Shuttle XPC SD39P2 User manual

XPCUserGuide

Forthe:SD39P2

ShuttleMainboardEMITestStatement

ShuttlemainboardshavebeenthroughEMItestsaccordingtothe followingseriesofregulations:

EN55022/CISPR22/AS/NZS3548ClassB,EN55024(1998/AS/NZS),EN4252.1(1994),EN61000,

ANSIC63.4(1992),CFR47 Part15 SubpartB,and CNS13438 (1997).The itemstested are

illustrated asfollows:

(A)Voltage:AC110V/60HZ&AC230V/50HZ

(B)Tested ProductInformation:

ProductName:PCMainboard

Status:Sample

ModelName:SD39P2

S/N:N/A

CPU:

IntelPentium4,LGA775 Core2 ExtremeX6800 Conroe 2.93GHz

FSB 1066 4ML2 cache B1stepping

USB 2.0Port: eightportswith4pinsrespectively

1394 Port: one portswith4pinsand one portswith6pinsrespectively

LANPort: one portwith8pins(10Mbps/100Mbps/1000Mbps)

Line-OutPorts:fourports

Front-OutPort: one port

Mic-InPorts:one port

Line-InPorts:one port

SPDIF-Out(Coaxial)Port: one port

SPDIF-Out(Optical)Port: one port

SPDIF-In(Optical)Port: one port

ClearCMOSbutton:one port

DIMM Memory(optional):DDR2533/667 2GBx4

PowerCable:Detachableand Shielded (withaGNDpin)

ExternalSerial-ATAII Port: one portwith7pins

All CPUshavecompletelybeen tested,and valuesoffered bythe worstEMIcombination of

CPUexternalfrequency arelisted asfollows:

TestMode ExternalFrequency CPU CPUOpen/Close

1 1066MHzConroe 2.93GHzClose

2 1066MHzConroe 2.93GHzOpen

(C)Remedyforthe Tested Product&ItsEMIInterference:

Remedy:N/A

EMIInterference:

Crystal:14.318MHz(X2)/25MHz(X3)/32.768KHz(X1)/24MHz(X7)

ClockGenerator:U6

(D)Supported HostPeripherals:

ComponentBrand ModelNo./Spec.

HDD x1HitachiTEOMV90K

DVD-ROMBTCP10437007994

Memoryx2Transcend 126589-0368(NH)/126589-0369(NH)

PowerShuttlePC43I3503

(E)NoticesforAssembling Computers:

1.AnI/O shielding shouldbe contacted withI/O metallicpartsofamainboard.

2.Cablesshouldappropriatelybe arranged and fixed inacase.Followinstructions:

ØLeaveIDEcablesnotcrossed upon CPUand SDRAM;

ØLeavepowercablesminimuminlength,and notcrossed upon amainboard;

ØLeaveCPUfan cablesminimuminlength,and notnearCPU;

ØLeavecableson panelsand othersparecablestied inacomputercase.

3.Makesurean EMIshielding attached toacasehasbeen properlyinstalled.

4.Makesurea5.25"driveand screwsarefastened tothe case(EMIshielding).

5.Makesurethe caseisincontactwithEMIconnection points.

6.Makesurethereisno cleft inthe case.

7.MakesureaPCIdoorisbound toacase.

8.Makesurecablesofotherdevices(fansorsomeothers)arefixed inacase.

Shuttle®

XPCInstallation Guide

Nopartofthispublication maybereproduced,transcribed,storedinaretrievalsystem,

translatedintoanylanguage,ortransmittedinanyform orbyanymeans,electronic,

mechanical, magnetic,optical, chemical, photocopying,manual, orotherwise,withoutprior

writtenpermission fromShuttle®Inc.

Disclaimer

Shuttle®Inc.shall notbeliableforanyincidentalorconsequentialdamagesresultingfrom

theperformanceoruseofthisproduct.

Thiscompanymakesno representationsorwarrantiesregardingthecontentsofthisma-

nual. Information inthismanualhasbeencarefullycheckedforreliability;however,no

guarantee isgivenastothecorrectness ofthecontents.Intheinterestofcontinuedproduct

improvement, thiscompanyreservestherighttorevisethemanualorincludechangesin

thespecificationsoftheproductdescribedwithinit atanytimewithoutnoticeand without

obligation tonotifyanyperson ofsuchrevision orchanges.Theinformation containedin

thismanualisprovidedforgeneralusebycustomers.

ThisdevicecomplieswithPart15 oftheFCC Rules,Operation issubjecttothefollowing

twoconditions:

1.Thisdevicemaynotcauseharmfulinterference.

2.Thisdevicemustacceptanyinterferencereceived,includinginterferencethatmay

causeundesiredoperation.

Trademarks

ShuttleisaregisteredtrademarkofShuttleInc.

Inteland PentiumareregisteredtrademarksofIntelCorporation.

PS/2isaregisteredtrademarkofIBMCorporation.

AWARDisaregisteredtrademarkofAwardSoftwareInc.

Microsoft and WindowsareregisteredtrademarksofMicrosoft Corporation.

GeneralNotice

Otherbrand and productnamesusedhereinareforidentification purposesonlyand may

betrademarksoftheirrespective owners.

InstallationNotices

Donotplace thisdevice underneath

heavy loadsorinanunstableposition.

Donotexpose thisdevice tohigh

levelsofdirectsunlight,high-humidity

orwetconditions.

Donotuse orexpose thisdevice

around magneticfieldsas magnetic

interference may affectthe

performance ofthedevice.

Donotblock theairventstothis

device orimpedetheairflowin

anyway.

CAUTION

Incorrectlyreplacing the batterymaydamage thiscomputer.Replaceonlywith

the sameorequivalentasrecommendedbyShuttle.Disposeofused batteries

accordingtothemanufacturer'sinstructions.

SafetyInformation

Read the following precautionsbeforesetting up aShuttleXPC.

1Driverand SoftwareInstallation .........................................................................1

1.1MainboardDriverCD .................................................................................1

1.1.1Install MainboardSoftware..................................................................... 2

Appendix............................................................................................................3

EntertheBIOS.................................................................................................3

THEMAIN MENU ............................................................................................4

StandardCMOSFeatures................................................................................ 6

AdvancedBIOSFeatures................................................................................. 9

AdvancedChipsetFeatures........................................................................... 13

IntegratedPeripherals.................................................................................... 15

PowerManagementSetup ............................................................................. 19

PnP/PCIConfigurations................................................................................ 22

PCHealthStatus........................................................................................... 24

FrequencyControl ........................................................................................ 26

LoadFail-SafeDefaults.................................................................................. 28

LoadOptimizedDefaults............................................................................... 28

SetSupervisor/UserPassword........................................................................ 28

Save &Exit Setup .......................................................................................... 29

Exit WithoutSaving....................................................................................... 29

TABLE OFCONTENTS

English

<1.1MainboardDriverCD

TheMainboardDriverCDcontainsall themotherboarddrivernecessarytooptimize

theperformanceofthisXPCinaWindows(R)OS.Install thesedriversafterinstalling

Microsoft(R)Windows(R).

Navigation BarDescription :

FInstall MainboardSoftware-IntelChipsetDriver,IntelHighDefinition Audio

Driver,BroadcomGigaLANDriver,BroadcomBACS,IntelMatrixstroage

Driver,IntelUSB2.0Driver,DirectX9Utility.

FInstall Utility-Install AcrobatReader,WinFlashUtility,XPCTools.

FManual-SD39P2 user'sguideand RAID manualinPDFformat.

FLinktoShuttleHomepage -Linktoshuttlewebsitehomepage.

FBrowsethisCD-Allowsyou tosee contentsofthisCD.

FQuit -ClosethisCD.

Note:TheCDcontentsattachedinSD39P2 mainboardaresubject

tochange withoutnotice.

1Driverand SoftwareInstallation

English

<1.1.1Install MainboardSoftware

InserttheattachedCDintoyourCD-ROMdrive.TheCDAutoRun screenshould

appear.If theAutoRun screendoesnotappear,doubleclickon Autorun icon inMy

Computertobringup ShuttleMainb-oardSoftwareSetup screen.

Clickthe“Install Main-boardSoftware“ bar.Individuallyinstall thefollowingdrivers.

EInstall IntelChipsetDriver

EInstall IntelHighDefinition AudioDriver

EInstall BroadcomGigaLANDriver

EInstall BroadcomBACS

EInstall IntelMatrixStroage Driver

EInstall IntelUSB2.0Driver

EInstall DirectX9Utility

English

BIOSSettings

TheSD39P2 BIOSROMhasabuilt-inSetup programthatallowsuserstomodifybasic

systemconfiguration.Thisinformation isstoredinbattery-backedRAMsothatit re-

tainsSetup information evenif thesystempoweristurnedoff.

ThesystemBIOSmanagesand executesavarietyofhardwarerelatedfunctions

including:

Systemdateand time

Hardwareexecution sequence

Powermanagementfunctions

Allocation ofsystemresources

EntertheBIOS

To entertheBIOS(BasicInput/OutputSystem)utility,followthesesteps:

Step1.Poweron thecomputer.Thesystemwill perform itsPOST(Power-On

Self Test) routinechecks.

Step2.Press the<Del>key immediately,oratthefollowingmessage:

Press DEL toenterSETUP,orsimultaneouslypress <Ctrl>,<Alt>,

<Esc>keys

Note1. If you miss thetrainofwordsmentionedinstep2 (themessage disap-

pearsbeforeyou canrespond)and you still wishtoenterBIOSSetup,

restartthesystemand tryagainbyturningthecomputerOFF and

ONagainorbypressingthe<RESET>switchlocatedatthe

computer’sfront-panel. You mayalsorebootbysimultaneously

pressingthe<Ctrl>,<Alt>,<Del>keyssimultaneously.

Note2. If you do notpress thekeysintimeand systemdoesnotboot, the

screenwill promptanerrormessage,and you will begiventhe

followingoptions:

"Press F1toContinue,DEL toEnterSetup”

Step3.Whenyou entertheBIOSprogram,theCMOSSetup Utilitywill displaythe

MainMenu,asshowninthenextsection.

Appendix

English

TheMainMenu

Onceyou entertheAwardBIOS(tm)CMOSSetup Utility,theMainMenu

will appearon thescreen.TheMainMenu allowsyou toselectfromsev-

eralsetup functionsand twoexit choices.Usethearrowkeystoselect

amongtheitemsand press <Enter>toacceptand enterthesub-menu.

Notethatabriefdescription ofeachhighlightedselection appearsatthe

bottomofthescreen.

Setup Items

Themainmenu includesthefollowingmainsetup categories.Recall that

somesystemsmaynotincludeall entries.

StandardCMOSFeatures

Usethismenu forbasicsystemconfiguration.

AdvancedBIOSFeatures

Usethismenu tosettheAdvancedFeaturesavailableon yoursystem.

AdvancedChipsetFeatures

Usethismenu tochange thevaluesinthechipsetregistersand optimize

yoursystem'sperformance.

IntegratedPeripherals

Usethismenu tospecifyyoursettingsforintegratedperipherals.

PowerManagementSetup

Usethismenu tospecifyyourpowermanagementsettings.

PnP/PCIConfigurations

Thisentryappearsif yoursystemsupportsPnP /PCI.
