StarTech.com EC1PECPS System manual

1 Port ExpressCard Laptop Parallel Adapter Card - SPP/EPP/ECP

StarTech ID: EC1PECPS

The EC1PECPS 1 Port ExpressCard Laptop Parallel Adapter Card turns an ExpressCard slot into an IEEE 1284

Parallel port, allowing you to connect parallel devices to a laptop computer. The ExpressCard Parallel card is

PCI Express (x1) based, ensuring faster data transfer rates between host and peripheral as compared to a USB-

based ExpressCard; providing a cost-effective way to bridge the compatibility gap between your laptop and

legacy devices.

A convenient solution for adding a parallel printer or scanner, simply insert the adapter (EC1PECPS) into an

available 34mm or 54mm ExpressCard slot and connect your parallel device to the adapter’s SPP/EPP/ECP

parallel port. The adapter card is WHQL certified, so driver installation is automated for a simple plug-and-play

solution.

Backed by a StarTech.com 2-year warranty and free lifetime technical support.

Applications

Connects any parallel-based peripheral to your notebook, including printers, scanners, CD-R/RWs, Zip®

drives, and memory card readers

Features

Provides one IEEE 1284 SPP/EPP/ECP Parallel Port

Fits into 34mm or 54mm ExpressCard slots

32-byte FIFO data buffer

WHQL certified drivers

Compatible with PCI Express lane bus (x1/x2/x4/x8/x16)

intrl.startech.com

Technical Specifications

Warranty 2 Years

Ports 1

Bus Type ExpressCard

Card Type 34mm ExpressCard

Port Style Integrated on Card

Chipset ID PLX/Oxford - OXPCIe952

Connector Type(s) 1 - ExpressCard (34mm)

External Ports 1 - DB-25 (25 pin; D-Sub) Female

Maximum Data Transfer Rate 1.5Mbps

Supported Protocols ECP/EPP/SPP

OS Compatibility Windows® 8 (32/64bit), 7 (32/64), Vista(32/64), XP(32/64), 2000, ME, 98SE, 95

Windows® Server 2008 R2

Linux

Microsoft WHQL Certified Yes

Product Length 4.5 in [115 mm]

Product Width 1.7 in [44 mm]

Product Height 0.8 in [20 mm]

Product Weight 1.4 oz [40 g]

Shipping (Package) Weight 0.6 lb [0.3 kg]

Included in Package 1 - ExpressCard Parallel Adapter

Included in Package 1 - Adapter Cable

Included in Package 1 - Driver CD

Included in Package 1 - Instruction Manual

intrl.startech.com
