models
