Samsung AC TNPPEH Series Guide

Air conditioner

User & installation manual

AC***TNPPEH

• Thank you for purchasing this Samsung air conditioner.

• Before operating this unit, please read this manual carefully and retain it for future reference.

DB68-09343A-00

DB68-09343A-00_IBIM_PAC 미라지 이집트파키스탄_IQ_EN.indd 1 2020-07-28 오전 11:08:42

English

Contents

Safety Information 4

Safety Information (Using the Air Conditioner) 4

Operation Features 12

Checking auxiliary power switch • Operating temperature and humidity 12

At a Glance 13

Indoor Unit Overview 13

Opening the panel 13

Control Panel Overview 14

Indoor unit display 14

Controlling with the control panel 15

Turning on or off the air conditioner • Controlling temperature • Controlling the fan speed 15

Selecting the operation mode/Locking the control panel 16

Remote Control Overview 17

Replacing batteries • Storing the remote control 18

Remote Control Operation 19

Turning on or off the air conditioner • Operation modes 19

Controlling fan speed • Controlling temperature • Controlling air flow direction 20

Power Smart Features 21

Auto mode • Cool mode 21

Dry mode • Fan mode 22

Heat mode 23

Variety Smart Features 24

Turbo function • Long reach function 24

Clean function 25

Energy-Saving Operation 26

Timed on/Timed off function 26

Cleaning and Maintenance 27

Cleaning at a Glance 27

Troubleshooting 30

DB68-09343A-00_IBIM_PAC 미라지 이집트파키스탄_IQ_EN.indd 2 2020-07-28 오전 11:08:42

English

Correct Disposal of This Product

(Waste Electrical & Electronic Equipment)

(Applicable in countries with separate collection systems)

This marking on the product, accessories or literature indicates that the product and its electronic accessories

(e.g. charger, headset, USB cable) should not be disposed of with other household waste at the end of their working life.

To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate these

items from other types of waste and recycle them responsibly to promote the sustainable reuse of material resources.

Household users should contact either the retailer where they purchased this product, or their local government ofce,

for details of where and how they can take these items for environmentally safe recycling.

Business users should contact their supplier and check the terms and conditions of the purchase contract. This product

and its electronic accessories should not be mixed with other commercial wastes for disposal.

Safety Information 33

Safety Information (Installing the Air Conditioner) 33

General information 33

Installing the unit 33

Power supply line, fuse or circuit breaker 34

Installation Procedure 35

Step 1 Choosing the installation location 35

Step 2 Checking and preparing accessories 35

Step 3 Drilling a hole through a wall 36

Step 4 Taping the pipes, cables, and drain hose 36

Step 5 Purging inert gas from the indoor unit 37

Step 6 Optional: Cutting and flaring the pipes 37

Step 7 Connecting the refrigerant pipes 38

Step 8 Performing the gas leak test 38

Step 9 Fixing and insulating the connection part for refrigerant pipes 39

Step 10 Installing and connecting the drain hose 39

Step 11 Performing drainage test 40

Step 12 Connecting the power and communication cables 40

Step 13 Optional: Extending the power cable 42

Step 14 Setting the indoor unit addresses and the installation options 43

Step 15 Optional: Fixing the indoor unit 52

Appendix 53

Troubleshooting 53

DB68-09343A-00_IBIM_PAC 미라지 이집트파키스탄_IQ_EN.indd 3 2020-07-28 오전 11:08:42

English

Safety Information

Safety Information (Using the Air Conditioner)

Before using your new air conditioner, please read this manual thoroughly to

ensure that you know how to safely and efciently operate the extensive features

and functions of your new appliance.

Because the following operating instructions cover various models, the

characteristics of your air conditioner may differ slightly from those described in

this manual. If you have any questions, call your nearest contact center or nd

help and information online at www.samsung.com.

These warning signs are here to prevent injury to you and others. Please follow

them carefully.

Important safety symbols and precautions:

WARNING

Hazards or unsafe practices that may result in severe personal injury or death.

CAUTION

Hazards or unsafe practices that may result in minor personal injury or property

damage.

Follow directions.

Do NOT attempt.

Make sure the machine is grounded to prevent electric shock.

Unplug the power plug from the wall socket.

Do NOT disassemble.

Safety Information

DB68-09343A-00_IBIM_PAC 미라지 이집트파키스탄_IQ_EN.indd 4 2020-07-28 오전 11:08:42

English

Safety Information

FOR INSTALLATION

WARNING

Use the power line with the power specications of the product or higher

and use the powerline for this appliance only. In addition, do not use an

extension line.

• Extending the power line may result in electric shock or re.

• Do not use an electric transformer. It may result in electric shock or re.

• If the voltage/frequency/rated current condition is different, it may cause re.

The installation of this appliance must be performed by a qualied

technician orservice company.

• Failing to do so may result in electric shock, re, explosion, problems with

the product, or injury.

Install a switch and circuit breaker dedicated to the air conditioner.

• Failing to do so may result in electric shock or re.

Fix the outdoor unit rmly so that the electric part of the outdoor unit is

not exposed.

• Failing to do so may result in electric shock or re.

Do not install this appliance near a heater, inammable material. Do

not install this appliance in a humid, oily or dusty location, in a location

exposed to direct sunlight and water (rain drops). Do not install this

appliance in a location where gas may leak.

• This may result in electric shock or re.

Never install the outdoorunit in a location such as on a high external wall

where it could fall.

• If the outdoor unit falls, it may result in injury, death or property damage.

DB68-09343A-00_IBIM_PAC 미라지 이집트파키스탄_IQ_EN.indd 5 2020-07-28 오전 11:08:42

English

Safety Information (Using the Air Conditioner)

Safety Information

This appliance must be properly grounded. Do not ground the appliance to

a gas pipe, plastic water pipe, ortelephone line.

• Failure to do so may result in electric shock, re, an explosion, or other

problems with the product.

• Never plug the power cord into a socket that is not grounded correctly and

make sure that it is in accordance with local and national codes.

CAUTION

Install your appliance on a level and hard oor that can support its weight.

• Failing to do so may result in abnormal vibrations, noise, or problems with

the product.

Install the draining hose properly so that water is drained correctly.

• Failing to do so may result in water overowing and property damage.

When installing the outdoor unit, make sure to connect the draining hose

so that draining is performed correctly.

• The water generated during the heating operation by the outdoor unit may

overow and result in property damage. In particular, in winter, if a block

of ice falls, it may result in injury, death or property damage.

Do not install the product in a place where thermo-hygrostat is needed

(such as serverroom, machinery room, computerroom, etc.)

• Those places do not provide guaranteed operation condition of the

product therefore performance can be poor in these places.

Do not install the product in a place where hairspray is frequently used

(such as hair salon) since it decreases the hydrophilicity of the product's

heat exchanger and cause dew formation on the surface of the product.

DB68-09343A-00_IBIM_PAC 미라지 이집트파키스탄_IQ_EN.indd 6 2020-07-28 오전 11:08:43

English

Safety Information

FOR POWER SUPPLY

WARNING

When the circuit breaker is damaged, contact yournearest service centre.

Do not pull orexcessively bend the powerline. Do not twist ortie the power

line. Do not hook the powerline overa metal object, place a heavy object

on the powerline, insert the power line between objects, orpush the power

line into the space behind the appliance.

• This may result in electric shock or re.

CAUTION

When not using the airconditionerfor a long period of time orduring a

thunder/lightning storm, cut the powerat the circuit breaker.

• Failing to do so may result in electric shock or re.

FOR USING

WARNING

If the appliance is ooded, please contact your nearest service centre.

• Failing to do so may result in electric shock or re.

If the appliance generates a strange noise, a burning smell orsmoke, unplug

the power plug immediately and contact yournearest service centre.

• Failing to do so may result in electric shock or re.

In the event of a gas leak (such as propane gas, LP gas, etc.), ventilate

immediately without touching the power line. Do not touch the appliance

or power line.

• Do not use a ventilating fan.

• A spark may result in an explosion or re.

DB68-09343A-00_IBIM_PAC 미라지 이집트파키스탄_IQ_EN.indd 7 2020-07-28 오전 11:08:43

English

Safety Information (Using the Air Conditioner)

Safety Information

To reinstall the air conditioner, please contact yournearest service centre.

• Failing to do so may result in problems with the product, water leakage,

electric shock, or re.

• A delivery service for the product is not provided. If you reinstall the

product in another location, additional construction expenses and an

installation fee will be charged.

• Especially, when you wish to install the product in an unusual location

such as in an industrial area or near the seaside where it is exposed to the

salt in the air, please contact your nearest service centre.

Do not touch the circuit breakerwith wet hands.

• This may result in electric shock.

Do not strike or pull the airconditionerwith excessive force.

• This may result in re, injury, or problems with the product.

Do not place an object nearthe outdoorunit that allows children to climb

onto the machine.

• This may result in children seriously injuring themselves.

Do not turn the airconditioner off with the circuit breakerwhile it is

operating.

• Turning the air conditioner off and then on again with the circuit breaker

may cause a spark and result in electric shock or re.

Afterunpacking the air conditioner, keep all packaging materials well

out of the reach of children, as packaging materials can be dangerous to

children.

• If a child places a bag over its head, it may result in suffocation.

Do not touch the air ow blade with your hands or ngers during the

heating operation.

• This may result in electric shock or burns.

Do not insert your ngers or foreign substances into the outlet when the air

conditioner is operating or the air ow blade is closing.

• Take special care that children do not injure themselves by inserting their

ngers into the product.

DB68-09343A-00_IBIM_PAC 미라지 이집트파키스탄_IQ_EN.indd 8 2020-07-28 오전 11:08:43

English

Safety Information

Do not insert your ngers or foreign substances into the air inlet/outlet of

the air conditioner.

• Take special care that children do not injure themselves by inserting their

ngers into the product.

Do not use this airconditionerfor long periods of time in badly ventilated

locations or near inrm people.

• Since this may be dangerous due to a lack of oxygen, open a window at

least once an hour.

If any foreign substance such as water has entered the appliance, cut the

power by unplugging the power plug and turning the circuit breaker off

and then contact your nearest service centre.

• Failing to do so may result in electric shock or re.

Do not attempt to repair, disassemble, ormodify the appliance yourself.

• Do not use any fuse (such as copper, steel wire, etc.) other than the

standard fuse.

• Failing to do so may result in electric shock, re, problems with the

product, or injury.

CAUTION

Do not place objects or devices underthe indoor unit.

• Water dripping from the indoor unit may result in re or property damage.

Check that the installation frame of the outdoorunit is not broken at least

once a year.

• Failing to do so may result in injury, death or property damage.

Max current is measured according to IEC standard forsafety and current is

measured according to ISO standard for energy efciency.

DB68-09343A-00_IBIM_PAC 미라지 이집트파키스탄_IQ_EN.indd 9 2020-07-28 오전 11:08:43

English

Safety Information (Using the Air Conditioner)

Safety Information

Do not stand on top of the appliance or place objects (such as laundry,

lighted candles, lighted cigarettes, dishes, chemicals, metal objects, etc.)

on the appliance.

• This may result in electric shock, re, problems with the product, or injury.

Do not operate the appliance with wet hands.

• This may result in electric shock.

Do not spray volatile material such as insecticide onto the surface of the

appliance.

• As well as being harmful to humans, it may also result in electric shock,

re or problems with the product.

Do not drink the waterfrom the airconditioner.

• The water may be harmful to humans.

Do not apply a strong impact to the remote control and do not disassemble

the remote control.

Do not touch the pipes connected with the product.

• This may result in burns or injury.

Do not use this airconditionerto preserve precision equipment, food,

animals, plants or cosmetics, or for any other unusual purposes.

• This may result in property damage.

Avoid directly exposing humans, animals or plants from the air ow from

the air conditionerforlong periods of time.

• This may result in harm to humans, animals or plants.

This appliance is not intended foruse by persons (including children) with

reduced physical, sensory or mental capabilities, or lack of experience

and knowledge, unless they have been given supervision or instruction

concerning use of the appliance by a person responsible fortheir safety.

Children should be supervised to ensure that they do not playwith the

appliance.

DB68-09343A-00_IBIM_PAC 미라지 이집트파키스탄_IQ_EN.indd 10 2020-07-28 오전 11:08:43

Table of contents

Other Samsung Air Conditioner manuals

Samsung

Samsung AS09P8GB User manual

Samsung

Samsung AM022FN1DEH/TK User manual

Samsung

Samsung AM FNND Series User manual

Samsung

Samsung AQV09USeries Guide

Samsung

Samsung AWT18PHHBB User manual

Samsung

Samsung AM096HNPDCH Series User manual

Samsung

Samsung AR MV Series Guide

Samsung

Samsung AR TXHZ Series User manual

Samsung

Samsung Slim 1 Way User manual

Samsung

Samsung AC RN DKG Series User manual

Samsung

Samsung AR NVWS Series User manual

Samsung

Samsung AVMKH020CA0 User manual

Samsung

Samsung AS09N Series User manual

Samsung

Samsung AQT32C2BE User manual

Samsung

Samsung MH080FXCA4A User manual

Samsung

Samsung AVXCSH023/032/040CE User manual

Samsung

Samsung AC071MN4PKH User manual

Samsung

Samsung EH035CAV User manual

Samsung

Samsung EH035EAV User manual

Samsung

Samsung AC***MNADKH User manual

Samsung

Samsung NJ***1HXCA User manual

Samsung

Samsung AQ09T Series Guide

Samsung

Samsung AW08EDB Series User manual

Samsung

Samsung MWR-WG00JN User manual

Popular Air Conditioner manuals by other brands

Spheros

Spheros CC 355 instructions

Bosch

Bosch Climate 5000 SCI 24 CAS/ OU- OUE owner's manual

Panasonic

Panasonic CS-E12HKEW operating instructions

nedis

nedis ACMB1WT7 quick start guide

Daikin

Daikin FCFV50A Operation manual

Fujitsu

Fujitsu Inverter ASBA30JFC operating manual

Toshiba

Toshiba RAS-M10SMUV-E installation manual

Daikin

Daikin FXLQ20MAVE Operation manual

Hitachi

Hitachi RAS-E24CAK instruction manual

CIAT

CIAT Magister 2 Series Installation, Operation, Commissioning, Maintenance

Bestron

Bestron AAC6000 instruction manual

Hisense

Hisense 7K Use and Installation Instructions

Frigidaire

Frigidaire FFRE0533S1E0 Use & care guide

Frigidaire

Frigidaire CRA073PU11 use & care

Soleus Air

Soleus Air GB-PAC-08E4 operating instructions

McQuay

McQuay MCK020A Technical manual

Webasto

Webasto Frigo Top 25 DS Instructions for use

Frigidaire

Frigidaire FAZ12ES2A installation instructions
