Samsung APC4082EC User manual

ENGLISH

Split-type Packged Air Conditioner (Cool)

Grieta de Colmado de Aire Acondicionado (Refrigeración)

Climatiseur Monobloc de Type Split (Refroidissement)

OWNER’S INSTRUCTIONS

MANUAL DE INSTRUCCIONES

MANUEL D’UTILISATION

E S F A DB98-04434A(1)

Indoor Unit

APC4082E

APC4082EC

Outdoor Unit

UPC4082E

UPC4082EC

ESPAÑOL

FRANÇAIS

Safety Precautions

◆If the power supply cord of this air conditioner is damaged,

it must be replaced by the manufacturer or its authorized

service personnel only in order to avoid a safety hazard.

WARNING

◆Do not attempt to install this air conditioner by yourself.

◆This unit contains no user-serviceable parts. Always consult authorized

service personnel for repairs.

◆When moving, consult authorized service personnel for disconnection

and installation of the unit.

◆Do not become over-exposed to cold air by staying in the direct path of

the airflow of the air conditioner for extended periods of time.

◆Do not insert fingers or objects into the outlet port or intake grilles.

◆Do not start and stop air conditioner operation by disconnecting the

power supply cord and so on.

◆Take care not to damage the power supply cord.

◆In the event of a malfunction (burning smell, etc.), immediately stop

operation, turn off the electrical breaker, and consult authorized

service personnel.

DANGER

◆Provide occasional ventilation during use.

◆Do not direct air flow at fireplaces or heating apparatus.

◆Do not climb on, or place objects on, the air conditioner.

◆Do not hang objects from the indoor unit.

◆Do not set flower vases or water containers on top of air conditioners.

◆Do not expose the air conditioner directly to water.

◆Do not operate the air conditioner with wet hands.

◆Do not pull power supply cord.

◆Turn off power source when not using the unit for extended periods.

◆Check the condition of the installation stand for damage.

◆Do not place animals or plants in the direct path of the air flow.

◆Do not drink the water drained from the air conditioner.

◆Do not use in applications involving the storage of foods, plants or

animals, precision equipment, or art works.

◆Do not apply any heavy pressure to radiator fins.

◆Operate only with air filters installed.

◆Do not block or cover the intake grille and outlet port.

◆Ensure that any electronic equipment is at least one metre away from

either the indoor or outdoor units.

◆Avoid installing the air conditioner near a fireplace or other heating

apparatus.

◆When installing the indoor and outdoor unit, take precautions to prevent

access to infants.

◆Do not use inflammable gases near the air conditioner.

CAUTION

E-2

Contents

◆

REPARING YOUR AIR CONDITIONER

■ Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

■ View of the Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

■ Remote Control-Buttons and Display . . . . . . . . . . . . . . . . . . . . 6

■ Digital Telecommunicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

■ Getting Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

■ Inserting the Remote Control Batteries . . . . . . . . . . . . . . . . . . . 9

■ Operating Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

◆

PERATING YOUR AIR CONDITIONER

■ Cooling Your Room . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

■ Selecting the Automatic Operating Mode . . . . . . . . . . . . . . . . 11

■ Changing the Room Temperature Quickly . . . . . . . . . . . . . . . 12

■ Cooling Distant Place . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

■ Removing Excess Humidity . . . . . . . . . . . . . . . . . . . . . . . . . . 14

■ Airing Your Room . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

■ Selecting Energy Saving Mode . . . . . . . . . . . . . . . . . . . . . . . 16

■ Cleaning Air in Your Room . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

■ Adjusting the Air Flow Direction Vertically . . . . . . . . . . . . . . . 18

■ Adjusting the Air Flow Direction Horizontally . . . . . . . . . . . . . 19

◆

ROGRAMMING YOUR AIR CONDITIONER

■ Setting the On Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

■ Setting the Off Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

■ Setting the Sleep Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

■ Using Digital Telecommunicator . . . . . . . . . . . . . . . . . . . . . . . 23

◆

ECOMMENDATIONS FOR USE

■ Operating Recommendations . . . . . . . . . . . . . . . . . . . . . . . . 25

■ Temperature and Humidity Ranges . . . . . . . . . . . . . . . . . . . . 25

■ Cleaning Your Air Conditioner . . . . . . . . . . . . . . . . . . . . . . . . 26

■ Solving Common Problems . . . . . . . . . . . . . . . . . . . . . . . . . . 28

◆

ECHNICAL SPECIFICATIONS

E-3

ENGLISH

View of the Unit

Indoor Unit

Air flow blades

(up/down orientation)

Air flow blades

(right/left orientation)

Automatic shutter

Air outlet

Air filter

Air inlet

Control Panel

On/Off button

You can operate the air conditioner with the control panel when you do not

wish to or cannot operate the air conditioner with the remote control.

E-4

To open the grille

◆Hold the upper

part of the

grille, then

pull it slightly

forward.

Clean level display

Digital telecommunicator indicator display

Temperature display

Temperature adjustment buttonsRemote control sensor

Air inlet(Rear)

Air outlet

Connection valve

Outdoor Unit

E-5

ENGLISH

Remote Control - Buttons and Display

Operating mode

(Cool, Auto, Dry, Fan)

Temperature setting

Sleep timer button

Temperature adjustment

buttons

Extra button

Operating mode selection button

(Cool, Auto, Dry, Fan)

Air flow swing button

On/Off timer button

Fan speed

(Auto, Low, Medium, High)

Timer settings

On/Off button

Fan speed adjustment button

Turbo button

Energy saving button

Air Clean button

Timer set/cancel button

E-6

Digital Telecommunicator

Operating indicator

◆ It flashes when the ARS is operating.

E-7

ENGLISH

Front

Reset button

◆ Press if the digital telecommunicator does not

operate normally.

Telephone cable port

Power cable port

Back

Connection

Connect telephone line

Telephone jack

(Line-phone)

Telephone jack

(Line-line)

Digital telecommunicator

DC adaptor

Plug in

Getting Start

You have just purchased a split-type packaged air conditioner and

it has been installed by your installation specialist.

You Owner's Instructions contain much valuable information on using your

air conditioner. Please take the time to read them as they will help you take

full advantage of unit's features.

The booklet is organized as follows.

◆The following figures are shown on pages from 4 to 7:

- Indoor and outdoor units

- Remote control (buttons and display)

- Digital telecommunicator

They will help you find the buttons and understand the symbols displayed.

◆In the main part of the document, you will find a series of step-by-step

procedures for each function available.

The illustrations in the step-by-step procedures use three different symbols:

PRESS PUSH HOLD DOWN

E-8

Inserting the Remote Control Batteries

Push the battery cover on the rear of the remote control with your thumb

in the direction of the arrow and remove it.

Insert the two batteries, taking care to respect the polarities :

◆+ on the battery with + on the remote control.

◆- on the battery with - on the remote control.

Close the cover by sliding it back until it clicks into place.

◆Use two AAA, LR03 1.5V batteries.

◆Do not use old batteries or different kinds of batteries together.

◆Batteries may be completely discharged after 12 months,

even if they have not actually been used.

You must insert or replace the remote control batteries when :

◆You purchase the air conditioner

◆The remote control does not work correctly

NNoo

oott

ttee

Operating Preparation

Turn the power switch on.1

Look around the indoor and outdoor unit. Confirm if any obstacles

that may prevent the air flow are present near the air conditioner.

E-9

ENGLISH

To operate the unit, the power switch is fitted to the wall

must be set to ON.

IMPORTANT

Cooling Your Room

E-10

You must select the Cool mode if you wish to adjust the :

◆Cooling temperature

◆Fan speed when cooling

1If necessary, press the button.

Result: ◆The air conditioner starts up in the Cool mode.

◆The indoor unit beeps.

The air conditioner is fitted with a protection mechanism to

prevent the unit from being damaged when it is started

immediately after being:

◆Plugged in

◆Stopped

lt will start up normally after three minutes.

IMPORTANT

If the is not displayed at the top of the remote control, press the button

on the remote control one or more times until it appears.

Result: ◆The indoor unit beeps each time you press the button.

◆The air conditioner runs in the Cool mode.

You can change modes at any time.

NNoo

oott

ttee

To adjust the temperature, press the button one or more times until the

required temperature is displayed. Possible temperatures are between 18

and 30

C inclusive.

Result: ◆Each time you press the button:

- The temperature is adjusted by 1

- The indoor unit beeps.

◆The air conditioner starts cooling, provided that the room

◆temperature is higher than the selected temperature.

Select the fan speed by pressing the button one or more times until

the required setting is displayed :

Result: ◆Each time you press the button, the indoor unit beeps.

Automatic(rotated : ➔➔ )

Low

Medium

High

To control the direction of the air flow, refer to pages 18~19.
