PROAIM Polaris Mini User manual

What’s In The Box

Please inspect the contents of your shipped package to ensure you have received everything that

is listed below.

No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,

electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright

statutes or in wring by the Publisher.

Assembly Manual

Polaris Mini Portable Video Camera Dolly w Universal Track Ends

| Mitchell & 75mm Bowl Mount (DL-PLRS-M01)

Proaim Mini Portable Camera Dolly

2 x End Spacers

4 x Foots

with Knobs

Bag Belt

1 x L Type Allen

Key Size: 3/16”

An-Tilt Safety Brake Bag Packing

75mm Bowl Adapter

8 x Wheels

 Loosen the knob of the End Spacers and then

mount them onto the C-Stand (Not Included)

NOTE: It comes with end-clamps that let you

attach to any compatible speed rail and can be

mounted on C-stands & tripods in seconds,

allowing you to start filming in a flash.

 To properly secure the foot to the End Spacer,

tighten it with the help of a knob. Follow the

same process on the other side.

End Spacers Assembly

 After mounting the End Spacers onto the

C-stand (Not Included), properly secure them

with the help of the knob. Then remove the

feet by loosening their knobs.

 The feet have been properly attached to the

End Spacers, as shown in the image.

 Insert washers to the feet after inserting in

the End Spacers.

 After removing the knobs of the feet, match

the feet’s bottom threads to the End Spacers’

and insert them in, as shown in the image.

 Insert a 4 track into the clamp. Once the

track is properly ed into the clamp, ghtly

secure it with the knob, as shown in the

image.

 The same process is to be followed for the

other track.

NOTE: It comes with track-ends for overall

secure and smooth track running.

An-Tilt Safety Brake Assembly

 Now place the mini portable dolly onto the 4

track. The handles part of the dolly plaorm

should be inside of the track as shown. Make

sure all wheels are aligned correctly on the

track and dolly runs smoothly.

NOTE: It comes Mitchell mount and a 75 mm

Bowl Adapter and is also compable with

100mm and 150mm Bowl Adapters, giving you

versale camera-heads mounng opons.

 The dolly plaorm already has a Mitchell

mount. To Mount the 75mm bowl adapter on

the dolly plaorm.

NOTE: Dolly has eight rolling track wheels that

run smoothly on tracks and a at surface, and it

has double ball bearings for ultra-smooth

performance.

 Then insert the screws by aligning to the

boom and properly ghten with the help of

Allen key as shown in the image.

NOTE: Proaim Polaris Mini Camera Dolly is a

compact and versale.

Polaris Mini Portable Dolly Setup

 Loosen the knob to properly open the safety

brake.

 Mount the Safety Brake on side of the Mini

portable dolly plaorm. Adjust the posion of

the bracket so it goes under the track to

prevent the plaorm from lng out.

 Properly secure with a knob aer mounng

the safety brake. Follow the same process on

the other side.

NOTE: Dolly has sturdy safety brakes you can

aach to safety es, making sure your plaorm

doesn’t get knocked o the rails.

 Remove the locking knob of the Fluid Head

(Not Included) by loosening it, then insert it

into the bowl adapter through the screw.

 After mounting the fluid head (Not Included)

on the bowl, secure it properly by inserting

the locking knob from the bottom side.

 Aer properly securing the Fluid Head

(Not Included) through the locking knob, push

the red ratchet knob to remove the uid

head’s camera plate.

Mount Fluid Head on the Bowl Adapter

 Aer removing the camera plate, aach it to

the boom of the camera (Not Included)

matching the threads.

 After attaching the plate to the camera,

properly secure it with the help of an Allen

key, then mount the camera (Not Included)

onto the Fluid Head (Not Included).

 The camera (Not Included) has now been

properly mounted on the Fluid Head

(Not Included).

NOTE: The mini dolly is compable with small

to medium-sized DSLR cameras; it is the best

lightweight product for your small producon.

NOTE: The whole dolly system is Quick & Easy

to Set up for a steady workow. It saves a lot of

your valuable producon me

YOUR PROAIM POLARIS MINI PORTABLE VIDEO CAMERA DOLLY W UNIVERSAL

TRACK ENDS | MITCHELL & 75MM BOWL MOUNT

ALL DRESSED UP AND READY TO GO!

Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,

we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it

cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon

and evaluaon by us.

Liability: We are not liable for damage caused by products that we do not supply or from mishandling in

transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.

utmost support and care unl you use our product.

(SHOWN WITH OPTIONAL ACCESSORIES)
