Sharp Advanced MXM365N User manual

Digital multifunctional system MX-M365N/MX-M465N/MX-M565N

PRINTING ALL CATEGORIES

USER'S MANUAL | MX-M365N/MX-M465N/MX-M565N USER'S ... http://siica.sharpusa.com/portals/0/downloads/Manuals/MX-M365N-M...

1 of 1441 3/17/2016 7:14 AM

EXTERIOR

This section describes the names and functions of the respective parts on the exterior of the

machine.

Tap the name to make its details pop up.

Automatic document feeder

This automatically feeds and scans multiple originals.

Both sides of 2-sided originals can be automatically scanned at one time.

- AUTOMATIC DOCUMENT FEEDER

Front cover

Open this cover to switch the main power switch to "On" or "Off" or to replace a toner cartridge.

- TURNING ON THE POWER

- REPLACING THE TONER CARTRIDGE

Output tray (center tray)*

Printed paper is output into this tray.

Operation panel

This panel hosts the [Power] button, [Power Save] button/indicator, [Home Screen] button, main power button

and touch panel.

Use the touch panel to operate each of these functions.

- OPERATION PANEL

Right tray*

Set so that paper is output into this tray as required.

By setting originals received via fax or Internet fax to be output into this tray, you can separate them from

paper output from copying.

Finisher*

This staples paper.

A punch module can also be installed to punch holes in output paper.

- FINISHER

Saddle finisher (large stacker)*

This staples and folds paper. A punch module can also be installed to punch holes in output paper.

- SADDLE FINISHER (LARGE STACKER)

USER'S MANUAL | MX-M365N/MX-M465N/MX-M565N USER'S ... http://siica.sharpusa.com/portals/0/downloads/Manuals/MX-M365N-M...

2 of 1441 3/17/2016 7:14 AM

Paper pass unit*

This unit sends printed paper to the finisher (large stacker), saddle finisher or saddle finisher (large stacker), or

functions as a relay between the machine and the finisher (large stacker), saddle finisher or saddle finisher

(large stacker).

USB port (A type)

This is used to connect a USB device such as a USB memory device to the machine. For the USB cable, use a

shielded cable.

Supports USB 2.0 (Hi-Speed).

Keyboard

Use this as a substitute for the soft keyboard displayed on the touch panel. When not being used, it can be

stored under the operation panel.

Tray 1

Store paper in this tray.

- LOADING PAPER INTO A TRAY

Tray 2 (when a stand/500/2x500/3x500/500&2000 sheet paper drawer is installed)*

Store paper in this tray.

- LOADING PAPER INTO A TRAY

Tray 3 (when a stand/2x500/3x500 sheet paper drawer is installed)*

Store paper in this tray.

- LOADING PAPER INTO A TRAY

Tray 4 (when a stand/3x500 sheet paper drawer is installed)*

Store paper in this tray.

- LOADING PAPER INTO A TRAY

Tray 5 (when a large capacity paper tray is installed)*

Store paper in this tray.

- LOADING PAPER INTO A LARGE CAPACITY TRAY

Bypass tray

Use this tray to feed paper manually.

When loading paper larger than 8-1/2" x 11"R or A4R, pull out the extension guide.

- LOADING PAPER INTO THE BYPASS TRAY

Tray 3 (when a stand/500&2000 sheet paper drawer is installed)*

USER'S MANUAL | MX-M365N/MX-M465N/MX-M565N USER'S ... http://siica.sharpusa.com/portals/0/downloads/Manuals/MX-M365N-M...

3 of 1441 3/17/2016 7:14 AM

Store paper in this tray.

- TRAY 3 - 4 (STAND/500&2000 SHEET PAPER DRAWER)

Tray 4 (when a stand/500&2000 sheet paper drawer is installed)*

Store paper in this tray.

- TRAY 3 - 4 (STAND/500&2000 SHEET PAPER DRAWER)

Punch module*

This is used to punch holes in output. Requires a saddle finisher, saddle finisher (large stacker), or finisher (large

stacker).

- PUNCH MODULE

Finisher (large stacker)*

This staples paper. A punch module can also be installed to punch holes in output paper.

- FINISHER (LARGE STACKER)

Saddle finisher*

This staples and folds paper. A punch module can also be installed to punch holes in output paper.

- SADDLE FINISHER

USER'S MANUAL | MX-M365N/MX-M465N/MX-M565N USER'S ... http://siica.sharpusa.com/portals/0/downloads/Manuals/MX-M365N-M...

4 of 1441 3/17/2016 7:14 AM

* Optional

USER'S MANUAL | MX-M365N/MX-M465N/MX-M565N USER'S ... http://siica.sharpusa.com/portals/0/downloads/Manuals/MX-M365N-M...

5 of 1441 3/17/2016 7:14 AM

UPPER SIDE

This section describes the names and functions of the respective parts inside the machine.

Toner cartridge

This cartridge contains toner.

When the toner in a cartridge runs out, replace with new one.

- REPLACEMENT OF TONER CARTRIDGE

Fusing unit

Heat is applied here to fuse the transferred image onto the paper.

Transfer roller

Forms a black toner image on the transfer roller and transfers the image to the paper.

Right side cover

Open this cover to remove a misfeed.

Paper reversing section cover

This unit is used for reversing paper when 2-sided printing is performed. Open this cover to remove

a paper misfeed.

Main power switch

Use this switch to turn on the power for the machine.

When using the fax or Internet fax functions, always keep this switch in the “ ” position.

- TURNING ON THE POWER

The fusing unit is hot. Take care not to burn yourself when removing a misfeed.

Do not touch or damage the transfer roller.

This may cause a defective image.

USER'S MANUAL | MX-M365N/MX-M465N/MX-M565N USER'S ... http://siica.sharpusa.com/portals/0/downloads/Manuals/MX-M365N-M...

6 of 1441 3/17/2016 7:14 AM

Toner collection container

This container collects excess toner that remains after printing.

- REPLACING THE TONER COLLECTION CONTAINER

Toner collection container release lever

Press up this lever when you need to release the toner collection container lock to replace the

toner collection container.

- REPLACING THE TONER COLLECTION CONTAINER

Handle

Pull this out and grasp it when moving the machine.

A stand/500/2x500/3x500/500&2000 sheet paper drawer right-side cover

Open this cover to remove a paper misfeed in tray 2, 3 or 4.

Paper tray right side cover

Open this to remove a paper misfeed in tray 1 or 2.

Right side cover release lever

To remove a paper misfeed, pull and hold this lever up to open the right side cover.

Bypass tray

Use this tray to feed paper manually.

When loading paper larger than 8-1/2" x 11"R or A4R, pull out the extension guide.

- LOADING PAPER INTO THE BYPASS TRAY

Tap the name to make its details pop up.

A service technician collects replaced toner collection containers.

USER'S MANUAL | MX-M365N/MX-M465N/MX-M565N USER'S ... http://siica.sharpusa.com/portals/0/downloads/Manuals/MX-M365N-M...

7 of 1441 3/17/2016 7:14 AM

USER'S MANUAL | MX-M365N/MX-M465N/MX-M565N USER'S ... http://siica.sharpusa.com/portals/0/downloads/Manuals/MX-M365N-M...

8 of 1441 3/17/2016 7:14 AM

TOP

This section describes the names and functions of the respective parts on the upper side

of the machine.

Tap the name to make its details pop up.

Document feeding cover

Open this cover to remove an original misfeed or clean the paper feed roller.

Original guides

These guides help ensure that the original is scanned correctly.

Adjust the guides to the width of the original.

- AUTOMATIC DOCUMENT FEEDER

Document feeder tray

Set the original in this tray. 1-sided originals must be placed face up.

- AUTOMATIC DOCUMENT FEEDER

Original exit tray

The original is discharged to this tray after scanning.

USER'S MANUAL | MX-M365N/MX-M465N/MX-M565N USER'S ... http://siica.sharpusa.com/portals/0/downloads/Manuals/MX-M365N-M...

9 of 1441 3/17/2016 7:14 AM

SIDE AND BACK

This section describes the names and functions of the respective parts on the side and

back of the machine.

USB port (A type)

This is used to connect a USB device such as a USB memory device to the machine.

Supports USB 2.0 (Hi-Speed).

USB port (B type)

A computer can be connected to this connector to use the machine as a printer.

For the USB cable, use a shielded cable.

Supports USB 2.0 (Hi-Speed).

LAN connector

Connect the LAN cable to this connector when the machine is used on a network.

Use a shielded LAN cable.

Service-only connector

Tap the name to make its details pop up.

This connector is for use only by service technicians.

Connecting a cable to this connector may cause the machine to malfunction.

Important note for service technicians:

The cable connected to the service connector must be less than 118" (3 m) in length.

USER'S MANUAL | MX-M365N/MX-M465N/MX-M565N USER'S ... http://siica.sharpusa.com/portals/0/downloads/Manuals/MX-M365N-M...

10 of 1441 3/17/2016 7:14 AM
