RH LUCENT Instruction manual
LUCENT ROUND MIRROR 60" (153 CM)
ASSEMBLY AND INSTALLATION INSTRUCTIONS
ENGLISH
LUCENT ROUND MIRROR 60" (153 CM) ENGLISH
RH.COM
REVISION 24-05-22
LUCENT ROUND MIRROR 60" (153 CM)
PART LIST
(A) Mirror With Bracket (1)
(B) Screw - M4 x 30mm (8)
(C) EZ Mini Anchor 14 x 44mm (8)
(D) Aluminum Hanger 30" (76 cm) (1)
WARNING
1. In order to prevent falling down this product must be used with the
wall attachment device provided.
2. Assess the suitability of the wall to ensure that the fastening devices
will withstand the forces generated.
STORAGE
1. Do not stack anything on top of the mirror.
2. Keep the mirror packaged until installation.
3. Store mirror upright on the long edge.
MIRROR HANDLING INSTRUCTIONS
Caution:
1. Remove vertically from package.
2. Always carry mirror vertically as illustrated.
Carrying flat will cause breakage.
BEFORE YOU BEGIN
1. Professional installation recommended.
2. Tool and materials required:
Carpenter's level
Phillips head screwdriver
3. These instructions are provided for your safety. It is important that
they are read carefully and completely before installation of the
fixture.
4. For your safety, it is recommended that two people hang the fixture.
5. Check with a professional to ensure your wall can tolerate a fixture
weighing 167 lbs (75 kg).
6. When wall mounting, stud mounting is strongly recommended.
(A)
(B)
(C)
(D)
LUCENT ROUND MIRROR 60" (153 CM) ENGLISH
RH.COM
REVISION 24-05-22
INSTALLATION OF MIRROR
1. Unpack all parts and place them on a protected work surface.
2. Determine the exact location of the fixture and mark the holes on the
wall surface using the holes in the aluminum hanger (D) as a guide.
3. Drill small holes on each point location on the wall.
Each hole should be just large enough to accommodate EZ mini
anchor (C).
4. Insert the EZ mini anchors (C) into the holes on the wall.
5. Mount the aluminum hanger (D) into the wall using screws (B).
6. Check that the aluminum hanger fixture is securely screwed into the
wall.
7. Place the mirror with hanger cleat (A) into the aluminum hanger
fixture.
8. Installation is complete.
**NOTE: MAKE SURE THAT THE TWO (2) CLEATS (1 ON MIRROR
AND 1 ON WALL) ARE LOCKED AND SECURED WITH EACH
OTHER. A LEVEL CHECK IS HIGHLY RECOMMENDED.
CHECK AND ADJUST IF NEEDED.
CLEANING INSTRUCTIONS
To clean, use a soft dry or damp cloth.
Do not use abrasive cleaners.
D
B
C
Wall
FIGURE 2 FIGURE 3
BC
Wall
Mirror
FIGURE 1
FIGURE 4 FIGURE 5
OK NOT OK
A
