Quick Start Guide

O2VLD6

1Warning and Caution

■ If the product does not work properly, please contact your

dealer or the nearest service center. Never attempt to disassemble

the camera yourself. Any unauthorized changes or modifications

could void the warranty.

■ Do not allow water or liquid intrusion into the camera.

■ All installation and operation here should conform to local

electrical safety codes. Make sure the device is firmly installed

on the wall or ceiling.

■ Do not use camera beyond specified voltage range.

■ Do not drop the camera or subject it to physical shock.

■ Avoid touching the camera lens.

■ If cleaning is necessary, please use cleaning cloth to wipe it

gently.

■ Do not aim the camera at the sun or extremely bright light

sources.

■ Do not place the camera in extremely hot or cold environments

and dusty and damp locations. Do not expose it to highly

electromagnetic radiation.

■ Do not block any ventilations.

Package

2

Overview

3 Overview

3

Adapter Plate

Camera Quick start guide

CD Water-proof cap Plastic plug ×4

Drill template

Sponge Screwdriver

4 tapping screws PA 4×25

3

4

1

2

Network Cable

Mounting Base MIC IN Cable

Power Cable

1

2

3

4

* 1 It is recommended to install the water-proof cap for outdoor installations.

* 2 DC 12V power supply is not required if a PoE switch or injector is used to power

the camera.

► Connecting Network Cable

2

13

① Loosen the nut from the main element.

② Run the network cable (without RJ 45 connector) through both

elements. Then crimp the cable with RJ 45 connector.

③ Connect the cable to the hermetic connector. Then tighten the nut

and the main cover.

Network Cable

DC12V

Installation

4

* Before you start, please make sure that the wall or ceiling is strong enough

to withstand three times the weight of the camera.

① Install junction box onto the wall by using the screws provided.

② Install the adapter plate onto the junction box as shown below.

Sponge

Junction Box

Water-proof Ring

Adapter Plate

③ Loosen the screws to open the lower dome and then loosen the

lock screw to remove the mounting base.

④ Mount the mounting base to the adapter plate.

⑤ Connect the cables and fix the dome to the mounting base with the

lock screw.

Lock Screw

Lower Dome

Sponge

Mounting Base

Mounting Base

⑧ Install the lower dome back to the camera and fix it with the screws.

Web Operation

5

● Operation

IP Scanner can search for the device on the local network.

① Make sure that the camera and the PC are connected to the same

local network. The camera is set to DHCP by default.

② Install IP Scanner from the CD and run it after installation.

Focus

Zoom

Rotation 0°~360°

Pan 0°~360°

Tilt 0°~77°

⑥Three-axis Adjustment-Before adjustment, preview the image of the

camera on a monitor and then adjust the camera according to the figure

below to get an optimum angle.

⑦ Adjust the Focus and Zoom screw to get a clear image.

③ In the device list, you can view the IP address, model number, and

MAC address of each device. Select the applicable device and double

click to open up the web viewer. You can also manually enter the IP

address in the address bar of the web browser.

The login interface is shown above. Default user name is admin and

password is 1234. After logging in, follow directions to install

applicable plugins.

450043000616 A0
