Samsung MOK-100LA User manual

System Air conditioner

Installation manual

LAC KIT (LOW AMBIENT COOLING KIT) MOK-100LA

• Before installation, be sure to read Safety Information.

• When the product is used in other countries, we do not guarantee the quality of the product.

DB68-06398A-01_IM_ACC 옵션 저온냉방 Kit_AA_EN_.indd 1DB68-06398A-01_IM_ACC 옵션 저온냉방 Kit_AA_EN_.indd 1 2022-09-08 오후 1:53:012022-09-08 오후 1:53:01

Safety Information 3

Part Names and Components 6

Assy Control Kit 6

Components 6

Installing LAC KIT 7

Assembling the Assy Control Kit and Low Ambient Damper 7

Construction of outdoor unit and low ambient cooling kit 10

The fully assembly apperance 11

Installation Environment for Low Ambient Cooling Kit 19

How to Install the Low Ambient Cooling Kit Damper 20

Connecting the Low Ambient Cooling Kit to the Outdoor Unit 21

Configuring the options of the outdoor unit for installation of LAC KIT 23

Cautions for LAC KIT (Low ambient cooling kit) 24

Features of LAC KIT (Low ambient cooling kit) 25

Setting the address 25

Inspection after installation of LAC KIT 26

Checking the version of LAC KIT 27

Contents

DB68-06398A-01_IM_ACC 옵션 저온냉방 Kit_AA_EN_.indd 2DB68-06398A-01_IM_ACC 옵션 저온냉방 Kit_AA_EN_.indd 2 2022-09-08 오후 1:53:022022-09-08 오후 1:53:02

Safety Information

California Proposition 65 Warning (US)

WARNING: Cancer and Reproductive Harm -

www.P65Warnings.ca.gov.

WARNING

Before installation, maintenance, and cleaning, be sure to cut

off the power supply.

The installation shall be conducted by the dealer or qualified

personnel.

• If installed by a unqualified person, it may cause leaks,

electric shock, or fire.

Be sure to install the product by following the instructions in

this manual.

• If not installed properly, it may cause leaks, electric shock,

or fire.

The LAC KIT manufacturer does not assume any responsibility

for losses or damages caused by careless installation or

installation by a unqualified person.

For installation, be sure to use the provided parts and the

specified parts and tools.

• If the specified tools are not used, it may cause a fall of the

product, leaks, electric shock, or fire.

If the power cable is damaged, be sure to let the cable

replaced by the manufacturer, service engineer, or person

with equivalent qualification.

DB68-06398A-01_IM_ACC 옵션 저온냉방 Kit_AA_EN_.indd 3DB68-06398A-01_IM_ACC 옵션 저온냉방 Kit_AA_EN_.indd 3 2022-09-08 오후 1:53:022022-09-08 오후 1:53:02

The electrical work shall be conducted by the qualified

personnel after following Technical Standards for Electrical

Equipment, Extension Regulations, and Installation Manual.

Additionally, be sure to follow the electrical specifications.

• The voltage drop, lack of voltage supply, inadvertent power

work, and use of unspecified wires may cause electric shock

or fire.

When wiring the power connection between LAC KIT and

outdoor units, the lines must be fixed not to allow movement

of structures such as cover of electrical unit. In addition, be

sure to fix the cover of electrical unit onto the product.

• If the cover of electrical unit is not securely fixed, it may

cause heating of connectors, electric shock, or fire.

For wiring, be sure to use the specified lines and firmly fix

them not to allow any external force to the connectors.

• Insecure connection and fixing may cause heating or fire.

Be cautious not to exceed the power limit of LAC KIT or supply

power less than the minimum voltage.

• Damage or dysfunction of any electrical part may cause

product failure.

Be sure to use the power cable made of copper and use only

the rated parts.

Then check the wiring status.

• It may cause fire due to heating.

Safety Information

DB68-06398A-01_IM_ACC 옵션 저온냉방 Kit_AA_EN_.indd 4DB68-06398A-01_IM_ACC 옵션 저온냉방 Kit_AA_EN_.indd 4 2022-09-08 오후 1:53:022022-09-08 오후 1:53:02

CAUTION

Be sure to conduct ground work.

• The ground wire shall not contact the following: gas pipes,

water pipes, lightning rod, and telephone grounding wire.

• An incomplete grounding may cause electric shock.

Be sure to place the power and communication lines of LAC

KIT at least 1 m apart from other electronic devices and at

least 2 m apart from the lightning rod's down conductor.

• Note that noise may occur even in the distance over 1 m

depending on the radio interference status.

Do not install the product in the following places:

• The place is filled with mineral oil, scattering oil, or steam

(e.g. kitchen): Heated resin parts may cause fall of the

product or leaks.

• The place generates corrosive gases such as sulfur dioxide

(e.g. Room with vents): Corrosion of copper pipes and joints

may cause refrigerant leak.

• There is equipment that generates electromagnetic waves:

Abnormal operation may be resulted due to malfunction of

the controller.

• Flammable gases may leak, carbon fiber dust or flammable

gas is floating, and volatile matters such as thinner and

gasoline are used: Leak gas may reside in the main valve,

which may cause a fire.

• In the place, an indoor unit may be corroded. (e.g. shore,

spa, etc.)

• The place is directly affected by external factors

(temperature, humidity, dust, etc.).

ÚInstallation-related claims caused by non-compliance with

above requirements are on your own responsibility.

(Service cost must be paid by you.)

DB68-06398A-01_IM_ACC 옵션 저온냉방 Kit_AA_EN_.indd 5DB68-06398A-01_IM_ACC 옵션 저온냉방 Kit_AA_EN_.indd 5 2022-09-08 오후 1:53:022022-09-08 오후 1:53:02

Assy Control Kit

Part Names and Components

Components

Name Body Communication Cable Power Cable

Amount 1 1 1

Shape

Name Cable Tie Installation Manual Grounding Screw Connection Cable

Amount 5 1 1 2

Shape

01 MAIN PBA

02 SMPS PBA

03 TERMINAL BLOCK

DB68-06398A-01_IM_ACC 옵션 저온냉방 Kit_AA_EN_.indd 6DB68-06398A-01_IM_ACC 옵션 저온냉방 Kit_AA_EN_.indd 6 2022-09-08 오후 1:53:022022-09-08 오후 1:53:02

Installing LAC KIT

Assembling the Assy Control Kit and Low Ambient Damper

1. Connect the actuator to TRANS.

– Place the actuator and TRANS on the Assy controller kit as shown in the figure and then

fix them on the plate with bolts, nuts, and screws.

Note

• Assemble them with the same alignment and rotation for the actuator as the figure below.

If its alignment and rotation are not correct, it may cause malfunction.

Note

• The direction of the actuator can be changed as follows:

ÚBefore installation on field, it must be assembled.

DB68-06398A-01_IM_ACC 옵션 저온냉방 Kit_AA_EN_.indd 7DB68-06398A-01_IM_ACC 옵션 저온냉방 Kit_AA_EN_.indd 7 2022-09-08 오후 1:53:032022-09-08 오후 1:53:03

2. Connect the actuator to TRANS.

1235

212 12 12 21

21 1 2 3

DAMPER

ACTUATOR SMPS PBA

CONTROL

PBA

TRANS

1(L) 212(N)

EXTERNAL

OUTPUT TEMP

SENSOR2

TEMP

SENSOR1

CN801

(RED)

CN805 CN804 CN806 CN803 CN802 CN301

(RED)

CN402

(WHT)

CON01

(WHT)

CON02

(WHT)

CN401

(WHT)

CN81

(RED)

CN83

(RED)

EXTERNAL

INPUT

Connect it after

removing the

wire coating.

Connect it after

removing the

wire coating.

Connect it after

removing the

wire coating.

with the

OPEN finish

with the

OPEN finish

Installing LAC KIT

DB68-06398A-01_IM_ACC 옵션 저온냉방 Kit_AA_EN_.indd 8DB68-06398A-01_IM_ACC 옵션 저온냉방 Kit_AA_EN_.indd 8 2022-09-08 오후 1:53:032022-09-08 오후 1:53:03

Assemble the control box and the control kit.

• The control kit must be taken into the

control box. (Check the fitting holes.)

• The UL certification must be acquired.

• When the louver actuator shaft enters into

the box, prevent water penetration. (Use a

bushing and such.)

• When assembling the control kit, use the

boss with12 mm or above in size.

(The heat transfer distance between the

control kit and control box must be 12 mm

or above.)

SCREW X 4 EA

10 3/8

95/8

113/16

75/8

31/2

813/16

4. Assemble the damper and Assy control box.

LOUVER

SHAFT

NUT

FULL OPEN

Louver

Damper

WARNING

• When assembling the damper and Assy control box, be sure to fix the shaft and actuator (Nut x2)

in the louver in fully open state.

DB68-06398A-01_IM_ACC 옵션 저온냉방 Kit_AA_EN_.indd 9DB68-06398A-01_IM_ACC 옵션 저온냉방 Kit_AA_EN_.indd 9 2022-09-08 오후 1:53:032022-09-08 오후 1:53:03

Construction of outdoor unit and low ambient cooling kit

Components of Low Ambient Cooling Kit for the Outdoor Unit

Model Number Position Type

LACH-SL Low Ambient Cooling Hood - Small (chassis) Left

LACH-SR Low Ambient Cooling Hood - Small (chassis) Right

LACH-R1 Low Ambient Cooling Hood - Rear 1 (Small chassis)

LACH-R2 Low Ambient Cooling Hood - Rear 2 (Large A type chassis)

LACH-SLR Low Ambient Cooling Hood - Left/Right (Large B type chassis)

LACH-R3 Low Ambient Cooling Hood - Rear 3 (Large B type chassis)

LACH-F1 Low Ambient Cooling Hood - Front 1 (Large A type chassis)

LACKD-1

(= LACH-1)

Low Ambient Cooling Kit Damper-1(Small chassis)

(Low Ambient Cooling Hood-1 (Small chassis))

LACKD-2

(= LACH-2)

Low Ambient Cooling Kit Damper-2 (Large A,B type chassis)

(Low Ambient Cooling Hood-2 (Large A,B type chassis)

LACH-SL-B

Low Ambient Cooling Hood - Left(S2 Small, S2 Large, S2 X-Large Chassis)

LACH-SR-B

Low Ambient Cooling Hood - Right(S2 Small, S2 Large, S2 X-Large Chassis)

LACH-R1-B Low Ambient Cooling Hood - Rear 1 (S2 Small Chassis, S2 X-Large Chassis)

LACH-R2-B Low Ambient Cooling Hood - Rear 2 (S2 Large Chassis)

LACH-F1-B Low Ambient Cooling Hood - Front 1 (S2 Large Chassis)

LACH-1-B Low Ambient Cooling Kit Damper - 1 (S2 Small Chassis)

(Low Ambient Cooling Hood - 1 S2 Small Chassis)

LACH-2-B Low Ambient Cooling Kit Damper - 2 (S2 Large Chassis)

(Low Ambient Cooling Hood - 2 (S2 Large Chassis)

LACH-3-B Low Ambient Cooling Kit Damper - 3 (S2 X-Large Chassis)

(Low Ambient Cooling Hood - 3 (S2 X-Large Chassis)

Required Model Number

per chassis

Model Number

Left Right Back Front Top

DVM S Small chassis LACH-SL LACH-SR LACH-R1 -LACKD-1

(= LACH-1)

DVM Large A type chassis LACH-SL LACH-SR LACH-R2 -LACKD-2

(= LACH-2)

DVM Large B type chassis LACH-SLR LACH-SLR LACH-R3 LACH-F1 LACKD-2

(= LACH-2)

DVM S2 Small chassis

LACH-SL-B LACH-SR-B

LACH-R1-B -

LACH-1-B

DVM S2 Large chassis

LACH-SL-B LACH-SR-B

LACH-R2-B LACH-F1-B

LACH-2-B

DVM S2 X-Large chassis

LACH-SL-B LACH-SR-B

LACH-R1-B -

LACH-3-B

CAUTION

• When installing the components in the outdoor unit, be careful for screws not to touch the

heat exchanger pin.

Installing LAC KIT

DB68-06398A-01_IM_ACC 옵션 저온냉방 Kit_AA_EN_.indd 10DB68-06398A-01_IM_ACC 옵션 저온냉방 Kit_AA_EN_.indd 10 2022-09-08 오후 1:53:032022-09-08 오후 1:53:03

Table of contents

Other Samsung Air Conditioner manuals

Samsung

Samsung AS18WJWD User manual

Samsung

Samsung AR09HSFSJWKN Guide

Samsung

Samsung NS***HHXEH Guide

Samsung

Samsung MH026FKEA User manual

Samsung

Samsung AM***XMDCH Series User manual

Samsung

Samsung Duct Type Series User manual

Samsung

Samsung ACBN1DCH Series User manual

Samsung

Samsung MH026FNCA User manual

Samsung

Samsung AQT18PJG Series User manual

Samsung

Samsung AS07A5(A6)MA User manual

Samsung

Samsung PC4NUC N Series User manual

Samsung

Samsung AQ12SGGE User manual

Samsung

Samsung ND 4HXEA Series User manual

Samsung

Samsung AQ09A Series User manual

Samsung

Samsung AR Series User manual

Samsung

Samsung AR12JC3ESLW Guide

Samsung

Samsung RD VHXF Series User manual

Samsung

Samsung 1 way cassette type User manual

Samsung

Samsung AR TY5A Series User manual

Samsung

Samsung AM036JNCDCH User manual

Samsung

Samsung AC***MNADKH User manual

Samsung

Samsung AR KV Series Guide

Samsung

Samsung AC TNCDKC Series User manual

Samsung

Samsung AJ BNHDCH Series User manual

Popular Air Conditioner manuals by other brands

Spheros

Spheros CC 355 instructions

Bosch

Bosch Climate 5000 SCI 24 CAS/ OU- OUE owner's manual

Panasonic

Panasonic CS-E12HKEW operating instructions

nedis

nedis ACMB1WT7 quick start guide

Daikin

Daikin FCFV50A Operation manual

Fujitsu

Fujitsu Inverter ASBA30JFC operating manual

Toshiba

Toshiba RAS-M10SMUV-E installation manual

Daikin

Daikin FXLQ20MAVE Operation manual

Hitachi

Hitachi RAS-E24CAK instruction manual

CIAT

CIAT Magister 2 Series Installation, Operation, Commissioning, Maintenance

Bestron

Bestron AAC6000 instruction manual

Hisense

Hisense 7K Use and Installation Instructions

Frigidaire

Frigidaire FFRE0533S1E0 Use & care guide

Frigidaire

Frigidaire CRA073PU11 use & care

Soleus Air

Soleus Air GB-PAC-08E4 operating instructions

McQuay

McQuay MCK020A Technical manual

Webasto

Webasto Frigo Top 25 DS Instructions for use

Frigidaire

Frigidaire FAZ12ES2A installation instructions
