StarTech.com ICUSBAUDIO2D System manual

USB Stereo Audio Adapter External Sound Card with SPDIF Digital Audio

StarTech ID: ICUSBAUDIO2D

The ICUSBAUDIO2D External USB Sound Card lets you add an S/PDIF digital audio output and standard 3.5mm

analog audio/microphone connections to your system through USB - a convenient way to bypass or replace an

internal sound card without having to open the computer case.

For home-theater quality sound, the USB DAC (digital-to-analog converter) offers 96KHz / 24-bit sampling rates for

both playback and recording, and a 3.5mm S/PDIF port with support for Dolby® Digital 5.1 surround sound (AC3)

and DTS® pass-through (Note: 5.1 surround sound is supported in Windows® only).

This versatile USB audio adapter features an integrated 3.5mm 4-position TRRS connection for your headphones

or combination headset/microphone. Also a convenient external volume control for quick adjustments, a hardware

EQ switch for Bass or Treble boosting, and an LED status bar to display the current sampling rate.

Backed by a StarTech.com 2-year warranty and free lifetime technical support.

Applications

Connect your computer to a home theater audio receiver through S/PDIF, without opening the case

Add digital audio support to an Ultrabook™ or small form factor system with no internal expansion options

Replace or upgrade the integrated audio on a laptop or portable computer

Features

96KHz / 24-bit Hi-Fi USB Audio

S/PDIF digital output with AC3 (Dolby Digital) and DTS pass-through support

5.1 Surround Sound supported (Windows® only)

3.5mm headphone/microphone ports

4 position TRRS headset with Mic supported

Hardware volume knob and Bass/Treble boost EQ switch

LED sample rate indicators

16in attached USB cable

Technical Specifications

Warranty 2 Years

Bus Type USB 2.0

Chipset ID VIA - VT1630A

Connector Type(s) 1 - 3.5 mm Mini-Jack (3 Position) Female

Connector Type(s) 1 - 3.5 mm Mini-Jack (4 Position) Female

Connector Type(s) 1 - 3.5mm Mini-Toslink (SPDIF; Optical) Female

Connector Type(s) 1 - USB A (4 pin) Male

Audio Specifications 96 KHz / 24-bit Sample Rate

Approx 91dB SNR (A-weighting)

16-100ohm Headphone Drive Ability

OS Compatibility Windows® 8 (32/64bit), 7 (32/64), Vista(32/64), XP(32/64)

Windows® Server 2008 R2, 2003(32/64)

Mac OS 10.x (Tested up to 10.8)

Linux

Cable Length 16 in [406.5 mm]

Color Black

Enclosure Type Plastic

Product Height 0.6 in [16 mm]

Product Length 1.9 in [47 mm]

Product Weight 1.3 oz [36 g]

Product Width 1.8 in [46 mm]

LED Indicators 1 - Power

LED Indicators 3 - Playback / Recording sample rate

Power Adapter Included USB-Powered

Humidity 10~90% RH (Non-Condensing)

Operating Temperature 0°C to 60°C (32°F to 140°F)

Storage Temperature 0°C to 70°C (32°F to 158°F)

Note 5.1 surround sound output is supported in Windows only

System and Cable Requirements Available USB Port

Included in Package 1 - USB Stereo Audio Adapter

Included in Package 1 - Software CD

Included in Package 1 - Instruction Manual

Shipping (Package) Weight 3.7 oz [105 g]
