Sony STR-DH820 User manual

STR-DH820

Sony

7.1 Channel 3D AV Receiver

Key Features

7.1 Channel A/V Receiver (110W x7 @ 8 ohms 1kHz 1% THD)

iPod

iPhone

video and music playback with included

dock

7 HD Inputs (4 HDMI™

3 Component)

3D pass

through

Upconvert/Upscale from analog to 1080p via HDMI™

(

Faroudja DCDi Edge )

HD Digital Cinema Sound™(HD DCS)

Advanced On

screen graphical user interface

Digital Legato linear advanced sound processing

Sound Optimizer for clarity at all volume levels

Dolby

TrueHD, Pro logic IIz and dts

HD Enhanced Audio

Codecs

Key Technologies

iPod

iPhone

Music and Video playback with included dock Listen to music and watch video stored on your iPod® or

iPhone® while charging your device with the included dock.

7 HD Inputs Get versatile HD connection options with seven HD inputs. Four HDMI™inputs (up to 1080/24p capable) let you connect

a Sony® PlayStation®

3 entertainment system, Blu

-ray Disc™player, any 2 other HDMI-capable devices, for high definition video and

audio. Three component inputs (1080/60i capable) provide added HD-capable connectivity and versatility.

3D Pass

through Compatible with Blu-ray 3D™movies, video games and other 3D content

Upconvert/Upscales Video signal to near HD via HDMI™ Improve image quality of analog connected devices to near HD.

Analog connected device signals are converted to digital and output via HDMI™, making one cable connection from the receiver to

the HDMI

-enabled TV possible.

HD Digital Cinema Sound Optimize your receiver to mimic the sound characteristics of Sony Pictures.

screen graphical user interface

Set

-up and control the A/V receiver with intuitive on-

screen graphical user interface.

Digital Legato Linear Improve audio performance when listening to internet radio stations and portable audio devices, adding

warmth and clarity.

Sound Optimizer Keep dynamic movie scenes in check, optimizing sound to the desired volume level.

Advanced Blu

ray Disc™Audio Decoding Experience sound closer to the way it was captured with LPCM, Dolby®

trueHD,

ProLogic IIz and dts®-HD master audio codecs.

BRAVIA Widget Control

Connect to select Sony 2011 Televisions and experience an integrated user interface on

screen. Enabling

on-

screen feedback and control function.

2nd Zone audio/Video Equipped with 2nd Zone pre-

outs.

Dual Subwoofer Preouts Add additional bass increasing the dynamic effects of movies and music.

Digital Cinema Auto Calibration

Quick Speaker Set Up

Ensure you get the best sound experience from your A/V receiver and

speakers with Digital Cinema Auto Calibration. Simply place the included microphone where you will be seated and settings are

automatically optimized based on the distance, delays and placement of your speakers.

Audio Return Channel Eliminate the need for extra cables connected to your TV. This feature allows audio to be sent from your

compatible TV to your receiver through the same HDMI™cable already being used to send audio and video to your TV.

Standby pass

through of Audio & Video Conveniently access all your HDMI™connected devices without having to power on

the receiver.

Assignable digital audio and video inputs Get the most out of each audio and video input with the ability to reassign inputs to

support connected devices.

BRAVIA

Sync Capable Conveniently operate and control select Sony® BRAVIA® Sync devices with one remote including: Sony

Blu-ray Disc™Players, BRAVIA® HDTVs, Sony home theater products.

Sony Electronics Inc.

•

16530 Via Esprillo

•

San Diego, CA 92127

•

1.800.222.7669

•

www.sony.com

Last Updated: 02/23/2011

STR-DH820

Sony

7.1 Channel 3D AV Receiver

Please visit the Dealer Source for current

information at www.sony.com/dealersource

UPC Code:

027242809321

1.3Dviewingrequires3Dcontent,3DHDTV,ahighspeedHDMI

™

cable

(supportingatleast10.2Gbps)connection,andother3Daccessories

(including 3D glasses).

2.Dolby®

True

HD and dts

HDMasterAudiodecodingrequireHDMI

™

cable and capable source device (both sold separately).

3.RequiresconnectionviaHDMI

™

cable(soldseparately)toequivalent

HDTV.Upscaled/upconverted image and sound quality will vary

depending on source.

4.Works with other BRAVIA® Sync orTheatreSync™

labeledhome

audio/videoproducts when connected via HDMI

™

interface.

5. iPod

supportis limited to the following players: iPod touch

iPod

classic

iPod nano

1st,2nd& 3rd generation, iPod

®4th&5th

generation & iPod mini and iPhone 3G, 3Gs and 4G models.

6.HDMI™

cable required, sold separately.

7.RequiressourcesconnectedwithHDMI

™

cables(sold separately).

Sound Quality will vary depending on source.

8.Canbeusedonlywhen receiver is connected to a Sony XBR

EX620,

EX630,EX720, EX820,EX830,NX830, HX820,HX830,or HX930series

BRAVIAHDTV via HDMI™

cable (sold separately).

inpart withoutwrittenpermission isprohibited.Sony, BRAVIA,Theatre

Sync,24p True Cinema, Cyber

shot,Handycam and DigitalCinema

Soundare trademarksofSony. PlayStation isa trademark ofSony

ComputerEntertainment. Blu

rayDiscandBlu

ray3Daretrademarks.

Dolbyis a registeredtrademark of DolbyLaboratories. dts isatrademark

ofdtsInc.HDMIisatrademarkofHDMILicensingLLC.iPod,iPhone, iPod

touch,iPodclassic,andiPodnanoaretrademarkofApple,Inc.Allother

trademarksare trademarksof their respectiveowners. Features and

specifications are subject to change without notice. Non

metricweights

andmeasures are approximate and may vary.
