Step 1.

Unpacking

Remove the printer an all of the accessories from the

packing carton. Make sure that the printer has been packe

with the following items:

OTES

• If any items are missing or amage , notify your ealer

imme iately.

• Components may iffer from one country to another.

• The CD-ROM contains the printer river, the User’s Gui e, an

the A obe Acrobat Rea er program.

• The power cor may be ifferent epen ing on your country.

AUTION

This printer weighs 35kg inclu ing eveloper cartri ge

an cassette. Use safe lifting an han ling techniques. If you nee

to move the printer it must be move by two people. Use the

lifting han les locate as shown in the iagram (see page 5). Back

injury coul be cause if a single person attempts to lift the

printer.

Toner Cartri ges Power Cor Transfer Belt

Imaging Unit CD-ROM Setup Gui e

SyncThru CD-ROM

(CLP-550N only)

SyncThru Quick Gui e

(CLP-550N only)

ETUP

UIDE

Carefully remove all of the packing tapes from the printer.

Pull the paper tray out of the printer an remove the

packing tapes from the tray.

Select a location for the printer:

•Leave enough room to open the printer trays, covers, an

allow for proper ventilation.

•Provi e the proper environment:

– A firm, level surface

– Away from irect airflow of air con itioners, heaters, or

ventilators

– Free of temperature, sunlight, or humi ity extremes or

fluctuations

– Clean, ry, an free of ust

AUTION

You must place your printer in the level surface. If you

o not, the print quality problems can occur.

ETUP

UIDE

English

Step 2.

Understanding Your Printer

These are the main components of your printer:

Output Support

Control Panel

(refer to Chapter

5 in the User’s

Gui e which is

on the CD-

ROM.)

Paper Output Tray

Top Cover

(Open to install the imaging unit,

an transfer belt.)

Front Cover

(Open to replace

the waste toner

container.)

Left Cover

(To install the toner cartri ges

press the top cover release

button an open fully.)

Tray 1

(250-sheet paper fee er)

Top Cover

Release Button

Optional Tray 2

(500-sheet paper fee er)

Handle

(Lifting han les are

locate at the lower

e ge of both si es

of the printer.)

ETUP

UIDE

Optional Tray 2 Jam Cover

(Open to remove jams in the optional tray 2.)

Muti-purpose Tray

(Open to loa special print materials.)

Right Cover

(Open to remove paper jams.)

Power Switch

USB Port

Power Receptacle

Control Board

Cover

(Open to install optional

accessories.)

Wireless Network

Antenna

Network Port

Parallel Port

* This wireless network antenna is not supplied with the printer. It is an option that must be purchased

and installed separately.

** The network port is fitted as standard on the CLP-550 . CLP-550 users can purchase an optional

etwork Card and install it separately. For details, see the User's Guide of the printer in the CD-ROM.

Handle

(Use it to lift the printer.)

ETUP

UIDE

English

Step 3.

Installing the Imaging Unit Transfer

Belt and Toner Cartridges

Using the han le, completely open the left cover until it is at

right angles to the main frame.

AUTION

If the left cover is not completely open, the top cover

release button oes not be presse .

Press the top cover release button to unlatch the top cover

an open it all the way.

Top cover release

button

ETUP

UIDE

Take the imaging unit out of the package using the han le.

Remove the paper covering on the imaging unit by

removing the tape un er the han le of the imaging unit.

AUTIONS

• Do not use sharp objects, such as a knife or scissors, to open the

imaging unit package an tape on the protective paper liner. You

coul amage the surface of the imaging unit.

• To prevent amage, o not expose the imaging unit to light for

more than a few minutes. Cover it with black paper, if necessary.

• Do not touch the surface of the green roller on the imaging unit

or print quality problems can occur.

Locate the imaging unit slots insi e the printer, one on each

si e.

ETUP

UIDE

English

Hol the han le on the imaging unit with the green roller

facing you. Align the imaging unit with the slots in your

printer so that the colors on both si es of the imaging unit

sli e into the correspon ing colors of the slots.

CAUTION

Insert the imaging unit carefully so as not to scratch

an amage the surface of the green roller.

Sli e the imaging unit own into the printer until it cannot

be pushe in any further an fol the han le own.

CAUTION

To prevent amage, o not expose the imaging unit to

light for more than a few minutes. Close the top an left cover

shoul the setup nee to be halte for any reason.

ETUP

UIDE

Take the transfer belt out of the package.

Remove the paper covering on the transfer belt by

removing the tape.

CAUTION

Don’t use sharp objects, such as a knife or scissors, to

open the transfer belt package. You coul amage the surface of

the transfer belt.

Pinch the transfer belt tention levers on both si es of the

transfer belt. Then, pull them out, as shown below.

Locate the transfer belt slots insi e the printer, one on each

si e.
