Pulsar KINETIC 5M42 User manual
CAL. 5M42
ENGLISH
●KINETIC E. S. U. (Electricity Storage Unit)
●Power reserve indicator
●Energy depletion forewarning function
●Instant-start function
●Time and date calendar
●Rotating bezel
(only for models with rotating bezel)
®
English
2
DISPLAY AND CROWN/BUTTON
CROWN
a b c
Hour hand
BUTTON
Second hand
Date
Minute hand
a: Normal position c: Second clickb: First click
English
3
SCREW DOWN CROWN
[for models with screw down crown]
Locking the crown
1Turn Crown counterclockwise until you no
longer feel the threads turning.
2Crown can be pulled out.
1Push Crown back in to normal position.
2TurnCrownclockwisewhilepressingitlightly
until tight.
Unlocking the crown
English
4
HOW TO CHARGE AND START THE WATCH
1Swing the watch from side to
side.
2Charge the KINETIC E. S. U.
sufficiently.
3Set the time/calendar and put
on the watch.
* Swing rhythmically at a rate of
twice a second.
English
5
✩★
Wearing the watch.
6 hours 2 days
Power reserve
➡
➡
80 m 350 m
✩
The second hand starts moving at one-second intervals.
✰
The illustration provides only a general guideline of the relationship between the power
reserve and the distance you walk. Actual amount of power reserve differs from person
to person.
✽Power reserve accumulated while you are walking
✽Precaution on see-through case-back models
If your watch has a glass case back, do not expose the case back to strong light
such as direct sunlight or an incandescent light at close range, as this may
temporarily increase the power consumption of the watch circuit, thus reducing the
power reserve in the KINETIC E. S. U. This condition, however, will be corrected
when the case back is turned away from the light.
English
6
POWER RESERVE INDICATOR
BUTTON Press the button at the 2 o’clock position.
5 seconds 10 seconds 20 seconds 30 seconds
QUICK MOVEMENT
OF SECOND HAND
★
➧
➧
➧
➧
POWER
RESERVE
Between
6 and 48
hours
Between
2 and 4
days
Between
4 and 7
days
More than
7 days
★
The second hand will resume normal movement after the indicated 5, 10, 20 or 30
seconds have elapsed.
English
7
FULL CHARGE OF THE KINETIC E. S. U.
●When the KINETIC E. S. U. is fully charged, the watch will keep operating for a
maximum of 12 to 14 days without recharging the KINETIC E. S. U.
REMARKS ON THE KINETIC E. S. U.
●Even while the second hand is stopped by pulling out the crown, current
continues being consumed by the built-in IC. Therefore, pulling out the crown will
not save the energy stored in the KINETIC E. S. U.
CAUTION
●Never install a silver oxide battery for conventional watches in place of
the KINETIC E.S.U. The battery may burst, become very hot or catch
fire.
English
8
ENERGY DEPLETION FOREWARNING FUNCTION
●When the second hand starts moving at two-second intervals instead of the
normal one-second intervals, the watch will run down in approximately 6 hours.
In this case, swing the watch from side to side to charge the KINETIC E. S. U.
sufficiently.
INSTANT-START FUNCTION
●When a long time has passed since the watch stopped, you can get it started
quickly with only a few swings.
●This function is available as long as:
1) the watch previously had more than 4 days of power reserve before it
stopped.
2) it has been left untouched for 1 to 4 weeks.
* After the watch starts operating, put it on your wrist so that it will be charged further
until the second hand moves at one-second intervals.
English
9
TIME/CALENDAR SETTING
5
Date
➠➠
➠
1
1Pull out to first click and set
the previous day’s date.
2Pull out to second click when
the second hand is at the 12
o’clock position.
3Turn to set the desired date.
4Turn to set the hands to the
desired time.
5Push back completely in
accordancewitha time signal.
CROWN
3
4
2
Second hand
English
10
ROTATING BEZEL (for models with rotating bezel)
●The rotating bezel can show up to 60 minutes of elapsed time.
1Turn the rotating bezel to align
its “ ” mark with the minute
hand.
2Readthenumberonthe rotating
bezelthattheminutehandpoints
to.
➡
Start
Elapsed
time
30 minutes
have elapsed.
* For some models, the rotating
bezel rotates only counter-
clockwise.
