Samsung AVMDSH022EA User manual

ENGLISHESPAÑOLFRANÇAISITALIANODEUTSCH

System Air Conditioner

(Cooling and Heating)

Aire acondicionado sistemático

(Enfriamiento y Calefacción)

Climatiseur numérique multifonctionnel

(Réfrigération & Chauffage)

Sistema Aria Condizionata

(Raffredamento e Riscaldamento)

Klimaanlage System

(Kühlen and Heizen)

DB98-24325A(1)SE F I D

OWNER’S INSTRUCTIONS

MANUAL DE INSTRUCCIONES

MANUEL D’UTILISATION

ISTRUZIONI PER L’USO

GEBRAUCHSANWEISUNG

AVMDSH022EA

AVMDSH028EA

AVMDSH036EA

AVMDSH045EA

AVMDSH056EA

AVMDSH071EA

AVMDSH112EA

AVMDSH128EA

AVMDSH140EA

AVMDSH022EA_E_24325.indd 15 2005-11-10 ｿﾀﾈﾄ 6:55:37

E-2

Safety Precautions

The following safety precautions must be taken when using your air conditioner.

WARNING

◆ Users of this product are cautioned not to attempt repair of this product

at their own discretion. Instead, they are requested to directly contact a

designated service center or the outlet at which the product was

purchased.

◆ Never spill any kind of liquid into the unit. Should this happen, unplug

or main switch off the unit and contact an authorized service center.

◆ Do not insert anything between the air outlet blades because the inner

fan may be damaged and could cause injury. Keep children away from

the unit.

◆ Do not place any obstacles in front of the unit.

◆ Do not spray liquid of any kind into the indoor unit. Should this

happen, switch off the breaker used for your air conditioner and

contact your installation specialist.

◆ Make sure that the unit is correctly ventilated at all times:

Do not place clothing or other materials over it.

◆ If the wireless remote control will not be used for a long time, remove

the batteries. (If applicable)

◆ When using a wireless remote control, the distance should not be more

than 7 meters from the air conditioner. (If applicable)

◆ Never store or ship the air conditioner upside down or sideways to

avoid damage to the compressor.

◆ The appliance is not intended for use by young children or infirm

persons without supervision: Young children should be supervised to

ensure that they do not play with the appliance.

◆ Max current is measured according to IEC standard for safety and

current is measured according to ISO standard for energy efficiency.

◆ Before throwing out the device, it is necessary to pull back the battery

cells and get rid of them safely for recycling reasons.

◆ When you need to dispose of the unit, consult your dealer. If pipes are

removed incorrectly, refrigerant may blow out and come into contact

with your skin, causing injury. Releasing refrigerant into the atmosphere

also damages the environments.

◆ Please recycle or dispose of the packaging material for this product in

an environmentally responsible manner.

DURING OPERATION

OTHERS

DISPOSING OF THE UNIT

Risk of electric shock. • Can cause injury or death. • Disconnect all

remote electric power supplies before servicing, installing or cleaning.

• This must be done by the manufacturer or its service agent or a

similar qualified person in order to avoid a hazard.

AVMDSH022EA_E_24325.indd 2 2005-11-10 ｿﾀﾈﾄ 6:55:30

E-3

ENGLISH

Contents

◆ PREPARING YOUR AIR CONDITIONER

■ Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

■ View of the Indoor unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

■ Wireless Remote Controller-Buttons and Display . . . . . . . . . . . . . . . 5

■ The Receiver & Display Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

■ Wired Remote Controller-Buttons and Display. . . . . . . . . . . . . . . . . . 8

■ Centralized Controller. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

■ Function Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

◆ RECOMMENDATIONS FOR USE

■ Operating Recommendations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

■ Temperature and Humidity Ranges. . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

■ Cleaning Your Air Conditioner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

■ Solving Common Problems. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Correct Disposal of This Product

(Waste Electrical & Electronic Equipment)

(Applicable in the European Union and other European countries with separate collection systems)

This marking shown on the product or its literature, indicates that it should not be disposed with other household

wastes at the end of its working life. To prevent possible harm to the environment or human health from uncontrolled

waste disposal, please separate this from other types of wastes and recycle it responsibly to promote the sustainable

reuse of material resources.

Household users should contact either the retailer where they purchased this product, or their local government office,

for details of where and how they can take this item for environmentally safe recycling.

Business users should contact their supplier and check the terms and conditions of the purchase contract.

This product should not be mixed with other commercial wastes for disposal.

AVMDSH022EA_E_24325.indd 3 2005-11-10 ｿﾀﾈﾄ 6:55:30

E-4

View of the Indoor unit

The figures are shown in this instruction may differ from yours depending on the model.

Indoor Unit

Air

inlet

Air

outlet

AVMDSH022EA_E_24325.indd 4 2005-11-10 ｿﾀﾈﾄ 6:55:31

E-5

ENGLISH

Wireless Remote Controller-Buttons and Display

The wireless remote controller is an optional accessory.

To use the wireless remote controller, refer to an appropriate manual.

◆ After cleaning the air filter, press the button.

◆ Duct type air conditioner does not have function of adjusting air flow direction.

Therefore, the function is not operated even if you press the button.

Note

Air flow direction

Operating mode Mode selection button

Filter Reset button

Swing button (Not operated)

On Timer button

Off Timer button

On/Off & Timer Set/

Cancel button

Fan speed adjustment

button

Temperature adjustment

buttons

Temperature setting

Fan speed

On Timer setting

Off Timer setting

Battery discharge indicator

AVMDSH022EA_E_24325.indd 5 2005-11-10 ｿﾀﾈﾄ 6:55:31

E-6

The Receiver & Display Unit

The Receiver & Display unit is an optional accessory and it is installed on the wall.

To use the receiver & display unit, refer to an appropriate manual.

Concealed Type

Filter sign indicator

Fan indicator

Timer indicator

Remote control sensor

- Heat Pump Models :

On/Off indicator(Blue) &

Removing frost

indicator(Red)

- Cooling Only Models :

On/Off indicator

AVMDSH022EA_E_24325.indd 6 2005-11-10 ｿﾀﾈﾄ 6:55:32

E-7

ENGLISH

The Receiver & Display Unit

Standard Type

Filter sign indicator

Removing frost indicator

(Except Cooling Only Models)

Fan indicator

On/Off indicator

Timer indicator

Remote control sensor

On/Off button

AVMDSH022EA_E_24325.indd 7 2005-11-10 ｿﾀﾈﾄ 6:55:32

E-8

Wired Remote Controller-Buttons and Display

The wired remote controller is an optional accessory and it is installed on the wall.

To use the wired remote controller, refer to an appropriate manual.

◆ The button is for your installation specialist. You must NOT press it.

◆ After cleaning the air filter, press the button. Then the wired remote

controller will display the FILTER SIGN indicator when the time to clean the

air filter; refer to page 12.

◆ Duct type air conditioner does not have function of adjusting air flow direction.

Therefore, the function is not operated even if you press the button.

Note

Communication error indicator

On Timer setting

Off Timer setting

Test indicator

On Timer button

Timer Set/Cancel button

Test button Filter Reset button

Mode selection button

Temperature adjustment

buttons

Centralized controller indicator

(In case of installing the Centralized controller)

Removing frost indicator

(Except Cooling Only Models)

Temperature setting

Fan speed

Air flow direction

Filter Sign indicator

On/Off button

Fan speed adjustment

button

Swing button

(Not operated)

On/Off indicator

Operating mode

AVMDSH022EA_E_24325.indd 8 2005-11-10 ｿﾀﾈﾄ 6:55:33

E-9

ENGLISH

Front View

Centralized Controller

The centralized controller is an optional accessory and it is installed on the wall.The centralized controller is an optional accessory and it is installed on the wall.

To use the centralized controller, refer to an appropriate manual.

Operating lamp

All On button

All Off button

On/Off indicators

On/Off buttons

Index

◆ The operating lamp comes on even when only one air conditioner

connected to the centralized controller is operating.

Note

◆ Choose the appropriate operating mode with the Operating Mode Switch

that enables the user to choose between the Cool/Auto/Heat mode.

Note

Side View

Operating Mode Switch

AVMDSH022EA_E_24325.indd 9 2005-11-10 ｿﾀﾈﾄ 6:55:34

E-10

Function Controller

The function controller is an optional accessory and it is installed on the wall.

The function controller is an additional controller which is used with the centralized controller.

To use the function controller, refer to an appropriate manual.

◆ The button is for your installation specialist. You must NOT press it.

◆ After cleaning the air filter, press the button. Then the wired remote controller will

display the FILTER SIGN indicator when the time to clean the air filter.

Note

Room number display

Filter Reset button

Swing button

Temperature setting

Fan speed

Air flow direction

Filter Sign indicator

On/Off & Timer Set/

Cancel button

Fan speed adjustment

button

On/Off indicator

Test indicator

Indoor unit selection button

Test button

Temperature adjustment

buttons

Mode selection button

Centralized controller indicator

Communication error indicator

Removing frost indicator

(Except Cooling Only Models)

Operating mode

AVMDSH022EA_E_24325.indd 10 2005-11-10 ｿﾀﾈﾄ 6:55:35
