Star Micronics SP349 User manual

HOWTO ATTACHTHEWALL METAL FITTINGS OF SP349

1. Unpacking :Confirm that all accessories are

included.

2. Attaching procedure :

Note1)Unplug the power plug from the outlet.

Note2)Select a position on the wall which is not

subjected to mechanical shocks or water

drops. Also confirm that the wall is

sufficiently wide for attaching the bracket.

2-1 How to attach the bracket

1If attachment of the bracket on the wall is

not possible,first fix a wooden plate whose

size is more than 120mm×170mm×5mm.

2Apply the bracket and mark the positions

of the screw holes.

3Drill screw holes in the marked positions.

4Firmly tighten and fix the bracket to the

wall with screws.

Attach and fix the bracket with the four

φ4mm screws.

Please prepare screws of sufficient length

to sccure the bracket.

2-2 How to attach the holder plate

1Remove the rubber foot.

2Firmly tighten the two accessory screws

M3 in the direction shown in the figure to

attach the two holder plate onto the printer.

Tightening torque : 9kg fcm ±1kg fcm

2-3 Setting

Slide the printer main unit downward from

the top of the bracket so that the holder

plate guides it to a secure position.

Bracket(1)

Holder plates(2)

Not supplied

φ4mm screws(4)

Please prepare these

φ4mm screws by yourself.

M3 screws(4)

Bracket Wall material

Rubber foot

Holder plate

80822265
