Sony UPA-PC700 User manual

4-121-059-11 (1)

DPF SYSTEM

CONTROLLER

UPA-PC700

Installation Guide GB

Read this guide before any other documentation.

WARNING

This manual is intended for qualified service personnel only. To reduce the risk of electric shock, fire or injury,

do not perform any servicing other than that contained in the operating instructions unless you are qualified

to do so. Refer all servicing to qualified service personnel.

Guide d’installation FR

Prière de lire ce guide avant tout autre documentation.

AVERTISSEMENT

Ce manual est destinè uniquement aux personnes compétentes en charge de l`entretien. Afin de réduire les risques de

décharge électrique, d`incendie ou de blessure n`effectuer que les réparations indiquées dqns lemode d`emploi à moins d`être

quqlifié pour en effectuer d`autres. Pour toute réparation faire appel à une personne compétente uniquement.

Installationsanleitung DE

Lesen Sie zuerst diese Anleitung, bevor Sie andere Dokumente lesen.

WARNUNG

Die Anleitung ist nur für qualifiziertes Fachper sonal bestimmt. Alle Wartungsarbeiten dürfen nur von qualifiziertem

Fachpersonal ausgeführt werden. Um die Gefahr eines elektrischen Schlages, Feuergefahr und Verletzungen zu

vermeiden, sind bei Wartungsarbeiten strikt die Angaben in der Anleitung zu befolgen. Andere als die angegeben

Wartungsarbeiten dürfen nur von Personen ausgeführt werden, die eine spezielle Befähigung dazu besitzen.

Guía de instalación ES

Comience a leer esta guía antes que cualquier otro documento.

ADVERTENCIA

Este manual está destinado únicamente a personal cualificado de servicio técnico. Para reducir el riesgo de

descargas eléctricas, incendios o lesiones, no realice ninguna reparación distinta de las que figuran en

manual de instrucciones excepto en caso de que esté cualificado para efectuarlas. Ponga cualquier tipo de

reparación en manos de personal de asistencia técnica cualificado.

Guida all’installazione IT

Leggere la presente guida prima di qualsiasi altra documentazione.

ATTENZIONE

Il presente manuale è destinato a personale di assistenza qualificato. Per ridurre il rischio di scosse elettriche,

incendio o lesioni, non eseguire attività di riparazione diverse da quelle descritte nelle Istruzioni per l’uso, a

meno che non si disponga delle qualifiche necessarie. Per tutte le attività di riparazione richiedere l’intervento

di personale qualificato.

To reduce the risk of fire or electric shock, do not

expose this apparatus to rain or moisture.

To avoid electrical shock, do not open the

cabinet. Refer servicing to qualified personnel

only.

THIS APPARATUS MUST BE EARTHED.

This unit has no power switch.

When installing the unit, incorporate a readily accessible

disconnect device in the fixed wiring, or connect the power

cord to a socket-outlet which must be provided near the

unit and easily accessible.

If a fault should occur during operation of the unit, operate

the disconnect device to turn off the power supply, or

disconnect the power cord.

CAUTION

Use of controls or adjustments or performance of

procedures other than those specified herein may result in

hazardous radiation exposure.

CAUTION

The use of optical instruments with this product will

increase eye hazard.

This DPF SYSTEM CONTROLLER is classified as a

CLASS 1 LASER PRODUCT.

Warning on power connection

Use a proper power cord for your local power supply.

1. Use the approved Power Cord (3-core mains lead)/

Appliance Connector/Plug with earthing-contacts that

conforms to the safety regulations of each country if

applicable.

2. Use the Power Cord (3-core mains lead)/Appliance

Connector/Plug conforming to the proper ratings

(Voltage, Ampere).

If you have questions on the use of the above Power Cord/

Appliance Connector/Plug, please consult a qualified

service personnel.

CAUTION

Danger of explosion if battery is incorrectly replaced.

Replace only with the same or equivalent type

recommended by the manufacturer.

Dispose of used batteries according to the manufacturer's

instructions.

For the customers in Europe

The manufacturer of this product is Sony Corporation,

1-7-1 Konan, Minato-ku, Tokyo, Japan.

The Authorized Representative for EMC and product

safety is Sony Deutschland GmbH, Hedelfinger Strasse 61,

70327 Stuttgart, Germany.

For any service or guarantee matters, please refer to the

addresses given in separate service or guarantee

documents.

For kundene i Norge

Dette utstyret kan kobles til et IT-strømfordelingssystem.

For the customers in Taiwan only

WARNING

English

Table of Contents

Introduction ...................................... 4

Guides for This Unit .............................................. 4

Accessory Checklist ........................ 4

Location and Function of Parts ...... 5

Front (Closed) ............................................................ 5

Front (Open) .............................................................. 5

Rear (Closed) ............................................................. 6

Rear (Open) ............................................................... 6

Connections ..................................... 7

Before Connecting ..................................................... 7

Opening and Closing the Rear Cover .................... 7

Opening and Closing the Cabinet .......................... 7

Internal Connectors ................................................ 8

Connecting the Power Cord ..................................... 8

Connecting a Peripheral USB Device ...................... 9

Replacing Components ................. 10

Replacing Media Drives ......................................... 10

Removing a Media Drive ..................................... 10

Inserting a Media Drive ....................................... 10

Replacing the Receipt Printer ................................ 11

Removing the Receipt Printer .............................. 11

Inserting the Receipt Printer ................................ 11

Appendix......................................... 12

Safety Precautions ................................................... 12

Notes on Installation ............................................ 12

Specifications ........................................................... 12

The following media names are trademarks of their

respective owners:

• “Memory Stick,” “Memory Stick Duo,” “Memory Stick

PRO,” and “Memory Stick PRO Duo” are trademarks of

Sony Corporation.

• CompactFlash is a trademark of SanDisk Corporation.

• miniSD is a trademark of SD Card Association.

• xD-Picture Card is a trademark of Fuji Photo Film Co.,

Ltd., Olympus Imaging Corp., and Toshiba Corporation.

• MultiMediaCard is a trademark of Infineon

Technologies AG.

4Introduction / Accessory Checklist

Introduction

Thank you for purchasing the UPA-PC700 Sony DPF

SYSTEM CONTROLLER.

This Installation Guide is for use by qualified service

personnel when setting up the system hardware.

Guides for This Unit

The following guides are supplied with this unit:

Installation Guide (this manual)

The Installation Guide describes the following:

• Part names and their functions

• Connections

• Replacement of components

Operating Instructions

The Operating Instructions describe the following:

• Using the receipt printer

• Setting media in the media drives

• Troubleshooting

User’s Guide

The User’s Guide describes the following:

• Printing pictures

• Editing pictures

• Using the various output services

• Modifying the settings of the unit

Accessory Checklist

Make sure the box includes all of the following items:

• Power cord (1)

• Cabinet keys (2)

• Eject pin (1)

• Installation Guide (this manual) (1)

• Operating Instructions (1)

• CD-ROM (User’s Guide) (1)

• Warranty booklet (1)

• End User License Agreement (1)

Notes

• If any of the above items is missing, contact your dealer

immediately.

• If you need to purchase an additional cable to connect

another device, refer to the manual that came with the

device to confirm the appropriate cable.

• Save the box and packing material. You may need them

later to pack the unit for shipping to another location.

Location and Function of Parts

Front (Closed)

ATouchscreen display

Displays information, selections, and commands.

Users can touch the screen directly to perform

selections.

BMedia reader

Holds various media for reading image data,

including “Memory Stick,” CompactFlash cards, xD-

Picture cards, SD Memory Cards, MultiMediaCards,

and USB memory devices.

Note

To avoid losing image data or damaging the unit,

never attempt to insert any media into a

CompactFlash adapter set in the CompactFlash slot.

CReceipt printer

Holds a roll of 2-inch receipt paper for printing

transaction information.

DDVD drive

Performs read and write operations on a disc.

Front (Open)

ASpeakers

Emit audio sounds at each touch of the display.

BDrawer

Houses the receipt printer and media drives.

CCabinet lock

Secures access to the inside of the unit.

DCabinet

Houses the components of the unit.

EVentilation holes

Allow air to pass through the unit to keep it cool

during operation.

3 245

6Location and Function of Parts

Rear (Closed)

ARear cover lock

Secures access to inside the unit.

BRear cover

Remove this to connect the power cord and other

cables to the internal connectors on the unit.

C1(On/Standby) button

Press this button to start the unit.

For details about operations, refer to the User’s Guide.

Note

For an emergency shutdown, press and hold this

button for at least four seconds. The unit will be

forcibly shut down.

Rear (Open)

ACooling fans

Force air to pass through the unit to keep it cool during

operation.

BInternal connectors

Connect to the various components of system and the

peripheral devices. For details, see “Internal

Connectors” on page 8.

Connections

Before Connecting

All the connectors for the unit are located behind the rear

cover. This section describes how to access and operate the

rear cover safely and illustrates the layout of the internal

connectors.

Note

Remove the internal packing material the first time you

open the unit, and save it in case you need to transport the

unit later.

Opening and Closing the Rear Cover

To open the rear cover

Unlock the rear cover lock using the supplied cabinet

key.

Remove the rear cover while holding it on both sides.

To close the rear cover

Attach the rear cover while holding it on both sides.

Lock the cover using the cabinet key.

Opening and Closing the Cabinet

To open the cabinet

Unlock the cabinet lock on the left side of the unit

using the supplied cabinet key.

8Connections

Pull out the drawer using the handholds on both sides.

Note

Do not remove the cabinet key when the drawer is

open.

Shutting the drawer while the key is removed may

damage the lock and prevent the key from being

inserted.

To close the cabinet

Note

Use both hands to lower the front panel. The front panel is

heavy and could cause serious injury if it fell unexpectedly.

Slide the drawer shut, and lock the cabinet lock.

Internal Connectors

AAC power connector

Connects to the specified AC power cord. For details,

see “Connecting the Power Cord”.

B(Printer) port

Not currently used.

CUSB ports (6)

Connect to peripheral USB devices. For details, see

“Connecting a Peripheral USB Device” on page 9.

D(LAN) connector (RJ-45 type)

Not currently used.

Caution

For safety, do not connect the connector for peripheral

device wiring that might have excessive voltage to this

port.

Follow the instructions for this port.

E(LINE IN) jack

Not currently used.

F(LINE OUT) jack

Not currently used.

G(MIC IN) jack

Not currently used.

HCash drawer port

Not currently used. Not for telecommunication

(telephone) network.

I1 (COM 1) port

Not currently used.

J(Monitor) port

Not currently used.

Notes

• Make sure any device cables with retaining screws are

properly fastened to the securing bolts on the sides of

each port.

• We recommend that you wire all device cables through

the holes at the rear of the unit and bundle them properly

with cable ties.

Connecting the Power

Cord

Follow the procedure below to connect the specified AC

power cord to the unit. For details on the locations of

internal connectors, see “Internal Connectors”.

Open the rear cover.

For details, see “To open the rear cover” on page 7.

Connect the specified power cord to the AC power

connector inside the unit.

Note

When wiring and bundling cables, leave some slack

inside the cabinet to prevent a sudden pull on the cable

from disconnecting the cable or damaging the

connector.

After all other connections are complete, connect the

power cord to an AC power outlet.

124 533

890

Connections

Close the rear cover.

For details, see “To close the rear cover” on page 7.

Connecting a Peripheral

USB Device

Follow the procedure below to connect a peripheral USB

device to one of the designated USB ports inside the unit.

For details on connecting a specific device, refer to the

manual that came with the device.

Supported USB devices

The following peripheral USB devices can be connected to

the internal USB ports on the UPA-PC700:

• UP-D75 (Sony Digital Photo Printer)

• UP-DR200 (Sony Digital Photo Printer)

• UP-GR700 (Sony Digital Photo Printer)

Notes

• To avoid causing a fire or damaging the unit, never

attempt to connect an unsupported device. For more

details about the types of devices supported by the unit,

consult your dealer.

• Up to three UP-DR200 printers can be connected to the

UPA-PC700.

• Up to one UP-D75 or UP-GR700 printer can be

connected to the UPA-PC700.

To connect a USB device

Open the rear cover.

For details, see “To open the rear cover” on page 7.

Connect one end of the USB cable to one of the four

designated USB ports inside the unit.

Notes

• The six designated USB ports for connecting

peripheral USB devices are shown by 3under

“Internal Connectors” on page 8.

• When wiring and bundling cables, leave some slack

inside the cabinet to prevent a sudden pull on the

cable from disconnecting the cable or damaging the

connector.

Connect the other end of the USB cable to a USB port

on the device.

Close the rear cover.

For details, see “To close the rear cover” on page 7.

Turn on the peripheral USB device.

Notes

• Connect peripheral USB devices directly to the USB

ports on the unit. Operation through a USB hub is not

guaranteed.

• If a message prompting you to install drivers appears

when you connect supported peripheral devices to the

unit, contact your dealer.

• When the UP-DR200/UP-D75/UP-GR700 is connected

to the UPA-PC700 and powered on, the following dialog

appears:

“A change of device connection has been recognized.

Please wait for a while.”, and “The connection has been

made in the system.”

Do not operate the system while the dialog is displayed.

10 Replacing Components

Replacing Components

Replacing Media Drives

It may become necessary to replace the media reader or the

DVD drive. Follow the procedures below to remove or

insert one of the media drives.

Note

Before removing or inserting a media drive, make sure the

unit and the peripheral devices are turned off.

Removing a Media Drive

Open the cabinet.

For details, see “To open the cabinet” on page 7.

Disconnect the power cord.

Remove the drive cover.

When removing the media reader, disconnect it from

the USB ports on the unit.

When removing theDVD drive, disconnect it from the

IDE port on the unit.

Pull the quick-lock pins on both sides of the media

drive directly outward 1, and then turn them 90

degrees 2to lock them in the open position.

Remove the media drive from the bay.

The old media drive is now removed. To finish the

replacement, you need to insert a new media drive.

Inserting a Media Drive

Insert the new media drive into the appropriate bay,

aligning the holes in the sides of the drive with the

quick-lock pins.

Turn the quick-lock pins 90 degrees to lock them in

the closed position.

When inserting a media reader, connect it to the USB

ports on the unit.

When inserting a DVD drive, connect it to the IDE

port on the unit.

Attach the drive cover.

Connect the power cord.

Close the cabinet.

For details, see “To close the cabinet” on page 8.

Opening the quick-lock pins

Media reader pins

(On both sides)

DVD drive pins

(On both sides)

Table of contents

Languages:

Other Sony Controllers manuals

Sony

Sony HKDV-900 User manual

Sony

Sony ZRD-C12A User manual

Sony

Sony HKSP-300 User manual

Sony

Sony BVE-600 User manual

Sony

Sony PlayStation DualSense CFI-ZCT1G User manual

Sony

Sony RM-E300 User manual

Sony

Sony MJ100 User manual

Sony

Sony RM-AV2100B Operating Instructions (primary... User manual

Sony

Sony JumboTron JTC-C200 User manual

Sony

Sony RM-TP1 Operating Instructions / Mode... User manual

Sony

Sony PlayStation DualSense Edge CFI-ZCP1 User manual

Sony

Sony RM-VZ220 User manual

Sony

Sony Jumbotron JME-UA200 User manual

Sony

Sony JumboTron User manual

Sony

Sony JunboTron JME-SA200 User manual

Sony

Sony UPA-PC500 User manual

Sony

Sony HKSP-R80 User manual

Sony

Sony MB-8N User manual

Sony

Sony RM-280 User manual

Sony

Sony DSBK-2020 User manual

Sony

Sony RM-V210 - Universal Remote User manual

Sony

Sony UPA-PC500 User manual

Sony

Sony HKSP-R80 User manual

Sony

Sony HKDV-900 User manual

Popular Controllers manuals by other brands

Digiplex

Digiplex DGP-848 Programming guide

YASKAWA

YASKAWA SGM series user manual

Sinope

Sinope Calypso RM3500ZB installation guide

Isimet

Isimet DLA Series Style 2 Installation, Operations, Start-up and Maintenance Instructions

LSIS

LSIS sv-ip5a user manual

Rockwell Automation

Rockwell Automation 1769-L31 installation instructions

Airflow

Airflow Uno hab Installation and operating instructions

ABB

ABB ACS580-01 drives Hardware manual

Panasonic

Panasonic GM1 Series Reference manual

Emerson

Emerson SW93 owner's manual

AutoAqua

AutoAqua Smart ATO micro SATO-120P manual

Panasonic

Panasonic FP? Positioning Unit RTEX Technical manual

Samson

Samson Type 5824 Mounting and operating instructions

Alpha IP

Alpha IP MIOB 21001 manual

Siemens

Siemens OpenAir GMA 1 Series Mounting instructions

Surecom

Surecom SR-629 user manual

Fishman

Fishman TriplePlay installation guide

Regulus

Regulus SRS1 T Installation and operation manual
