Speco CVC637EX User manual

SEE"A"

FRONT VIEW SIDE VIEW

DC 12V INPUT:RED

VIDEO OUTPUT:YELLOW

SEE"A"

REAR VIEW

NTSC=1/60 - 1/120,000 Sec

RH95% MAX(-4 deg F to 140 deg F)

RH95% MAX(14 deg F to 122 deg F)

1.0 Vp-p 75 ohm COMPOSITE

.LOW ILLUMINATION

WEIGHT

DIMENSIONS

IMAGE SENSOR

MINIMUM ILLUMINATION

GAMMA CHARACTERISTIC

ELECTRONIC SHUTTER

VIDEO OUTPUT

POWER CONSUMPTION

LENS

SCANNING SYSTEM

TV SYSTEM

SYNC SYSTEM

S/N RATIO

RESOLUTION

3.6mm

0.45

NTSC

MORE THAN 50dB

INTERNAL SYNC

2:1 INTERLACED

.COMPACT AND LIGHTWEIGHT

.TURBO AGC

.EXTREMELY LOW POWER CONSUMPTION

.BUILT IN BACK LIGHT COMPENSATION

.PRE-SET AUTO EXPOSURE SETTINGS

.LOW SMEAR LEVEL

.BUILT IN ELECTRONIC AUTO IRIS

.HIGH RESOLUTION

WITH BUILT-IN 3.6MM LENS

EXTREME LOW LIGHT SENSITIVITY

2.7”(L) x 1”(W) x 1”(H)

APPX.3.8oz

12VDC 150mA

MINIATURE COLOR BULLET CAMERA

MODEL:CVC637EX/CVC637EXW

CVC637EX/CVC637EXW

.1/3" SONY SUPER HAD CCD

1/3" SONY SUPER HAD CCD

0.1 LUX

540TV LINES

SPECIFICATIONS

GENERAL FEATURES

MODEL NO

NTSC=768(H) * 494(V)

NO.OF PIXELS

STORAGE TEMPERATURE

OPERATIONAL TEMPERATURE

200 New Highway, Amityville, NY 11701

800-645-5516 / www.specotech.com

1”(W) 2.7”(L)

1”(H)

This manual suits for next models
