Siemens WT47W580AU/01 User manual

your

product

online

ns-home.com/welcome

siemens-home.com/welcome

HQ ,QVWDOODWLRQDQGRSHUDWLQJLQVWUXFWLRQV

Tumble dryer

WT47W580AU

Your new tumble dryer

You have opted for a tumble dryer

manufactured by Siemens.

Please take a few minutes to read and

become familiar with the advantages of

your tumble dryer.

To meet the high quality demands

required by Siemens, every tumble dryer

that leaves our factory is carefully

checked to ensure that it functions

correctly and is in perfect condition.

For more information on our products,

accessories, replacement parts and

services, see our website www.siemens-

home.com or contact our Customer

Service centres.

If the operating and installation

instructions describe different models,

any differences will be pointed out at the

relevant points in the text.

Read these operating and installation

instructions before operating the tumble

dryer.

Display rules

:Warning!

This combination of symbol and signal

word indicates a possibly dangerous

situation. Not heeding the warning can

cause death or injuries.

Caution!

This signal word indicates a possibly

dangerous situation. Not heeding the

caution can cause property and/or

environmental damage.

Note/tip

Information about the optimum use of

the appliance/any other useful

information.

1. 2. 3. / a) b) c)

The steps are represented by numbers

or letters.

■/ -

Lists are represented by a small box or

a dash.

Contents

en Installation and operating instructions

8Intended use. . . . . . . . . . . . . . . . .4

(Safety instructions . . . . . . . . . . .4

Electrical safety. . . . . . . . . . . . . . . . . . 4

Safety for children. . . . . . . . . . . . . . . . 5

Appliance safety . . . . . . . . . . . . . . . . . 5

7Environmental protection . . . . . .7

Packaging/old appliance . . . . . . . . . . 7

Coolant . . . . . . . . . . . . . . . . . . . . . . . . 7

Energy-saving tips. . . . . . . . . . . . . . . . 7

YThe main points in brief . . . . . . .8

*Getting to know

your appliance . . . . . . . . . . . . . . .9

Dryer. . . . . . . . . . . . . . . . . . . . . . . . . . 9

Control panel . . . . . . . . . . . . . . . . . . 10

Display panel . . . . . . . . . . . . . . . . . . 11

ZLaundry . . . . . . . . . . . . . . . . . . .12

Preparing the laundry . . . . . . . . . . . . 12

Sorting washing according to: . . . . . 12

/Programmes and buttons . . . . .13

Programmes . . . . . . . . . . . . . . . . . . . 13

Buttons . . . . . . . . . . . . . . . . . . . . . . . 15

1Operating the appliance . . . . . .16

Loading laundry

and switching on the dryer . . . . . . . . 16

Setting a programme . . . . . . . . . . . . 16

Starting the programme . . . . . . . . . . 17

Programme sequence . . . . . . . . . . . 17

Changing the programme

or adding laundry . . . . . . . . . . . . . . . 17

Cancelling the programme . . . . . . . . 17

Programme end . . . . . . . . . . . . . . . . 17

Removing laundry

and switching off the dryer . . . . . . . . 17

Clean the fluff filter . . . . . . . . . . . . . . 18

Emptying

the condensate container . . . . . . . . . 19

MSignal setting. . . . . . . . . . . . . . . 20

>Noises . . . . . . . . . . . . . . . . . . . . 21

DCleaning . . . . . . . . . . . . . . . . . . . 22

Cleaning the dryer

and the control panel . . . . . . . . . . . .22

Cleaning the moisture sensor . . . . . .22

Cleaning the filter

in the condensate container . . . . . . .22

3Faults and what to do

about them . . . . . . . . . . . . . . . . . 23

JAfter-sales service . . . . . . . . . . 25

[Consumption values. . . . . . . . . 26

Consumption values table . . . . . . . . .26

JTechnical data . . . . . . . . . . . . . . 27

5Installation and connection . . . 28

Scope of delivery. . . . . . . . . . . . . . . .28

Installing

and connecting the dryer . . . . . . . . .28

Changing the condensation drain . . .29

Optional accessories. . . . . . . . . . . . .31

Transport and frost protection . . . . . .31

en Intended use

8Intended use

Intendeduse

■Operate the dryer:

– Indoors only (not in an outside

area),

– Only inside the home and

– Only to dry and refresh fabrics

that have a care label specifying

that they are suitable for use in a

dryer.

■The dryer can be operated by

children 8 years old and older, by

persons with reduced physical,

sensory or mental abilities and by

persons with insufficient experience

or knowledge if they are supervised

or have been instructed in its use by

a responsible adult.

■Keep children under the age of 3

years old away from the dryer.

■Do not let children carry out any

unsupervised cleaning or

maintenance work on the dryer.

■Keep pets away from the dryer.

(Safety instructions

Safetyinstructions

Electrical safety

:Warning

Risk of death!

There is a risk of electric shock

as the dryer is operated with

electricity.

You should therefore observe

the following:

■Never touch or hold the

mains plug with wet hands.

■Only pull out the mains cable

directly at the plug and never

by the cable, as this could

damage it.

■Do not use extension cables,

multiple plugs or connectors.

■Only have the mains cable

replaced by our after-sales

service.

Safety instructions en

Safety for children

:Warning

Risk of death or injury!

You should therefore observe

the following:

■Do not leave the dryer

unattended when children or

other people who cannot

assess the risks are nearby.

■Do not let children play with

the dryer.

■Children may become

entangled in packaging or

film if allowed to play with

them, or they may pull them

over their heads and

suffocate. Keep packaging,

packaging parts and film out

of the reach of children.

■Children may lock

themselves in the dryer.

Therefore, when an

appliance has reached the

end of its service life, unplug

it from the mains, cut through

the mains cable and destroy

the lock on the dryer door.

Appliance safety

:Warning

Risk of death!

■Do not use the dryer if

industrial chemicals have

been used to clean it.

■Laundry that has come into

contact with solvents, oil,

wax, wax remover, paint,

grease or stain remover may

ignite or cause an explosion

when drying is in progress.

Before drying, rinse the

laundry in hot water with

detergent.

■Coal dust or flour in the area

around the dryer may cause

an explosion.

■Only replace defective

components with genuine

spare parts.

en Safety instructions

Caution!

Risk of material damage to the

dryer or fabrics

■Only use the dryer for drying

and freshening up fabrics at

home and for fabrics that

have been washed with

water and are suitable for

tumble-drying.

Any other use is not

considered intended use and

is prohibited.

■Foamed material or foam

rubber may become

deformed or melt during

drying. Do not dry any

laundry that contains foamed

material or rubber.

■Do not lean or sit on the

dryer door, as the dryer may

tip over.

■Loose cables or hoses may

cause you to trip. Avoid

tripping hazards.

■Light things, such as hair,

may be sucked into the air

inlet during operation; keep

these away from the dryer.

■The last phase of the drying

cycle takes place without any

heat (cooling cycle) to

ensure that the laundry

remains at a temperature

that will not damage it.

Environmental protection en

7Environmental

protection

Environmentalprotection

Packaging/old appliance

)

Dispose of packaging in an

environmentally-responsible manner.

This appliance is designated according

to European directive 2012/19/EC

which governs waste electrical and

electronic equipment (WEEE).

The directive provides a framework

for the collection and recycling of old

appliances, which is valid across

the EU.

Coolant

The dryer's heat exchanger contains

fluorinated greenhouse gas in a

hermetically sealed unit.

Dispose of the dryer properly.

Energy-saving tips

■Spin the laundry before drying. The

drier the laundry, the shorter the

drying time will be, thus consuming

less energy.

■Load the dryer with the maximum

load.

Note: Do not exceed the maximum

load for the programs, as this

prolongs the drying time and

increases energy consumption.

■Ventilate the room and keep the air

inlet on the dryer free to ensure air

exchange.

■Clean the fluff filter after each drying

cycle. If the fluff filter is dirty, the

drying time is prolonged and energy

consumption is increased.

■Energy saving mode: If the dryer is

not operated for a prolonged period,

it automatically switches off before

the program starts and when the

program has ended to save energy.

The display panel and indicator

lamps go off after a few minutes and

the Start button flashes. To activate

the lighting, press any button, open

or close the dryer door or turn the

program selector.

Greenhouse gas: R407c

Capacity (g): 385

GWP (kgCO2/kgRefrig): 1653

Total GWP (kgCO2): 636.4

en The main points in brief

YThe main points in brief

Themainpointsinbrief

--------

1@ @

Load the laundry and close

the door.

Switch off the dryer. Select a programme and,

if necessary, adjust

the default programme

settings.

2@ @

Select the start button Ü. Dry. Unload the laundry.

3@ @

Switch off the dryer. Empty the condensate

container.

Clean the fluff filter.

Getting to know your appliance en

*Getting to know your appliance

Gettingtoknowyourappliance

Dryer

(Condensate container

0Control and display panel

8Drum interior light (depending on the model)

@Dryer door

HAir inlet

PFluff filter







en Getting to know your appliance

Control panel

Note: All buttons are sensitive and only need to be touched briefly.



(Programmes ~Page 13.

0Programme selector and On/Off button.

8Display panel with buttons ~Page 13.

@Start button for starting, interrupting or cancelling the programme.

HButtons ~Page 15.

This manual suits for next models

Table of contents

Other Siemens Dryer manuals

Siemens

Siemens WT47W560TR User manual

Siemens

Siemens WQ45G2ABDN User manual

Siemens

Siemens WQ33G2CIDN User manual

Siemens

Siemens WT34A201HK User manual

Siemens

Siemens WT46G4000W User manual

Siemens

Siemens WT46G482IL User manual

Siemens

Siemens WT46G40SZA User manual

Siemens

Siemens WT46G400HK User manual

Siemens

Siemens WQ41G29IL User manual

Siemens

Siemens Dryer User manual

Siemens

Siemens WT47W591GB User manual

Siemens

Siemens WT46E381GB User manual

Siemens

Siemens WP31G200IN User manual

Siemens

Siemens WT46N203IN User manual

Siemens

Siemens WT47XM01CS User manual

Siemens

Siemens WT43H007DN User manual

Siemens

Siemens WT47G438ES User manual

Siemens

Siemens WT47U640EU User manual

Siemens

Siemens WT4HXKE9DN User manual

Siemens

Siemens WT47W540ZA User manual

Siemens

Siemens WT47W4E9DN User manual

Siemens

Siemens WT45W460AU User manual

Siemens

Siemens WT46G400AU User manual

Siemens

Siemens WT47XKH1ZA User manual

Popular Dryer manuals by other brands

Bosch

Bosch WTA79200GB Installation and operating instructions

Amana

Amana W10233410A Use and care guide

Miele

Miele TWH 780 WP operating instructions

Asko

Asko T760 user guide

Alliance Laundry Systems

Alliance Laundry Systems 25 Series Original instructions

Bosch

Bosch Logixx 10 WTB76556GB Instruction manual and installation instructions

STIEBEL ELTRON

STIEBEL ELTRON Ultronic S Operation and installation

Electrolux

Electrolux EW2H328R2 user manual

Beko

Beko DS8433RX1M user manual

Dawlance

Dawlance Spinner DS 6000 C owner's manual

Electrolux

Electrolux TP5080TW user manual

AEG

AEG TR838P4OB user manual

Indesit

Indesit IDV 75 instruction manual

Infiniton

Infiniton SD-DG85C manual

BOMANN

BOMANN WT 5019 instruction manual

Alliance Laundry Systems

Alliance Laundry Systems TMB795C Installation

Asko

Asko T793C operating instructions

Kenmore

Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer installation instructions
