SIIG CE-HM0021-S1 User manual
1
HDMI to DVI + Audio
QuickInstallationGuide
Introducing the HDMI to DVI + Audio
The HDMI to DVI + Audio provides an easy solution for
converting digital HDMI to digital video (DVI-D) and
both digital audio (S/PDIF) and analog stereo audio.
This device enables you to connect full digital video and
audio to DVI enabled monitors and coaxial S/PDIF
equipped audio receivers and amplifiers for highest
compatibility to your home theater system.
FeaturesandBenefits
• HDMI 1.2a compliant
• Fully HDCP compliant
• Supports DVI video up to 165 MHz
• Coaxial S/PDIF and stereo analog audio outputs
• Front panel LED indicators
• Works with various types of HDMI based audio/
video devices including DVD players, game
consoles, camcorders, set-top boxes
PackageContents
• HDMI to DVI + Audio converter
• Power Adapter (5V, 2A)
• Quick Installation Guide
04-0495A
2
TechnicalSpecifications
• Video Amplifier Bandwidth: 1.65 Gbps
• Input Video Signal: 1.2 Volts p-p
• Input DDC Signal: 5 Volts p-p (TTL)
• Single Link Range: 1080p/1920 x 1200
• HDMI connector: 19 pin type female connector
• DVI connector: DVI-I 29 pin female (digital only)
• RCA connector: Coaxial S/PDIF
• Audio out: Analog stereo jack
• Power supply: Output - 5VDC, 2A
• Power consumption: 10 watts (max)
FrontPanel
HDMI Status Rotary Power +5VDC
RearPanel
S/PDIF Audio Out DVI
3
RotarySwitch
The function of the rotary switch is reserved, please keep
the rotary switch at 0.
• Position 0: Analog audio output
• Position 1: Analog audio output
• Position 2: Analog audio output
• Position 3: Analog audio output
• Position 4 & 5 : Reserved
• Position 6: Restore default EDID
• Position 7: Learn EDID of HDMI equipped device
Hardware Installation
General instructions for connecting devices are provided
below. Please consult your device’s users manual for
more information, if needed.
1. Connect your HDMI source to the HDMI input
connector.
2. Connect your DVI enabled monitor to the DVI out
port.
3. Connect your S/PDIF AV receiver into the S/PDIF
Out.
4. Connect your PC speaker into the Audio Out jack.
5. Plug the power adapter into the +5VDC jack then
plug the power adapter into a reliable power outlet.
Note: S/PDIF format is dependent upon the
embedded digital audio in the HDMI stream. The
S/PDIF receiver must be able to recognize the input
S/PDIF format. This converter only separates the
digital audio in the HDMI stream, and passes the
audio to the output.
4
Figure 1: Connecting Devices
Safety Precautions
Like all electronic equipment the HDMI to DVI + Audio
should be used with care. Please read and follow the
safety precautions to protect yourself from possible
injury and minimize the risk of damage to the unit.
• Follow all instructons and warnings marked on the
unit
• Provide proper ventilation and air circulation, do
not use near water
• Do not service the unit yourself, except where
explained in the manual
• Use only the power adapter and accessories that
came with the unit
HDMI to DVI+Audio
Connecting Devices
HDMI Source
DVI LCD monitor
Analog Speakers
S/PDIF AV Amplifier
5
Notes
• Audio Out jack supports 2-channel stereo audio
only
• S/PDIF Out supports up to 8-channel audio output
(depending on the audio source)
6
Blank Page
7
Technical Support and Warranty
QUESTIONS? SIIG’sOnline Support hasanswers! Simply visitour
web site at www.siig.com and click Support. Our online support
database is updated daily with new drivers and solutions. Answers
toyour questionscould bejust a few clicks away. You can also submit
questions online and a technical support analysts will promptly
respond.
SIIGoffers a 2-yearmanufacturer warranty with this product. Please
see our web site for more warranty details. If you encounter any
problems with this product, please follow the procedures below.
A) If it is within the store's return policy period, please return the
product to the store where you purchased from.
B) Ifyour purchase has passed the store's returnpolicy period,please
follow these steps to have the product repaired or replaced.
Step 1: Submit your RMA request.
Go to www.siig.com, click Support, then RMA to submit a
request to SIIG RMA. If the product is determined to be
defective, an RMA number will be issued.
Step 2: After obtaining an RMA number, ship the product.
•Properly pack the product for shipping. All software, cable(s)
and any other accessories that came with the original package
must be included.
•Clearly write your RMA number on the top of the returned
package. SIIG will refuse to accept any shipping package, and
will not be responsible for a product returned without an
RMA number posted on the outside of the shipping carton.
•You are responsible for the cost of shipping. Ship the product
to the following address:
SIIG, Inc.
6078 Stewart Avenue
Fremont, CA 94538-3152, USA
RMA #:
•SIIG will ship the repaired or replaced product via Ground
in the U.S. and International Economy outside of the U.S. at
no cost to the customer.
HDMItoDVI+AudioisatrademarkofSIIG,Inc. SIIGandtheSIIGlogoareregisteredtrademarksof
SIIG, Inc. Other names used in this publication are for identification only and may be trademarks of
theirrespectivecompanies.
September, 2008 Copyright © 2008 by SIIG, Inc. All rights reserved.
About SIIG, Inc.
Foundedin1985,SIIG,Inc.isaleadingcomputerupgrademanufacturer
of I/O connectivity products, including PCIe, PCI & ISA serial and
parallel ports, USB, Serial ATA & UltraATA controllers, FireWire
(1394a/b),networking,sound cards,andother accessories. SIIGisthe
premier one-stop source of upgrades.
SIIGproductsoffer comprehensive usermanuals,many user-friendly
features, and are backed by an extensive manufacturer warranty.
High-quality control standards are evident by the overall ease of
installation and compatibility of our products, as well as one of the
lowest defective return rates in the industry. SIIG products can be
found in computer retail stores, mail order catalogs, through major
distributors, system integrators, and VARs in the Americas and the
UK, and through e-commerce sites.
PRODUCT NAME
HDMIto DVI+Audio
FCC RULES: TESTED TO COMPLY WITH FCC PART 15, CLASS
B OPERATING ENVIRONMENT: FOR HOME OR OFFICE USE
FCCCOMPLIANCESTATEMENT:
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
THE PARTY RESPONSIBLE FOR PRODUCT COMPLIANCE
SIIG, Inc.
6078 Stewart Avenue
Fremont, CA 94538-3152, USA
Ph: 510-657-8688
