ProMinent Duodos 10 User manual

Duodos 10

Air-driven double diaphragm pump

Assembly and operating instructions

A1136

Original Operating Instructions (2006/42/EC)Part number 985472 BA DUO 011 09/16 EN

Please carefully read these operating instructions before use. · Do not discard.

The operator shall be liable for any damage caused by installation or operating errors.

The latest version of the operating instructions are available on our homepage.

In order to make it easier to read, this document uses the male

form in grammatical structures but with an implied neutral sense. It

is aimed equally at both men and women. We kindly ask female

readers for their understanding in this simplification of the text.

Please read the supplementary information in its entirety.

Information

This provides important information relating to the cor‐

rect operation of the unit or is intended to make your

work easier.

Warning information

Warning information includes detailed descriptions of the haz‐

ardous situation, see

Ä Chapter 2.1 ‘Labelling of Warning Informa‐

tion’ on page 5

The following symbols are used to highlight instructions, links, lists,

results and other elements in this document:

More symbols

Symbol Description

Action, step by step.

⇨Outcome of an action.

Links to elements or sections of these instructions or other applicable documents.

nList without set order.

[Button]

Display element (e.g. indicators).

Operating element (e.g. button, switch).

‘Display /GUI’

Screen elements (e.g. buttons, assignment of function keys).

CODE Presentation of software elements and/or texts.

General non-discriminatory approach

Supplementary information

Supplemental instructions

Table of contents

1 Function and identification.................................................... 4

1.1 Function........................................................................ 4

1.2 Identification.................................................................. 4

2 Safety and Responsibility...................................................... 5

2.1 Labelling of Warning Information.................................. 5

2.2 Users' qualifications...................................................... 6

2.3 Intended use................................................................. 7

2.4 Duodos general safety notes........................................ 7

3 Transport and storage......................................................... 10

3.1 Transport.................................................................... 10

3.2 Storage....................................................................... 10

4 Assembly............................................................................ 11

4.1 Installation surroundings............................................. 11

4.1.1 Securing the double diaphragm pump..................... 12

4.2 Ambient conditions..................................................... 13

4.3 Layout of the suction side........................................... 13

4.4 Compressed air supply............................................... 14

5 Operation of the double diaphragm pump.......................... 15

6 Commissioning................................................................... 16

6.1 Checks prior to commissioning................................... 16

6.2 Priming........................................................................ 17

6.3 Interrupting operation.................................................. 17

7 Checking Tightening Torque Prior to Commissioning......... 18

8 Maintenance of the double diaphragm pump...................... 19

8.1 Troubleshooting.......................................................... 19

8.2 Air valve maintenance................................................ 20

8.3 Maintenance of the pilot valve.................................... 23

8.4 Maintenance of the ball valves................................... 24

8.5 Maintenance of the diaphragms................................. 25

9 Disposal of Used Parts....................................................... 27

10 Technical Drawing – Duodos 10......................................... 28

10.1 Exploded drawings and parts lists............................ 29

11 Spare Parts kits................................................................... 33

12 Technical data..................................................................... 34

12.1 Performance curves.................................................. 36

13 Declaration of Conformity................................................... 37

14 Index................................................................................... 38

Table of contents

1 Function and identification

1.1 Function

The Duodos is an air-driven double diaphragm pump.

The Duodos is run-dry safe and self-priming.

The pump capacity of the double diaphragm pump can be con‐

trolled by changing the pressure in the air supply. The air control is

designed for oil-free operation. The Duodos is optimally suited to

the transport of liquid chemicals.

The Duodos double diaphragm pump transports liquids to a dis‐

charge lift of 70 m. As the pump capacity depends greatly on the

back pressure, the performance curve must always be observed.

At the same time, the differential pressure between the hydraulic

and pneumatic sides must not exceed 2 bar. Higher values reduce

the service life of the double diaphragm pump.

When selecting the double diaphragm pump you must check its

material compatibility. In addition, the density, viscosity, solids con‐

tent and temperature of the liquid being transported must be con‐

sidered.

Permissible values for the medium

Temperature of the medium

–

PP version: 5 ... 65 °C

–

PVDF version: -13 ... 93 °C

Viscosity of the medium max. 200 mPas

Solids content: none

1.2 Identification

Type Housing Diaphragm Feed rate l/h Order numbers

Duodos 10 PP Santoprene®0 ... 900 1010793

Duodos 10 PVDF Teflon®0 ... 900 1010797

Function and identification

2 Safety and Responsibility

2.1 Labelling of Warning Information

These operating instructions provide information on the technical

data and functions of the product. These operating instructions pro‐

vide detailed warning information and are provided as clear step-

by-step instructions.

The warning information and notes are categorised according to

the following scheme. A number of different symbols are used to

denote different situations. The symbols shown here serve only as

examples.

DANGER!

Nature and source of the danger

Consequence: Fatal or very serious injuries.

Measure to be taken to avoid this danger.

Description of hazard

– Denotes an immediate threatening danger. If the

situation is disregarded, it will result in fatal or very

serious injuries.

WARNING!

Nature and source of the danger

Possible consequence: Fatal or very serious injuries.

Measure to be taken to avoid this danger.

– Denotes a possibly hazardous situation. If the sit‐

uation is disregarded, it could result in fatal or very

serious injuries.

CAUTION!

Nature and source of the danger

Possible consequence: Slight or minor injuries. Mate‐

rial damage.

Measure to be taken to avoid this danger.

– Denotes a possibly hazardous situation. If the sit‐

uation is disregarded, it could result in slight or

minor injuries. May also be used as a warning

about material damage.

NOTICE!

Nature and source of the danger

Damage to the product or its surroundings.

Measure to be taken to avoid this danger.

– Denotes a possibly damaging situation. If the situa‐

tion is disregarded, the product or an object in its

vicinity could be damaged.

Introduction

Safety and Responsibility

Type of information

Hints on use and additional information.

Source of the information. Additional measures.

–

Denotes hints on use and other useful information.

It does not indicate a hazardous or damaging sit‐

uation.

2.2 Users' qualifications

WARNING!

Danger of injury with inadequately qualified personnel!

The operator of the plant / device is responsible for

ensuring that the qualifications are fulfilled.

If inadequately qualified personnel work on the unit or

loiter in the hazard zone of the unit, this could result in

dangers that could cause serious injuries and material

damage.

– All work on the unit should therefore only be con‐

ducted by qualified personnel.

– Unqualified personnel should be kept away from

the hazard zone

Training Definition

Instructed personnel An instructed person is deemed to be a person who has been instructed and,

if required, trained in the tasks assigned to him/her and possible dangers that

could result from improper behaviour, as well as having been instructed in the

required protective equipment and protective measures.

Trained user A trained user is a person who fulfils the requirements made of an instructed

person and who has also received additional training specific to the system

from ProMinent or another authorised distribution partner.

Trained qualified per‐

sonnel

A qualified employee is deemed to be a person who is able to assess the

tasks assigned to him and recognize possible hazards based on his/her

training, knowledge and experience, as well as knowledge of pertinent regula‐

tions. The assessment of a person's technical training can also be based on

several years of work in the relevant field.

Electrician Electricians are deemed to be people, who are able to complete work on elec‐

trical systems and recognize and avoid possible hazards independently based

on his/her technical training and experience, as well as knowledge of pertinent

standards and regulations.

Electricians should be specifically trained for the working environment in

which the are employed and know the relevant standards and regulations.

Electricians must comply with the provisions of the applicable statutory direc‐

tives on accident prevention.

Customer Service depart‐

ment

Customer Service department refers to service technicians, who have

received proven training and have been authorised by ProMinent to work on

the system.

Safety and Responsibility

Note for the system operator

The pertinent accident prevention regulations, as well

as all other generally acknowledged safety regulations,

must be adhered to!

2.3 Intended use

CAUTION!

Intended use

Possible consequences if the instructions are not

observed: Minor injuries and material damage

– The pump is intended for liquids transport

– The pump is not intended for the transport of gas‐

eous or solid media

– Only use the pump in accordance with the tech‐

nical data and specifications outlined in the oper‐

ating instructions.

– The pump is not designed for use in areas at risk

from explosion

– Only switch the device on if it has been properly

fastened to the ground or its holding fixture.

2.4 Duodos general safety notes

WARNING!

Danger from hazardous substances!

Possible consequence: Fatal or very serious injuries.

Please ensure when handling hazardous substances

that you have read the latest safety data sheets pro‐

vided by the manufacture of the hazardous substance.

The actions required are described in the safety data

sheet. Check the safety data sheet regularly and

replace, if necessary, as the hazard potential of a sub‐

stance can be re-evaluated at any time based on new

findings.

The system operator is responsible for ensuring that

these safety data sheets are available and that they

are kept up to date, as well as for producing an associ‐

ated hazard assessment for the workstations affected.

Safety and Responsibility

WARNING!

Hazardous media / contamination of persons and

equipment

Possible consequence: Fatal or very serious injuries.

material damage

– Ensure the device is resistant to the media being

conveyed

– Always observe the safety data sheets for the

media to be conveyed. The system operator must

ensure that these safety data sheets are available

and that they are kept up-to-date

– The safety data sheets for the media being con‐

veyed are always decisive for initiating counter

measures in the event of leakage to the media

being conveyed

– Observe the general restrictions in relation to vis‐

cosity limits, chemical resistance and density

WARNING!

Service life of the diaphragm

Possible consequence: Fatal or very serious injuries

The service life of the diaphragm cannot be precisely

specified. For this reason, the possibility of fracture

and subsequent leakage of liquids must be taken into

account.

In addition, you must prevent particles from the defec‐

tive diaphragm reaching the media being conveyed.

This can be achieved e.g. by filtration, a hose rupture

alarm or other means suitable for the respective

process.

CAUTION!

Compressed air

Before working on the double diaphragm pump, close

the compressed air lines and vent the double dia‐

phragm pump.

Before undertaking any maintenance and repair work,

close off the compressed air supply, discharge the

compressed air and detach the air supply line from the

double diaphragm pump. The line to the discharge

side of the double diaphragm pump may be under

pressure and must likewise be vented.

CAUTION!

Hot surface

When conveying hot liquids, the pump can likewise

become hot. Hot surfaces may then be present on the

pump. Bear this in mind and take suitable measures to

reduce any hazards.

Safety and Responsibility

Maximum pump sound pressure level 91 dB

Depending on the operating conditions, the maximum

sound pressure level of the device can reach 88 dB ±

3 dB. Bear this in mind and take suitable measures to

reduce any impact caused by this sound pressure

level. The type and implementation of suitable meas‐

ures depends on the local circumstances and is the

responsibility of the system operator.

Check the fastening elements are correctly seated.

Before commissioning the double diaphragm pump,

you must check that all fastening elements with sealing

rings are correctly seated. The seals may ‘creep’ , so

that the fastening elements come loose over time.

In the event of a diaphragm rupture

In the event of a diaphragm rupture, the pumped

medium can enter the air system of the double dia‐

phragm pump and from there into the atmosphere. If

the pumped medium is a dangerous, harmful or toxic

substance, the air outlet must be routed to a suitable

area where safe disposal is possible.

Operation in the open air and outdoors

–

Take suitable measures to protect the device from

environmental influences when operating outside

such as:

–

UV rays

–

Humidity

–

Frost, etc.

Safety and Responsibility

3 Transport and storage

nUser qualification, transport and storage: trained user, see

Ä Chapter 2.2 ‘Users' qualifications’ on page 6

WARNING!

Danger from hazardous substances!

Possible consequence: Fatal or very serious injuries.

Please ensure when handling hazardous substances

that you have read the latest safety data sheets pro‐

vided by the manufacture of the hazardous substance.

The actions required are described in the safety data

sheet. Check the safety data sheet regularly and

replace, if necessary, as the hazard potential of a sub‐

stance can be re-evaluated at any time based on new

findings.

The system operator is responsible for ensuring that

these safety data sheets are available and that they

are kept up to date, as well as for producing an associ‐

ated hazard assessment for the workstations affected.

3.1 Transport

Transport

nThe pump is protected by means of cardboard packaging

nThe packaging materials can be recycled

nConsider the ambient conditions

3.2 Storage

The device must be completely drained before storage.

Permissible storage conditions:

All versions: + 5 °C ... 60 °C

All versions: < 95% relative air humidity (non-condensing)

Permissible operating conditions:

All versions: - 10 °C ... 40 °C

All versions: < 95% relative air humidity (non-condensing)

Transport and storage

Table of contents

Other ProMinent Water Pump manuals

ProMinent

ProMinent gamma XL User manual

ProMinent

ProMinent Makro TZ User manual

ProMinent

ProMinent Sigma/ 1 S1Ba User manual

ProMinent

ProMinent DULCOflex DFAa 003 User manual

ProMinent

ProMinent Sigma / 2 Basic S2Ba User manual

ProMinent

ProMinent von Taine 0807 PP/FKM User manual

ProMinent

ProMinent Beta BT4a Instruction Manual

ProMinent

ProMinent DULCO flex DFCa User manual

ProMinent

ProMinent DULCODOS ULIa User manual

ProMinent

ProMinent DULCO flex Control User manual

ProMinent

ProMinent Hydro/ 4 User manual

ProMinent

ProMinent alpha ALPc 1001 User manual

ProMinent

ProMinent Sigma 2 S2Ca User manual

ProMinent

ProMinent Vario d User manual

ProMinent

ProMinent Sigma 2 S2Cb User manual

ProMinent

ProMinent delta Wiring diagram

ProMinent

ProMinent Pneumados PNDb Series User manual

ProMinent

ProMinent DFB13 User manual

ProMinent

ProMinent Sigma 3 Basic User manual

ProMinent

ProMinent Dulco Flex DF2a User manual

ProMinent

ProMinent Makro/ 5 HK User manual

ProMinent

ProMinent DULCO Trans 32/700 PVDF User manual

ProMinent

ProMinent DULCO Trans 41/1200 PVDF User manual

ProMinent

ProMinent DULCO flex DFAa User manual

Popular Water Pump manuals by other brands

Neptun

Neptun NPHW 5500 operating instructions

Sensidyne

Sensidyne Gilian BDX-II Operation & service manual

Draper

Draper 47808 instructions

Trolla

Trolla 12820 manual

Sunfab

Sunfab SVH Series installation guide

WilTec

WilTec 50740 Operation manual

Fieldmann

Fieldmann FVC 5015 EK user manual

Everbilt

Everbilt EFSUB5-122HD Use and care guide

Graco

Graco Husky 3300e manual

esotec

esotec 101018 operating manual

moyno

moyno 2000 CC Service manual

Becker

Becker BASIC VASF 2.80/1-0.AC230 operating instructions

Sykes AmeriPumps

Sykes AmeriPumps GP100M Operation and maintenance instructions

DUROMAX

DUROMAX XP WX Series user manual

BRINKMANN PUMPS

BRINKMANN PUMPS SBF550 operating instructions

Franklin Electric

Franklin Electric IPS Installation & operation manual

Xylem

Xylem e-1532 Series instruction manual

Milton Roy

Milton Roy PRIMEROYAL instruction manual
