Sharp AF-Q100VX User manual

AF-Q100VX

AF-Q120VX

AF-Q100VX, AF-Q120VX)

15%

FOR YOUR PROTECTION............................... 2

CONSUMER LIMITED WARRANTY ................ 3

INSTALLATION INSTRUCTIONS

CHECK WINDOW AREA .............................. 4

LOCATION.................................................... 4

ACCESSORIES ............................................ 5

SUGGESTED TOOLS .................................. 5

INSTALLATION............................................. 6

PRECAUTIONS ................................................ 9

USING YOUR AIR CONDITIONER .................. 11

CLEANING AND MAINTENANCE ................... 16

BEFORE CALLING FOR SERVICE ................. 17

This INSTALLATION AND OPERATION MANUAL explains the proper use of your new Sharp Air Conditioner.

Read these instructions carefully before installing or operating your air conditioner. The INSTALLATION AND

OPERATION MANUAL should be kept in a safe place for handy reference.

AF-Q100VX, AF-Q120VX Room Air Conditioner. Be sure to have this

68

must be 15 1/2" (394mm)

25 1/4" (641mm)

Right

accordion

panel

Foam top

window gasket

Window

sash seal

Left

accordion

panel

Type A (6) Window locking Frame locking

bracket (1)

bracket (1)

Remote Control

Use protective material to prevent damage to

the surface.

Install the accordion panels on each side.

A. Locate the accordion panels in the box.

B. Gently pull the free end of the accordion

panel (See FIG. 1). Do this for both panels.

C. Slide the free end of the accordion panel

into the slot on the the side panel of the air

conditioner (See FIG. 1). Do this for each

side. The accordian panel labeled “LEFT”

goes on the left side of the air conditioner

as you are facing the control panel. The

accordion panel labeled “RIGHT” is should

be installed on the right side.

D. Once the accordion panels are slid into place, make sure you leave enough space to slip

on the top and bottom rails. Now, slide the top and bottom of the side panels inside top

and bottom rails. Adjust the panels until they fit securely inside the rails.

upper guide rail

lower guide rails

flexible screen

FIG. 1

3

Keeping a firm grip on the air conditioner carefully place the unit into the window open-

ing so the bottom of the air conditioner frame is against the window sill. Carefully close

the window behind the top rail of the unit.

Extend the side panels out against the window frame.

Front Side

Horizontal or inclined about 3° Upper guide rail

Lower guide rail

Window frame

6

Use 5 Type A screws to secure the frame of the flexible screen to the window frame

and sash.

Window frame

windowsill

7

To secure the sash in place, attaché the

right angle window lock with a Type B

screw as shown.

8

Cut Foam Seal to same width as window.

Insert foam strip in the space between the

upper and lower sashes.

Plastic window

Wooden window

Sealing strip

( without adhesive)
