Ricoh Aficio SG 3110SFNw User manual

Notes for Wireless LAN Users

This manual explains how to connect the machine to the network via a wireless LAN interface.

• Ad hoc mode is not supported.

• Ethernet and wireless LAN settings cannot be enabled at the same time.

Checking Your Wireless Network Environment

• Before configuring the wireless LAN settings, configure the machine's IP address.

For details about configuring the machine's IP address, see "2. Preparing for Printing", User

Guide .

• Check that the access point is operating.

CHV600

• Plug the wireless LAN cable into the Ethernet port before configuring the wireless LAN set-

tings.

CHV601

• Change the [LAN Type] to [IEEE 802.11b/g/n] before configuring the wireless LAN settings.

the [User Tools] key [Login] Enter the login password. (default: 000000) [System Settings]

[Interface Settings] [Network] [LAN Type] [IEEE 802.11b/g/n] Turn the machine off.

Turn the machine on.

CHV632

Selecting the Configuration Method

The configuration method depends on the access point being used.

"Easy Setup" is a function for automatically configuring the wireless LAN settings. The actual

name of the function may vary depending on the access point being used. See the access point

manual.

Page 4

”Easy Setup Using the

WPS Button”

Page 8

”Manual setting”

Easy Setup

“PBC Method”

Easy Setup

“PIN Method” Manual setting

Does the access point support "Easy Setup" of the wireless LAN?

Is there a push button

on the access point?

Page 6

”Easy Setup Using a

PIN Code”

Yes No

CHV604

• Manual setting: Page 8 "Configuring Settings Using Web Image Monitor"

• Manual setting: Page 17 "Configuring Settings Using the Control Panel"

Easy Setup Using the WPS Button

1. Turn the machine on.

CHV605

2. Press the [User Tools] key.

CHV051

3. Press [Login].

4. Enter the login password, and then press the [OK] key.

If this is the first time to log in, enter the default password of "000000".

5. Press the [ ] or [ ] key to display [System Settings], and then press the [OK] key.

6. Press the [ ] or [ ] key to display [Interface Settings], and then press the [OK] key.

7. Press the [ ] or [ ] key to display [IEEE 802.11], and then press the [OK] key.

8. Press the [ ] or [ ] key to display [Easy Setup], and then press the [OK] key.

1/1

IEEE

802.11 b/g/n

Det. Settings

Easy Setup

Current status

9. Press the WPS button on the access point.

WPS

CHV607

10. Press the [ ] or [ ] key to display [PBC Method], and then press the [OK] key.

1/1

Easy Setup:

PIN Method

PBC Method

If the connection is successful, "Connection to AP has succeeded." will be displayed.

If the connection fails, "Connection to AP has failed." is displayed. If this is the case, go back

to Step 8. If the problem persists, check whether the access point is working properly. If the

access point is working properly but the problem still persists, contact your sales or service

representative.

• If the access point cannot be detected within 120 seconds, the search session expires.

Easy Setup Using a PIN Code

1. Turn the machine on.

CHV605

2. Press the [User Tools] key.

CHV051

3. Press [Login].

4. Enter the login password, and then press the [OK] key.

If this is the first time to log in, enter the default password of "000000".

5. Press the [ ] or [ ] key to display [System Settings], and then press the OK key.

6. Press the [ ] or [ ] key to display [Interface Settings], and then press the OK key.

7. Press the [ ] or [ ] key to display [IEEE 802.11], and then press the OK key.

8. Press the [ ] or [ ] key to display [Easy Setup], and then press the OK key.

1/1

IEEE

802.11 b/g/n

Det. Settings

Easy Setup

Current status

9. Press the [ ] or [ ] key to display [PIN Method], and then press the OK key.

1/1

Easy Setup:

PIN Method

PBC Method

10. Check the machine's PIN.

PIN Method:

Connect

11. Enter the machine's PIN on the access point web page.

CHV609

For details, see the manual supplied with the wireless LAN access point.

12. Execute WPS (PIN system) from the access point's web page.

13. Press [Connect].

If the connection is successful, "Connection to AP has succeeded." will be displayed.

If the connection fails, “Connection to AP has failed.” is displayed. If this is the case, go back

to Step 10. If the problem persists, check whether the access point is working properly. If the

access point is working properly but the problem still persists, contact your sales or service

representative.

Manual Setting

If you cannot confirm the settings of the access point being used or the access point does not

support WPS, configure the wireless LAN settings manually.

You can configure the settings using Web Image Monitor or the control panel. This manual mainly

explains configuration using Web Image Monitor.

Configuring Settings Using Web Image Monitor

• Connect the machine and computer with an Ethernet cable before configuring the settings.

CHV619

• Check the security method employed by the access point being used.

• Change the [LAN Type] to [Ethernet] before configuring the wireless LAN settings.

CHV632

the [User Tools] key [Login] Enter the login password. (default: 000000) [System Settings]

[Interface Settings] [Network] [LAN Type] [Ethernet] the [OK] key Turn the machine

off. Turn the machine on.

• Check the machine's IP address.

CHV654

the [User Tools] key (1) [System Settings] [Interface Settings] [Network] [Machine IPV4

Address] [IP Add.] the [Escape] key (2) The control panel returns to the initial screen.

1/1

Mach.IPv4 Addr. :

Specify

Auto-Obtain(DHCP)

IP Add. Subnet M MAC Add.

1. Launch the Web browser.

2. In the address bar, enter "http://(machine's IP address or host name)/".

3. Enter the administrator password, and then click [Login].

If this is the first time to log in, enter the default password of "000000".

CHV636

4. In the menu area, click [Configuration].

CHV638
