Samsung FH052EAMT User manual

ENGLISH

INSTALLATION MANUAL

MANUAL DE INSTALACIÓN

MANUEL D’INSTALLATION

MANUALE D’INSTALLZIONE

MANUAL DE INSTALAÇÃO

INSTALLATIONS-HANDBUCH

E°XEIPI¢IO E°KATA™TA™H™

àçëíêìäñàü èé ìëíÄçéÇäÖ

System Air Conditioner (Cool and Heat)

Aire acondicionado sistemático (Refrigeración y Calefacción)

Climatiseur numérique multifonctionnel (Refroidissement et Chauffage)

Sistema Aria Condizionata (Raffreddamento e Riscaldamento)

Sistema Ar Condicionado (Refrigeração e Aquecimento)

Klimaanlage System (Kühlen und Wärmen)

™‡ÛÙËÌ· ∫ÏÈÌ·ÙÈÛÌÔ‡

(æ‡ÍË˜ Î·È £¤ÚÌ·ÓÛË˜)

ëËÒÚÂÏÌ˚ ÇÓÁ‰Û¯Ì˚ äÓÌ‰ËˆËÓÌÂ

(éıÎ‡Ê‰ÂÌËÂ Ë Ó·Ó„Â‚)

ESPAÑOL

FRANÇAIS

ITALIANO

PORTUGUÊS

DEUTSCH

E S F I P D G R DB98-14419A(2)

FH052EAMT

FH070EAMT

RUSSIAN E§§HNIKA

■ Parts list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

OOPP

PPTT

TTII

IIOO

OONN

NNAA

AALL

LLAA

AACC

CCCC

CCEE

EESS

SSSS

SSOO

OORR

RRII

IIEE

EESS

Chapter

Contents

E-2

■ Preparation for Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

■ Deciding on where to Install the indoor unit . . . . . . . . . . . . . . . . . . 5

■ Ceiling installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

■ Floor installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

■ Purging the unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

■ Connecting the refrigerant pipe . . . . . . . . . . . . . . . . . . . . . . . . . . 11

■ Cutting / Flaring the pipes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

■ Performing leak test & insulation . . . . . . . . . . . . . . . . . . . . . . . . . 13

■ Drain hose installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

■ Connecting the connection cord . . . . . . . . . . . . . . . . . . . . . . . . . . 15

■ Assigning address to indoor unit . . . . . . . . . . . . . . . . . . . . . . . . . 16

■ Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

CCEE

EEII

IILL

LLII

IINN

NNGG

GG//

//FF

FFLL

LLOO

OOOO

OORR

RRTT

TTYY

YYPP

PPEE

EEII

IINN

NNSS

SSTT

TTAA

AALL

LLLL

LLAA

AATT

TTII

IIOO

OONN

Chapter

■Preparation for installation . . . . . . . . . . . . . . . . . 4

■Deciding on where to install the indoor unit . . . 5

■Ceiling installation . . . . . . . . . . . . . . . . . . . . . . . 8

■Floor installation . . . . . . . . . . . . . . . . . . . . . . . . 9

■Purging the unit . . . . . . . . . . . . . . . . . . . . . . . . 10

■Connecting the refrigerant pipe . . . . . . . . . . . . 11

■Cutting / Flaring the pipes . . . . . . . . . . . . . . . . 12

■Performing leak test & insulation . . . . . . . . . . . 13

■Drain hose installation . . . . . . . . . . . . . . . . . . . 14

■Connecting the connection cord . . . . . . . . . . . 15

■Assigning address to indoor unit . . . . . . . . . . . 16

■Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . 18

CCEE

EEII

IILL

LLII

IINN

NNGG

GG//

//FF

FFLL

LLOO

OOOO

OORR

RRTT

TTYY

YYPP

PPEE

EEII

IINN

NNSS

SSTT

TTAA

AALL

LLLL

LLAA

AATT

TTII

IIOO

OONN

Chapter

E-3

ENGLISH

Preparation for installation

When deciding on the location of the air conditioner with the owner,

the following restrictions must be taken into account.

General

Do NOT install the air conditioner in a location where it will come into

contact with the following elements:

◆Combustible gases

◆Saline air

◆Machine oil

◆Sulphide gas

◆Special environmental conditions

If you must install the unit in such conditions, first consult your dealer.

E-4

Accessories

◆The following accessories are supplied with the indoor unit.

◆The type and quantities may differ depending on a specification.

M4 X 12 Tapped

Screw

Wireless Remote

Controller BatteryRemote Controller

Holder

Pattern sheet

Plate Hanger

Installation ManualOwner’s Instructions

Cable-Tie

OWNER'SINSTRUCTIONS

MANUALDEINSTRUCCIONES

ISTRUZIONIPERL'USO

MANUALDEINSTRUÇÕES

MANUELD'UTILISATION

GEBRAUCHSANWEISUNG

Splut-typeRoomAirConditioner

AireacondicionadodomésticosistemaSplit

Condizionatored'ariaperambientiadunitàSeparate

AparelhodearcondicionadotipoSplit

Climatiseurdetypeséparé

Geteilteraumklimaanlage

OWNER'SINSTRUCTIONS

MANUALDEINSTRUCCIONES

ISTRUZIONIPERL'USO

MANUALDEINSTRUÇÕES

MANUELD'UTILISATION

GEBRAUCHSANWEISUNG

Splut-typeRoomAirConditioner

AireacondicionadodomésticosistemaSplit

Condizionatored'ariaperambientiadunitàSeparate

AparelhodearcondicionadotipoSplit

Climatiseurdetypeséparé

Geteilteraumklimaanlage

Deciding on where to install the indoor unit

Indoor Unit

◆Select a convenient location that permits the air to reach every corner of the

area to be cooled.

◆Pre-plan for easy and short routing of the refrigerant tubing and wiring to the

outdoor unit.

◆There should be no flammable gas, alkaline, substances present in the air.

◆Avoid location where obstacles preventing good air circulation are present.

◆Noise prevention should be considered in determining the unit's location.

◆The structure, where the unit is to be installed should be strong enough to

support the weight of the unit.

◆Do not install the unit where it will be exposed to direct sunlight.

E-5

ENGLISH

Space Requirements for Indoor Unit

Ceiling installation

Floor installation

300mm

50mm

Deciding on where to install the indoor unit (cont.)

E-6

240

200

650

197

922

1000

Drawing of the indoor unit

Unit : mm

Back side

E-7

ENGLISH

Pipe outlet (bottom side)

Drain hose outlet

Wiring hole

Air intake hole (Ø50)

Ceiling installation

1000

922

197 240

650

1Select pipe directions.

When the directions are selected, drill 3-1/8'' (100mm, for pipe and cables)

and 1-3/4'' (40mm, for drain hose) diameter holes on the wall so that it

slants slightly downwards toward the outdoor for smooth water flow.

2Drill holes for anchor bolts according to the distance and mount them.

3Install the unit onto the ceiling. Be sure to arrange the drain hose so that it

is leveled lower than the drain hose connecting port of the indoor unit.

4If installing on dropped ceiling, install threaded rod onto anchor

bolt (expansion bolt) to long enough to suspend the unit right below the

dropped ceiling and the install the unit suspending on the threaded rod.

Ensure that the ceiling is strong enough to support the

weight of the indoor unit. Before hanging the unit, test

the strength of each attached suspension bolt.

IMPORTANT

◆Use the pattern sheet to select pipe directions.

NNoo

oott

ttee

◆Use the pattern sheet.

NNoo

oott

ttee

◆For proper drainage of condensate, give a 2°slant to the

side of the unit which will be connected with the drain

hose as shown in the figure.

NNoo

oott

ttee

300mm or more

Connection pipe

Back side

Connection pipe

Drain hose

300mm or more

Unit : mm

E-8

Floor installation

1Select pipe directions.

When the directions are selected, drill 3-1/8'' (100mm, for pipe and cables)

and 1-3/4'' (40mm, for drain hose) diameter holes on the wall so that it

slants slightly downwards toward the outdoor for smooth water flow.

2Install the hanging plate according to the distance and mount it.

3Install the unit and be sure to arrange the drain hose so that it is leveled

lower than the drain hose connecting port of the indoor unit.

1000

793

650 101

◆Use the pattern sheet to select pipe directions.

NNoo

oott

ttee

Drain hose

300mm

or more

300mm

or more

Back side

Unit : mm

E-9

ENGLISH

E-10

Purging the unit

On delivery, the indoor unit is loaded with an inert nitrogen gas.

All this gas must therefore be purged before connecting the assembly

piping. To purge the inert gas, proceed as follows.

Unscrew the caps at the end of each pipe.

Result: All inert gas escapes from the indoor unit.

◆To prevent dirt or foreign objects from getting into the pipes

during installation, do NOT remove the caps completely until

you are ready to connect the piping.

NNoo

oott

ttee
