Sharp Plasmacluster AE-A09DJ User manual

AY-AP09DJ

AE-A09DJ

INDOOR UNIT

SPLITTYPE

ROOM AIR CONDITIONER

OPERATIONMANUAL

OUTDOOR UNIT

AY-AP09DJ

ENGLISH

Thank you for purchasing a SHARP air conditioner. Please read this manual carefully

before operating the product.

•PRECAUTIONS ..............................................1

•ADDITIONAL NOTES ON OPERATION ........3

•TIPS ON SAVING ENERGY ...........................3

•PART NAMES.................................................4

•USING THE REMOTE CONTROL .................6

•

TIPS ABOUT PLASMACLUSTER OPERATION....

•BASIC OPERATION .......................................8

•ADJUSTING THE AIR FLOW DIRECTION ....10

CONTENTS

•PLASMACLUSTER OPERATION ........ 11

•ONE-HOUR OFF TIMER ...................... 11

•TIMER OPERATION............................. 12

•AUXILIARY MODE ............................... 14

• MAINTENANCE .................................... 15

•BEFORE CALLING FOR SERVICE ..... 16

•SPECIFICATIONS ................................ 17

PRECAUTIONS

WARNINGS FOR USE

1This model should be installed with a fixed power cord to the meter box.

2Be careful not to expose your body to the outlet air for prolonged periods. It may affect

your physical condition.

3Whenusingtheairconditionerforinfants,children,elderly,bedriddenordisabledpeople

make sure the room temperature is suitable for those in the room.

4Never insert objects into the unit. Inserting objects can result in injury due to the high

speed rotation of the internal fans.

5If anything abnormal with the air conditioner (eg burning smell), stop the opertaion

immediately and turn the circuit breaker off.

6This air conditioner should be installed by a licensed air conditioning contractor in

accordance with AS/NZS 3000:2000 and your electricity suppliers rules.

7There are local council rules regarding maximum allowable noise levels emitted by air

conditioners, your licensed air conditioning contractor will advise you on the correct

location of your outdoor unit.

8Useonlythemanufacture-specifiedpowercordforreplacement.Replacementshouldbe

performed by a service centre approved by SHARP.

WARNINGS FOR INSTALLATION / REMOVAL / REPAIR

For your safety, ensure that your new air conditioner is installed by a licensed air

conditioning contractor in accordance with the AUSTRALIAN/NEW ZEALAND WIRING

RULES.

•Donotattempttoinstall/remove/repairtheunitbyyourself.Incorrectworkwillcauseelectric

shock,water leak,fireetc. Consult alicensed air conditioning contractor for the installation/

removal/repair of the unit.

PRECAUTIONS

CAUTIONS FOR USE

1If a gas appliance is used in the same room as the air conditioner, ventilate the room

periodically to prevent oxygen depletion.

2For safety, do not touch the unit with wet hands, it may cause an electric shock.

3For safety, turn the circuit breaker off when not using the unit for an extended period of

time.

4For safety, do not place anything on top of the outdoor unit or step on it.

5This unit is designed for residential use. Do not use for other applications such as in a

kennel or greenhouse to raise animals or grow plants.

6Do not block the air inlets or outlets of the unit.

7For safety, be sure to turn the unit off the circuit breaker before performing any

maintenance or cleaning.

Do not pour water directly on the unit. Water can cause electrical shock or equipment

failure.

This appliance is not intended for use by young children or infirm persons without

supervision.

Young children should be supervised to ensure that they do not play with the appliance.

CAUTIONS FOR LOCATION / INSTALLATION

To ensure that your warranty is not cancelled, both the indoor/outdoor units and supply/

interconnecting cables must be installed by a licensed air conditioning contractor.

•The unit is designed to operate on 230-240 VAC, 50Hz

•Do not install the unit where flammable gas may leak. It may cause a fire.

INDOOR TEMP. OUTDOOR TEMP.

COOLING upper limit 32˚C D.B. 46˚C D.B.

23˚C W.B. -

lower limit 21˚C D.B. 21˚C D.B.

15˚C W.B. -

HEATING upper limit 27˚C D.B. 24˚C D.B.

- 18˚C W.B.

lower limit 20˚C D.B. -8.5˚C D.B.

- -9.5˚C W.B.

ADDITIONAL NOTES ON OPERATION

OPERATING TEMPERATURE RANGE •The built-in protective

device may prevent the

unit from operating when

used out of this range.

•Condensation may form

on the air outlet if the

unit operates continu-

ously in the COOL or

DRY mode when humid-

ity is over 80 percent.

D.B. = Dry-bulb W.B. = Wet-bulb

PREHEATING FUNCTION

In the HEAT operation, the indoor fan may not start for two to five minutes after the unit is turned on to prevent

cold air from blowing out of the unit.

DE-ICING FUNCTION

•When ice forms on the heat exchanger in the outdoor unit during the HEAT operation, an automatic de-icer

provides heat for about 5 to 10 minutes to remove the ice. During de-icing, the inside and outside fans stop

operating.

•After de-icing is completed, the unit automatically resumes operation in the HEAT mode.

HEATING EFFICIENCY

•The unit employs a heat pump that draws heat from the outside air and releases it into the room. The outside

air temperature therefore greatly affects the heating efficiency.

•If the heating efficiency is reduced due to low outside temperatures, use an additional heater.

•It takes time to warm up and heat the entire room because of the forced air circulation system.

TIPS ON SAVING ENERGY

Below are some simple ways to save energy when you use your air conditioner.

SET THE CORRECT TEMPERATURE

•Setting the thermostat 1°C higher than the desired temperature in the COOL mode and 2°C lower in the

HEAT mode will save approximately 10 percent in power consumption.

•Setting the temperature lower than necessary during cooling operation will result in increased power

consumption.

BLOCK DIRECT SUNLIGHT AND PREVENT DRAFTS

•Blocking direct sunlight during cooling operation will reduce power consumption.

•Close the windows and doors during opeation.

SET PROPER AIR FLOW DIRECTION TO OBTAIN THE BEST AIR

CIRCULATION

KEEP FILTER CLEAN TO ENSURE THE MOST EFFICIENT OPERATION

MAKE MOST OF THE TIMER OFF FUNCTION

DISCONNECT THE POWER CORD WHEN THE UNIT IS NOT USED FOR AN

EXTENDED PERIOD OF TIME

•The indoor unit still consumes a small amount of power when it is not operating.

WHEN POWER FAILURE OCCURS

This air conditioner has a memory function to store settings when a power failure occurs.

After power recovery, the unit will automatically re-start in the same settings which were active before the power

failure, except for timer settings.

If the timers were set before a power failure, they will need to be re-set after power recovery.

PART NAMES

1Inlet (Air)

2Open Panel

3Air Filters

4AUX. Button

5RECEIVER Window

6Power Supply Cord

7Indicator Panel

8Vertical Adjustment Louvres

9Horizontal Adjustment Louvres

0Outlet (Air)

qRemote Control

wAUTO FAN SPEED Lamp

(green )

eFAN SPEED Lamp (green )

rPLASMACLUSTER Lamp (blue,

green)

tTIMER Lamp (orange )

yOPERATION Lamp (red )

OUTDOOR UNIT

NOTE: Actual units might vary slightly from those shown above.

INDOOR UNIT

uInlet (Air)

iRefrigerant Tube and

Interconnecting Cord

oDrainage Hose

pOutlet (Air)

REMOTE CONTROL

1TRANSMITTER

2DISPLAY (Liquid Crystal Display)

3ON/OFF Button

4THERMO. (Thermostat) Button

5DISPLAY Button

6MODE Button

7TIMER ON Button (for setting the timer)

8ONE-HOUR OFF TIMER Button

9TIMER OFF Button (for setting the timer)

0FAN Button

qTIMER CANCEL Button

wSWING Button

ePLASMACLUSTER Button

rMODE SYMBOLS

: AUTO : HEAT

: COOL : DRY : FAN ONLY

tFAN SPEED SYMBOLS

: AUTO : Manual setting

yPLASMACLUSTER SYMBOL

uTEMPERATURE AND TIMER COUNT DOWN

INDICATOR

iTRANSMITTING SYMBOL

oTIMER ON/TIMER OFF INDICATOR

Indicates when timer on or timer off is set.

L.C.D. REMOTE CONTROL DISPLAY

MODE

DISPLAY MODE

FAN1h

SWING

CANCEL

TEMP.

FAN TIMER

CAUTION

•Do not allow the signal receiver window to receive strong direct sunlight, since it can

adversely affect its operation. If the signal receiver window is exposed to direct sunlight,

close a curtain to block the light.

•Using a fluorescent lamp with a quick starter in the same room may interfere with

transmission of the signal.

•The unit can be affected by signals transmitted from the remote control of a television,

VCR or other equipment used in the same room.

•Do not leave the remote control in direct sunlight or near a heater. Also, protect the unit

and remote control from moisture and shock which can discolour or damage them.

1Remove the battery cover at the back of

the remote control.

2Insert batteries in the compartment, mak-

ing sure the ±and —polarities are

correctly aligned.

•Lines will be indicated on the display

when batteries are properly installed.

3Replace the battery cover.

USING THE REMOTE CONTROL

NOTES:

•The battery life is approximately one year in normal use.

•When you replace the batteries, always change both batteries, and make sure

they are the same type.

•If the remote control does not operate properly after replacing the batteries, take

out the batteries and reinstall them again after 30 seconds.

•If you will not be using the unit for a long time, remove the batteries from the

remote control.

Point the remote control towards the

unit’s signal receiver window and

press the desired button. The unit

generates a beep when it receives the

signal.

•Make sure there is no curtain or other

object between the remote control and

the unit.

•The operation range of the remote control

is up to 7 metres.

LOADING BATTERIES Use two size-AAA (R03) batteries.

HOW TO USE THE REMOTE CONTROL

Battery cover

TIPS ABOUT PLASMACLUSTER OPERATION

AIR CLEAN OPERATION

Cluster ions released into the air will reduce airborne mold fungus.

ION BALANCE OPERATION

It is said that plenty of negative ions exist in places such as waterfalls or watreside in

natural environment. In this operation mode, negative ions will be released in an

increased rate, in order to bring the room air close to this condition.

Please refer to page 11 for operation.

The ionizer inside the air conditioner will release cluster ions, which are collective

mass of positive and negative ions, into the room.

The cluster ions reduce airborne mold fungus.

Ionizer

Cluster ions

Mold fungus

Press the THERMO. button to set the

desired temperature.

AUTO/DRY MODE

The temperature can

be changed in 1°C in-

crements within the

range of 2°C higher to

2°C lower from the tem-

perature automatically

determined by the air

conditioner.

COOL/HEAT MODE

The temperature can

be set within the range

of 18 to 32°C.

FAN ONLY MODE

The temperature set-

ting cannot be made.

BASIC OPERATION

2Press the ON/OFF button to start op-

eration.

•The red OPERATION lamp ( ) on the

unit will light.

Press the MODE button to select the

operation mode.

AUTO HEAT COOL DRY FAN ONLY

MODE

DISPLAY MODE

FAN1h

SWING

CANCEL

TEMP.

FAN TIMER

Press the FAN button to set the de-

sired fan speed.

AUTO SOFT LOW HIGH

•In the DRY mode, the fan speed is pre-

set to AUTO and cannot be changed.

•In the FAN ONLY mode, the fan speed

cannot be set to AUTO.

To turn off the unit, press the ON/OFF

button again.

•The red OPERATION lamp ( ) on the

unit will turn off.

This manual suits for next models

Table of contents

Other Sharp Air Conditioner manuals

Popular Air Conditioner manuals by other brands

Spheros

Spheros CC 355 instructions

Bosch

Bosch Climate 5000 SCI 24 CAS/ OU- OUE owner's manual

Panasonic

Panasonic CS-E12HKEW operating instructions

nedis

nedis ACMB1WT7 quick start guide

Samsung

Samsung AR KV Series User & installation manual

Daikin

Daikin FCFV50A Operation manual

Fujitsu

Fujitsu Inverter ASBA30JFC operating manual

Toshiba

Toshiba RAS-M10SMUV-E installation manual

Daikin

Daikin FXLQ20MAVE Operation manual

Hitachi

Hitachi RAS-E24CAK instruction manual

CIAT

CIAT Magister 2 Series Installation, Operation, Commissioning, Maintenance

Bestron

Bestron AAC6000 instruction manual

Hisense

Hisense 7K Use and Installation Instructions

Frigidaire

Frigidaire FFRE0533S1E0 Use & care guide

Samsung

Samsung AS09HM3N user manual

Frigidaire

Frigidaire CRA073PU11 use & care

Soleus Air

Soleus Air GB-PAC-08E4 operating instructions

McQuay

McQuay MCK020A Technical manual
