PROAIM CINEMA Series User manual

What’s In The Box

Please inspect the contents of your shipped package to ensure you have received everything that

is listed below.

All rights reserved.

No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,

electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright

statutes or in wring by the Publisher.

Assembly Manua l

4 x 7.5ft Portable Track Sections

Bag Packing

7.5ft Track Aluminium Pipe Kit (TRK-4P)

2

7.5ft Track Aluminum Pipe Kit Setup

Interconnect the portable track secons.

Loosen the long thumbscrews of the track

ends (Not Included), insert the track rails into

them and lock the thumbscrews to secure the

track into posion.

Place the dolly platform (Not Included) onto

the track. The handles part of the dolly

platform (Not Included) should be inside the

track as shown.

NOTE: Make sure all wheels are aligned

correctly on the track, and the dolly runs

smoothly.

Loosen the knob of the break bracket

(Not Included), mount it on the side of the

dolly platform (Not Included) & tighten the

knob.

NOTE: Track can be used in lengths of 3.75ft

and 7.5ft, depending on your shot

requirements. Polaris and Flymate Dolly

(Not Included) Compatible with Track as shown

in the picture.

NOTE: Adjust the position of the break bracket

so it goes under the track to prevent the

platform from tilting.

3

YOUR PROAIM 7.5FT TRACK ALUMINUM PIPE

KIT ALL DRESSED UP AND READY TO GO!

(SHOWN WITH OPTIONAL ACCESSORIES)

Warranty: We oer one year warranty for our products from date of purchase. Within this period of

me, we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor

does it cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to

inspecon and evaluaon by us.

Liability: We are not liable for damage caused by products that we do not supply or from mishandling in

transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our

company.

Contact Us: In case of any kind of dissasfacon, please Contact us immediately and we promise our

utmost support and care unl you use our product.
