PROAIM CINEMA ST-HWK-01 User manual

What’s In The Box

Please inspect the contents of your shipped package to ensure you have received everything that is listed

below.

Assembly Manual

No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,

electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright

statutes or in wring by the Publisher.

Vest Jacket

Hawk Gimbal Support Rig (ST-HWK-01)

Le Shoulder Arms with 1 x Rod

Bag Packing

Right Shoulder Arms with 1 x Rod

 Fasten the buckle around your chest to adjust

the vest.

NOTE: Adjustable waist is supported by Velcro

straps and Push-t buckles, making it a

comfortable t for all body types.

Hawk Gimbal Support Setup

 Wear the vest jacket and buckle up from the

waist.

 Use the strap to ghten or loosen the chest

Velcro as per your comfort.

 Similarly, follow the same procedure to adjust

the vest area with the help of the strap.

 Adjust the vest around your waist via the

provided strap.

 Now, Loosen the vest rod knob.

NOTE: It has an adjustable vest rod with a

ratchet knob.

 Aach the le arm with the rod by inserng it

into the hole of the rod.

 Now, set the length of the rod and secure the

posion by ghtening the bolt of the power

arm using the Allen Key.

 Tighten the ring of the le arm to properly

secure it, and loosen the bolt of the power

arm using the Allen Key.

 Similarly, follow the same instrucon to

assemble the right shoulder arm.

 Insert the le arm into the jacket as shown in

the image and repeat the same process for

the right arm.

 Adjust the rod per your requirement, then

ghten using the provided knob.

 Now, loosen the locking knob of the arms to

set them as required, and then ghten the

locking knob.

 Both arms will look like this, as shown in the

image.

NOTE: There is a locked area on the top Posion

power arms to support a payload of 8-12kg/

17-26lb and hold of 14Kg/30lb at the lock area.

NOTE: The rig oers you more stability and

control over your 2 Axis Gimbals during

handheld shoong and the dual rod system

removes the X & Y axis fricons for overall

stability and balance.

 Now, the Handheld Gimbal (Not Included) is

correctly aached to the arms.

 Aach the right arm’s hook with the Velcro of

the Handheld Gimbal (Not Included) and

repeat the same with the le arm.

 Remove the quick-release plate from the

Handheld Gimbal (Not Included) by loosening

the knob.

 Push the provided pin on the Gimble plate and

remove it to aach it to the camera

(Not Included).

 Now, slide the Gimble to aach it to the

Handheld Gimbal (Not Included) and ghten

the knob to secure it.

 Secure the Gimble plate with the camera

(Not Included) by ghtening with the provided

bolt using a screwdriver.

 Aach the Camera (Not Included) with the

Gimbal (Not Included) and pull the lock lever

to secure it.

 The Gimbal (Not Included) has been properly

aached to the camera (Not Included).

YOUR PROAIM HAWK GIMBAL SUPPORT RIG

ALL DRESSED UP AND READY TO GO!

(SHOWN WITH OPTIONAL ACCESSORIES)

Dierent Angles During Wide Turning & Height Range

Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,

we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it

cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon

and evaluaon by us.

Liability: We are not liable for damage caused by products that we do not supply or from mishandling in

transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.

utmost support and care unl you use our product.
