Ricoh MP C3003 User manual

STEP 1:

Select the Copier icon. Note: If you are not already

on the home screen, Select the Home button on

the Control Panel.

STEP 2:

• Enter the number of Booklets you want to

create. (For demonstration purposes, the

number 25 has already been added.)

• You will now choose the Paper Size. Select

11 x 17.

STEP 3:

Select Dup./Combine/Series.

TRAINING EXERCISE

CUSTOMIZING HOME SCREEN WITH SHORT CUT ICON: CREATING

STAPLED BOOKLETS

SELECT

Ricoh Americas Corporation, 70 Valley Stream Parkway, Malvern, PA 19355. Ricoh® and the Ricoh logo are registered trademarks of Ricoh Co, Ltd.

Color Multifunction

MP C3003/MP C3503/MP C4503/MP C5503/MP C6003 Series

Ricoh Americas Corporation, 70 Valley Stream Parkway, Malvern, PA 19355. Ricoh® and the Ricoh logo are registered trademarks of Ricoh Co, Ltd.

CUSTOMIZING HOME SCREEN WITH SHORT CUT ICON: CREATING STAPLED BOOKLETS

Color Multifunction

MP C3003/MP C3503/MP C4503/MP C5503/MP C6003 Series

STEP 4:

Select Book.

STEP 5:

Select Magazine.

STEP 6:

Select the Staple icon.

SELECT

Ricoh Americas Corporation, 70 Valley Stream Parkway, Malvern, PA 19355. Ricoh® and the Ricoh logo are registered trademarks of Ricoh Co, Ltd.

CUSTOMIZING HOME SCREEN WITH SHORT CUT ICON: CREATING STAPLED BOOKLETS

Color Multifunction

MP C3003/MP C3503/MP C4503/MP C5503/MP C6003 Series

STEP 7:

Select the Program button on the Control Panel.

STEP 8:

Select Program.

STEP 9:

You will now begin the process of naming your

short cut icon. Select a “Not Programmed” button.

SELECT

Ricoh Americas Corporation, 70 Valley Stream Parkway, Malvern, PA 19355. Ricoh® and the Ricoh logo are registered trademarks of Ricoh Co, Ltd.

CUSTOMIZING HOME SCREEN WITH SHORT CUT ICON: CREATING STAPLED BOOKLETS

Color Multifunction

MP C3003/MP C3503/MP C4503/MP C5503/MP C6003 Series

STEP 10:

Type the name of your icon. Select OK. For

demonstration purposes, Booklets 11x17 has

already been entered.

STEP 11:

The name of your short cut icon now appears in the

program list. Select Program to Home.

STEP 12:

A screen appears asking if you are sure you want

to register the program to the Home screen. Select

Yes.

SELECT

Ricoh Americas Corporation, 70 Valley Stream Parkway, Malvern, PA 19355. Ricoh® and the Ricoh logo are registered trademarks of Ricoh Co, Ltd.

CUSTOMIZING HOME SCREEN WITH SHORT CUT ICON: CREATING STAPLED BOOKLETS

Color Multifunction

MP C3003/MP C3503/MP C4503/MP C5503/MP C6003 Series

STEP 13:

Notice that the Home icon appears next to the

Booklets 11x17 program. Select Exit to return to

the Copier main screen.

Note: To see the short cut icon you created, Select

the Home button on the Control Panel.

STEP 14:

You have now completed customizing your home

screen.

JOB TASK COMPLETE.

SELECT
