Schlage M400 Series User manual

*44487312*

44487312

1 Place template and prepare holes.

Single

a. Place template on top corner, opposite of hinges.

b. Mark holes and prepare them per template.

Shown from Interior

Template

Double

a. Place template on top centerline of doors.

b. Mark holes and prepare them per template.

Shown from Interior

Template

2 Reorient the magnet(s)

• SINGLE LOCKS: The magnet may need to be reoriented before installation, depending on the handing of your door.

• DOUBLE LOCKS: The magnet in one of the locks must be reoriented before installation.

• See the instructions that came with your lock(s) for information about magnet orientation.

Electromagnetic Locks for Inswinging Doors

M420TJ, M422TJ, M450TJ, M452TJ, M490TJ, M492TJ

M400 Series TJ Locks

Installation Instructions

LThese instructions cover only the mounting of the lock(s) using TJ brackets. Before proceeding with installation, see main

electromagnetic lock instructions for the following information:

• Electrical Specications

• Reorienting the Magnet

• ATS and MBS Indicator Installation

• Connecting Wiring to Board

3 Attach frame L-Bracket.

Single

Inside

Double

Inside

Actual Size

Reinforced Metal Sheet Metal

4 Attach mounting bracket(s).

a. Place template on gate and post surfaces as marked on template.

b. Mark holes and prepare them per template.

Single Double

Actual Size

5 Double lock ONLY: Install join block.

5a Remove wiring covers and end blocks. 5b Install join block.

6 Install magnet(s).

6a SINGLE AND DOUBLE LOCKS: Slide magnet onto bracket.

Inside

6b DOUBLE LOCK ONLY: Slide second magnet onto bracket.

Join block slides into ﬁrst magnet housing.

7 Secure magnet(s).

7a Single lock. 7b Double lock

Actual Size

Printed in U.S.A.

44487312 Rev. 11/15-d

Customer Service

1-877-671-7011 www.allegion.com/us

8 Assemble armature

8a Attach armature to top L-Bracket.

Armature

Holder

Actual Size

Top

L-Bracket

8b Attach armature plate to armature holder.

WARNING

Use bolt from TJ kit.

M490 armature must be disassembled to replace armature bolt.

Flat Washer

Star Locking Washer

Cone Washer

Armature Bolt

Actual Size

Armature

Plate

Top

L-Bracket

8c Attach bottom L-Bracket to door.

WARNING

The included sex nut is for 1C\v” (45 mm) doors ONLY. For other door

thicknesses, please contact customer service, 1-877-671-7011. Using

the incorrect sex nut for your door thickness will lead to improper

function and possible injury.

Armature bolt must be tightened to at least 120 in.-lbs. for all doors

except composite wood doors. For composite wood doors, tighten only

to tight and ush. 120 in.-lbs. may damage composite wood doors.

DO NOT back off bolt after tightening! Backing off the bolt after

tightening will loosen the thread-locking patch, which may allow the bolt

to loosen over time.

LUse bolt that came with lock.

Inside

Actual Size

9 Attach and adjust armature.

9a Attach armature assembly to bottom L-Bracket

Actual Size

9b Adjust armature

a. Close door.

b. Press armature to fully engage with magnet.

c. Fully tighten two screws and set screw to lock position.

d. If double, repeat adjustment process on second door.

Press armature

to magnet

Two (2)

screws

Inside
