Samsung DV665J Series User manual
Electric Dryer
user manual
imagine the possibilities
Thank you for purchasing this Samsung product.
To receive more complete service,
please register your product at
www.samsung.com/global/register
DV665J
DV665JW-02369E_EN.indd 1 2007-05-15 ø¿»ƒ 3:05:42
2_ Features
features
1. Delay Start
You can delay the dryer’s start-up time for up to 24 hours. The Delay Start feature will allow
you to dry your clothes at a time that is convenient for you.
2. Freshen-up Program
Samsung’s Freshen-up program tumble-dries garments in cool air set at a time of your
choice, for up to 50 minutes. This program makes it easy to freshen-up clothes that only
require a little airing out.
3. Sensor Dry & Fuzzy Logic Control
Both technologies bring you outstanding economic benefits as well as excellent drying
performance. The Fuzzy Logic Control determines the dryness and gentleness needed
for your laundry and sets the appropriate drying time/cycle. The Sensor dry function
continuously measures the temperature in the inner section of the dryer to provide excellent
drying performance.
4. Various Drying Cycles & Fuzzy Logic Algorithm
Simply turn the Jog Dial to select one of the 11 automatic drying cycles, including normal,
heavy duty and towels. You can also choose to use the Fuzzy Logic Algorithm to measure
the degree of dampness and automatically set the drying time. Precision drying has never
been easier than with Samsung.
5. Wrinkle-Release
Our Wrinkle-Release program tumble dries garments in warm air for 10 minutes, then cool
air for an additional 10 minutes. You can use the Wrinkle-Release program to smooth the
wrinkles of garments that have been stored away.
6. Stacking
Samsung Washers and Dryers can be stacked to maximize usable space, using an optional
Stacking Kit.
DV665JW-02369E_EN.indd 2 2007-05-15 ø¿»ƒ 3:05:43
Safety instructions _3
safety instructions
Congratulations on the purchase of your new Samsung Dryer. This manual
contains valuable information on the installation, use, and care of your appliance.
Please take the time to read this manual to take full advantage of your dryer’s
many benefits and features.
WHAT YOU NEED TO KNOW ABOUT SAFETY INSTRUCTIONS
Warnings and Important Safety Instructions in this manual do not cover all possible conditions and
situations that may occur. It is your responsibility to use common sense, caution, and care when installing,
maintaining, or operating your dryer.
Always contact your manufacturer about problems or conditions you do not understand.
IMPORTANT SAFETY SYMBOLS AND PRECAUTIONS
WARNING
Hazards or unsafe practices that may result in severe personal injury or
death.
CAUTION
Hazards or unsafe practices that may result in minor personal injury or
property damage.
CAUTION
Follow the information in this manual to minimize the risk of fire or explosion or
to prevent property damage, personal injury, or death.
Do not store or use gasoline or other flammable vapors and liquids near this or
any other appliance.
Do NOT attempt.
Do NOT disassemble.
Do NOT touch.
Follow directions explicity.
Unplug the power plug from the wall socket.
Make sure the machine is grounded to prevent electric shock.
Call the service center for help.
DV665JW-02369E_EN.indd 3 2007-05-15 ø¿»ƒ 3:05:43
4_ Safety instructions
Read all instructions before using the appliance.
To reduce the risk of fire or explosion:
• Do not dry items that have been previously cleaned, washed, soaked, or spotted with
gasoline, dry cleaning solvents, or other flammable or explosive substances. They
emit vapors that could ignite or explode. Any material that has been in contact with a
cleaning solvent or flammable liquids or solids should not be placed in the dryer until all
traces of these flammable liquids or solids and their fumes have been removed.
There are many highly flammable items used in homes, such as acetone, denatured
alcohol, gasoline, kerosene, some liquid household cleaners, some spot removers,
turpentine, waxes, and wax removers
• Items containing foam rubber (may be labeled latex foam) or similarly textured rubber-
like materials must not be dried on a heat setting. Heated foam rubber materials can,
under certain circumstances, produce fire by spontaneous combustion.
Do not allow children or pets to play on, in, or in front of the appliance. Close supervision is
necessary when the appliance is used near children and pets.
Before discarding or removing your dryer from service, remove the door to the drying
compartment to prevent children or animals from becoming trapped inside.
Do not reach into the appliance when the drum is moving.
Do not install or store this appliance where it will be exposed to the weather.
Do not tamper with controls.
Do not repair, replace, or attempt to service any part of the appliance unless specifically
recommended in the user-repair instructions. You must also have the skills necessary to
service this appliance.
Do not use fabric softeners or products to eliminate static unless recommended for dryer
use by the manufacturer of the fabric softener or product.
Clean the lint screen before or after each load.
Keep the area around the exhaust opening and surrounding areas free from lint, dust, and
dirt.
The interior of the dryer and exhaust duct should be cleaned periodically by qualified service
personnel.
This appliance must be properly grounded. Never plug the power cord into a receptacle
that is not grounded adequately and in accordance with local and national codes. See
installation instructions for grounding this appliance.
Do not sit on top of the dryer.
Because of continuing product improvements, Samsung reserves the right to change
specifications without notice. For complete details, see the Installation Instructions
packed with your product before selecting cabinetry, making cutouts, or beginning
installation.
Ensure pockets are free from small irregularly shaped hard objects, foreign material, etc. ie.
coins, knives, pins, etc. These objects could damage your dryer.
Do not wash clothing with large buckles, buttons, or other heavy metal or solid things.
safety instructions
WARNING
WARNING
DV665JW-02369E_EN.indd 4 2007-05-15 ø¿»ƒ 3:05:43
Safety instructions _5
Install and use in accordance with the manufacturer’s instructions.
Do not place items in your dryer that have been spotted or soaked with vegetable oil or
cooking oil. Even after being washed, these items may contain significant amounts of these
oils.
The residual oil can ignite spontaneously. The potential for spontaneous combustion
increases when the items containing vegetable oil or cooking oil are exposed to heat. Heat
sources such as your dryer can warm these items, allowing an oxidation reaction in the
oil to occur. Oxidation creates heat. If this heat cannot escape, the items can become hot
enough to catch fire. Piling, stacking, or storing these kinds of items may prevent heat from
escaping and can create a fire hazard.
All washed and unwashed fabrics that contain vegetable oil or cooking oil can be
dangerous. Washing these items in hot water with extra detergent will reduce, but not
eliminate, the hazard. Always use the Cool Down cycle for these items to reduce their
temperature. Never remove these items from the dryer hot or interrupt the drying cycle until
the items have run through the Cool Down cycle. Never pile or stack these items when they
are hot.
DV665JW-02369E_EN.indd 5 2007-05-15 ø¿»ƒ 3:05:43
6_ Contents
contents
INSTALLING YOUR DRYER
7
7 Tools needed for installation
7 See Exhaust Requirements
8 Ducting requirements
8 Exhaust length calculation
9 Exhaust directions
9 Exhaust duct locating dimensions
9 Important to installer
10 Location considerations
10 Alcove or closet installation
10 Exhausting
11 Electrical requirements
11 Grounding
12 Electrical connections
12 Replacement parts and accessories
13 Installation
14 Final installation checklist
15 Dryer Exhaust Tips
16 Door Reversal
OPERATING INSTRUCTIONS, TIPS
17
17 Overview of the control panel
18 How To Operate Your Dryer
18
Polyester Knits & Permanent Press Drying Tips
18 Loading Clothes
18 Drying Times
19 Cycle selecting guide
19 Cycle Chart
20 Clean the lint filter
20 Load the dryer properly
20 Getting started
CARE AND CLEANING
21
21 Clean Filter
21 Control Panel
21 Stainless Steel Tumbler
21 Dryer Exterior
21 Dryer Exhaust
21 Inside the dryer cabinet
TROUBLESHOOTING
22
22 Questions? Use this problem solver
22 Information Codes
APPENDIX
23
23 Fabric Care Chart
24 Protecting The Environment
24 Specifications
DV665JW-02369E_EN.indd 6 2007-05-15 ø¿»ƒ 3:05:43
Installing your dryer _7
installing your dryer
TOOLS NEEDED FOR INSTALLATION
Hire a professional to install this dryer properly. If there is a service call performed as a result of poor setup,
adjustment, and connection, it is considered the responsibility of the installer. If you install the dryer you are
responsible.
Make sure you have everything necessary for proper installation.
1. A GROUNDED ELECTRICAL OUTLET is required. See Electrical Requirements on page 11.
2. A POWER CORD for electric dryers (except Canada).
3. EXHAUST SYSTEM – must be rigid metal or flexible stiff-walled metal exhaust ducting. See exhaust
requirements on page 8.
SEE EXHAUST REQUIREMENTS
Pliers Cutting knife Nut drivers
Level Phillips Screwdriver Duct tape Crescent spanner
01 Installing your dryer
Control panel
Door
DV665JW-02369E_EN.indd 7 2007-05-15 ø¿»ƒ 3:05:43
8_ Installing your dryer
DUCTING REQUIREMENTS
• Use a 4-inch (10.2 cm) diameter rigid aluminum or rigid galvanized steel duct.
• Do not use a smaller duct.
• Ducts larger than 4 inches (10.2 cm) in diameter can result in increased lint accumulation.
Lint accumulation should be cleaned regularly.
• If a flexible metal duct must be used, use the type with a stiff sheet metal wall. Do not use a flexible duct
with a thin foil wall. Serious blockage can result if the flexible metal duct is bent too sharply.
• Never install any type of flexible duct in walls, ceilings, or other concealed spaces.
• Keep the exhaust duct as straight and short as possible.
• Secure joints with duct tape. Do not use screws.
• DO NOT EXHAUST DRYER INTO ANY WALL, CEILING, CRAWL SPACE, OR CONCEALED SPACE OF
A BUILDING, GAS VENT, OR ANY OTHER COMMON DUCT OR CHIMNEY.
THIS COULD CREATE A FIRE HAZARD FROM LINT EXPELLED BY THE DRYER.
•
Plastic flexible duct can kink, sag, be punctured, reduce airflow, extend drying times, and affect dryer operation.
• Exhaust systems longer than recommended can extend drying times, affect machine operation, and
may collect lint.
• The exhaust duct should end with an exhaust hood with a swing-out damper to prevent back drafts and
entry of wildlife. Never use an exhaust hood with a magnetic damper.
• The hood should have at least 12 inches (30.5 cm) of clearance between the bottom of the hood and
the ground or other obstruction. The hood opening should point down.
• Never install a screen over the exhaust outlet.
•
To avoid lint buildup, do not exhaust the dryer directly into a window well. Do not exhaust under a house or porch.
• If exhaust ductwork must run through an unheated area, the duct should be insulated and slope slightly
down towards the exhaust hood to reduce condensation and lint buildup.
•
Inspect and clean the interior of the exhaust system at least once a year. Unplug the power cord before cleaning.
• Check frequently to be sure the exhaust hood damper opens and closes freely.
• Check once per month, and clean at least one time per year. Note: If clothes are not getting dry, then
check ducting for obstructions.
EXHAUST LENGTH CALCULATION
Table 1: RECOMMENDED MAXIMUM LENGTH
ELECTRIC DRYERS
Weather Hood Type
Recommended Use only for short run installations
4” (10 .16 cm) 21/2” (6.35 cm)
No. of 90° elbows Rigid Metallic Flexible* Rigid Metallic Flexible*
0 14 m (46 ft.) 9 m (30 ft.) 11 m (37 ft.) 7 m (24 ft.)
1 11 m (38 ft.) 7.5 m (25 ft.) 9 m (30 ft.) 6 m (20 ft.)
2 9 m (31 ft.) 6 m (20 ft.) 6.5 m (22 ft.) 4 m (14 ft.)
3 7 m (24 ft.) 5 m (16 ft.) 4.5 m (15 ft.) 3 m (10 ft.)
* Do not use non-metallic flexible duct.
installing your dryer
DV665JW-02369E_EN.indd 8 2007-05-15 ø¿»ƒ 3:05:45
Installing your dryer _9
If the new dryer is installed into an existing exhaust system you must make sure:
• The exhaust system meets all local, state, and national codes.
• That a flexible plastic duct is not used.
• To Inspect and clean all lint buildup from inside the existing duct.
• The duct is not kinked or crushed.
• The exhaust hood damper opens and closes freely.
The static pressure in any exhaust system must not exceed 0.83 inches of water column, or
be less than 0. This can be measured with the dryer running with a manometer at the point
where the exhaust duct connects to the dryer. A no-heat setting should be used. The dryer
tumbler should be empty and the lint filter clean.
EXHAUST DIRECTIONS
All dryers shipped from the factory are set up for rear exhausting. However
exhausting can be on the right, left or bottom of the dryer.
• Remove the access panel at back of dryer to gain access to the internal ducts.
• Disconnect the duct exhaust from the blower housing.
• Remove the desired knockout plate (either right or left side).
• Attach a 90° elbow duct to the blower housing and facing desired opening.
• Reinstall the rear access panel.
EXHAUST DUCT LOCATING DIMENSIONS
Non-metallic ducts must never be used inside the dryer cabinet.
SPECIAL ACCESSORY
Stacking kit (Model no:SK-2A)
You can obtain the stacking kit from your retailer. With this kit
you can combine your Samsung dryer with a Samsung washing
machine in a washing and drying column. The appliances are
stacked in a space-economizing manner in this arrangement, the
washing machine on the bottom and the dryer on the top!
IMPORTANT TO INSTALLER
Please read the following instructions carefully before installing the dryer. These instructions should be kept
for future reference.
REMOVE THE DOOR FROM ALL DISCARDED APPLIANCES TO AVOID THE DANGER OF A CHILD
SUFFOCATING.
01 Installing your dryer
WARNING
WARNING
Front of dryer
Same as
other side
3-3/4”(9.5cm)
13-1/2”(34cm)
3-3/4”(9.5cm)
4-3/8”(11cm)
5-7/8”(15cm)
Duct Exhaust
Blower Housing
DV665JW-02369E_EN.indd 9 2007-05-15 ø¿»ƒ 3:05:45
10_ Installing your dryer
installing your dryer
LOCATION CONSIDERATIONS
The dryer should be located where there is enough space in front for loading the dryer, and enough space
behind for the exhaust system. This dryer is factory-ready for rear exhaust. To exhaust out the bottom or
the left, inquire at the installer. It’s important to make sure the room has enough fresh air. The dryer must be
located where there is no air-flow obstruction.
THE DRYER MUST NOT BE INSTALLED OR STORED IN AN AREA WHERE IT WILL BE EXPOSED TO
WATER AND/OR WEATHER. THE DRYER AREA IS TO BE KEPT CLEAR OF COMBUSTIBLE MATERIALS,
GASOLINE, AND OTHER FLAMMABLE VAPORS AND LIQUIDS. A DRYER PRODUCES COMBUSTIBLE
LINT. THE AREA AROUND THE DRYER SHOULD BE KEPT LINT-FREE.
ALCOVE OR CLOSET INSTALLATION
The dryer must be exhausted to the outside to reduce the risk of fire when installed in an alcove or
closet.
• No other fuel-burning appliance should be installed in the same closet as the dryer.
• WARNING: To reduce the risk of fire, this dryer MUST BE EXHAUSTED TO THE OUTDOORS.
See EXHAUST INFORMATION section.
• Minimum clearances between the dryer and adjacent walls or other surfaces are:
2” in front, 17” on top, 1” on either side, and 2.375” in the back.
• The closet front must have two unobstructed air openings for a combined minimum total area of 72 in²
with 3” minimum clearance on the top and bottom. A louvered door with equivalent space clearance is
acceptable.
EXHAUSTING
Exhausting the dryer to the outside will prevent large amounts of lint and moisture from being blown into the
room.
In the United States:
• All dryers must be exhausted to the outside.
• Only a rigid or flexible metal duct should be used for exhausting.
In Canada:
• All dryers must be exhausted to the outside.
The dryer must be exhausted to the outside to reduce the risk of fire when installed in an
alcove or closet.
NEVER USE A PLASTIC OR NON-METAL FLEXIBLE DUCT.
If your existing ductwork is plastic, non-metal, or combustible, replace it with metal.
Use only a metal exhaust duct that is non-flammable to ensure containment of exhaust air,
heat, and lint.
WARNING
WARNING
DV665JW-02369E_EN.indd 10 2007-05-15 ø¿»ƒ 3:05:46
Other manuals for DV665J Series
2
This manual suits for next models
1
Table of contents
Languages:
Other Samsung Dryer manuals
Samsung
Samsung DV50F9A7GVP Owner's manual
Samsung
Samsung DV448AEP User manual
Samsung
Samsung DV422 Series User manual
Samsung
Samsung DV455EVGSWR/AA User manual
Samsung
Samsung DV338AEW User manual
Samsung
Samsung DV419AEU/XAA User manual
Samsung
Samsung DVG54M8750V/A3 User manual
Samsung
Samsung DVE50M7450W/A3 User manual
Samsung
Samsung DV316LGW/XAA User manual
Samsung
Samsung DVE55A7700 Series User manual
Samsung
Samsung DV56H9100EV/A2 User manual
Samsung
Samsung SDC18809 User manual
Samsung
Samsung FlexDry DVG55M9600V/A3-00 User manual
Samsung
Samsung DVE47CG3500 Series User manual
Samsung
Samsung DVE50M7450P User manual
Samsung
Samsung DV50K8600E User manual
Samsung
Samsung DV45K7100E(G) series User manual
Samsung
Samsung DV435ETGJWR/A1 User manual
Samsung
Samsung DVG53BB8700 Series User manual
Samsung
Samsung DVG50M7450 Series User manual
Popular Dryer manuals by other brands
Bosch
Bosch WTA79200GB Installation and operating instructions
Amana
Amana W10233410A Use and care guide
Miele
Miele TWH 780 WP operating instructions
Asko
Asko T760 user guide
Alliance Laundry Systems
Alliance Laundry Systems 25 Series Original instructions
Bosch
Bosch Logixx 10 WTB76556GB Instruction manual and installation instructions
Indesit
Indesit IDV 75 instruction manual
Infiniton
Infiniton SD-DG85C manual
BOMANN
BOMANN WT 5019 instruction manual
Alliance Laundry Systems
Alliance Laundry Systems TMB795C Installation
Asko
Asko T793C operating instructions
Kenmore
Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer installation instructions
