Swann HD-420 User manual

• High resolution 400 TV lines

• Latest enhanced video image sensor

• 60ft (18m) BNC cable

• Perfect for home, business, office, warehouse & more

• 3.5 to 8mm zoom lens, wide angle to long distance

Latest

Technology

PRO

High Resolution

Warranty

month

HD-420

Security Camera

High Powered, Discreet Surveillance

www.swannsecurity.com

Enquiries: [email protected]

Product Code: SW221-H42

Pro High Resolution Cameras

Also mounts

from ceilings

60ft (18m)

cable

BNC to RCA

Adapter

Plugs into any TV

or security monitor

www.swannsecurity.com

Please note that the information

contained within this document is

subject to change without notification.

Product Specifications

Camera Sensor: 1/3” / 8.5mm Color SSC Technology Sensor

TV System: PAL/CCIR (AU, UK, EU)

NTSC/EIA (USA)

Effective Element: PAL: 628 x 582

NTSC: 510 x 492

Definition: 400 TV lines

Scanning Frequency: PAL/CCIR: 50HZ

NTSC: 60HZ

Minimum Illumination: 0.8 Lux

Signal Noise Ratio: >+40dB

Electronic Shutter: 1/60 ~ 1/15000second

Power Supply: 12V DC

View Angle: 35° to 50° Variable

Construction: Aluminium

Operation Temperture: -4°F ~ 140°F (-20°C ~ 60°C)

Package Contents

- HD-420 Security Camera

- 60ft (18m) BNC to BNC & Power Cable

- BNC to RCA Adapter

- 3.5-8mm Manual Vari-Focal C/CS Lens

- 4 Bonus Security Stickers

- Power Adapter

- Instruction Manual

The Swann HD-420 Security Camera provides you with crisp clear video images

when connected to your DVR, Quad, TV, VCR, or Swann Security solution.

With a C/CS inter-changeable lens system, which allows for the addition of

optional lenses, the Swann HD-420 Security Camera is ideal for domestic

and commercial applications to suit a broad range of surveillance needs.

PRO

High Resolution

HD-420™

Security Camera

High Powered, Discreet Surveillance
