Portwell WUX Series User manual
WUX-3455/3350/4200
Copyright © Portwell 2017 WUX series User's Guide
1
NUC form factor board
Version 1.1
WUX-3455/3350/4200
WUX-3455/3350/4200
Copyright © Portwell 2017 WUX series User's Guide
2
Revision History
R1.0
Preliminary
R1.1
Fix the wrong word
WUX-3455/3350/4200
Copyright © Portwell 2017 WUX series User's Guide
3
Contents
1Introduction ............................................................................................................................................................................................................7
2Specifications .........................................................................................................................................................................................................8
2.1 Supported Operating Systems ..........................................................................................................................................................................10
2.2 Mechanical Dimensions ...................................................................................................................................................................................11
2.3 Power Consumption.........................................................................................................................................................................................13
2.4 Environmental Specifications............................................................................................................................................................................14
3 Block Diagram ...........................................................................................................................................................................................................15
4 Hardware Configuration ..............................................................................................................................................................................................16
4.1 Connector Function .........................................................................................................................................................................................16
4.2 Jumper Settings ..............................................................................................................................................................................................18
5 System Resources .....................................................................................................................................................................................................25
5.1 Intel® Apollo Lake SoC ....................................................................................................................................................................................25
5.2 Main Memory ..................................................................................................................................................................................................25
5.3 Installing the Single Board Computer.................................................................................................................................................................25
5.3.1 Chipset Component Driver ............................................................................................................................................................................26
5.3.2 Intel® HD Graphics 50X................................................................................................................................................................................26
5.3.3 Realtek RTL 8111H Gigabit Ethernet Controller..............................................................................................................................................27
6 BIOS Setup Items.......................................................................................................................................................................................................28
6.1 Introduction.....................................................................................................................................................................................................28
6.2 BIOS Setup.....................................................................................................................................................................................................28
6.2.1 Main.............................................................................................................................................................................................................30
WUX-3455/3350/4200
Copyright © Portwell 2017 WUX series User's Guide
4
6.2.2 Configuration................................................................................................................................................................................................32
6.2.3 Security...................................................................................................................................................................................................55
6.2.4 Boot..........................................................................................................................................................................................................57
6.2.5 Save & Exit.............................................................................................................................................................................................59
7 Troubleshooting....................................................................................................................................................................................................61
7.1 Hardware Quick Installation..............................................................................................................................................................................61
7.2 BIOS Setting ...................................................................................................................................................................................................64
7.3 FAQ ............................................................................................................................................................................................................65
8 Portwell Software Service...................................................................................................................................................................................67
9 Industry Specifications.........................................................................................................................................................................................68
WUX-3455/3350/4200
Copyright © Portwell 2017 WUX series User's Guide
5
Preface
This user’s guide provides information about the components, features, connectors and BIOS Setup menus available on the WUX-3455/3350/4200. This
document should be referred to when designing Intel®NUC form factor board application. The other reference documents that should be used include the
following:
Intel Apollo Lake Design Guide
Intel Apollo Lake l Specification
Please contact PORTWELL Sales Representative for above documents.
Disclaimer
The information contained within this user’s guide, including but not limited to any product specification, is subject to change without notice.
Portwell provides no warranty with regard to this user’s guide or any other information contained herein and hereby expressly disclaims any implied warranties
of merchantability or fitness for any particular purpose with regard to any of the foregoing. PORTWELL assumes no liability for any damages incurred directly or
indirectly from any technical or typographical errors or omissions contained herein or for discrepancies between the product and the user’s guide. In no event
shall PORTWELL be liable for any incidental, consequential, special, or exemplary damages, whether based on tort, contract or otherwise, arising out of or in
connection with this user’s guide or any other information contained herein or the use thereof.
Trademarks
Product names, logos, brands, and other trademarks featured or referred to within this User’s guide or the PORTWELL website, are the property of their
respective trademark holders. These trademark holders are not affiliated with PORTWELL, our products, or our website.
WUX-3455/3350/4200
Copyright © Portwell 2017 WUX series User's Guide
6
Warranty
Portwell makes no representation, warranty or guaranty, express or implied regarding the products except its standard form of limited warranty (“Limited
Warranty”). Portwell may in its sole discretion modify its Limited Warranty at any time and from time to time.
Beginning on the date of shipment to its direct customer and continuing for the published warranty period, Portwell represents that the products are new and
warrants that each product failing to function properly under normal use, due to a defect in materials or workmanship or due to non conformance to the agreed
upon specifications, will be repaired or exchanged, at Portwell’s option and expense.
Certification
PORTWELL is certified to DIN EN ISO 9001:2000 standard.
Technical Support
PORTWELL technicians and engineers are committed to providing the best possible technical support for our customers so that our products can be easily used
and implemented.
We request that you first visit our website at http://www.portwell.com.tw/support/ for the latest documentation, utilities and drivers, which have been made
available to assist you. If you still require assistance after visiting our website then contact our technical support department by email at
[email protected]for further assistance. Thank you!
WUX-3455/3350/4200
Copyright © Portwell 2017 WUX series User's Guide
7
1Introduction
Portwell Inc., a world-leading innovator in the Industrial PC (IPC) market and a member of the Intel®Embedded and Communications Alliance (Intel ECA),
, today announces the release of the WUX-3455/3350/4200/3350/4200 utilizing the Intel® NUC form factor based on the Intel® Atom™ Pentium and Celeron
Processor, includes integrated, enhanced graphics and memory controllers on 14nm process technology, delivering significant power reduction, performance
improvements and smaller platform footprint over the previous Intel® Atom™ Pentium and Celeron Processor. The WUX series can provide the low power
consumption for low profile fan-less applications such as Medical, Panel PC, POS, Print Imaging, ATM, Kiosk, Digital Security and Digital Signage.
WUX-3455/3350/4200
Copyright © Portwell 2017 WUX series User's Guide
8
2Specifications
CPU
Intel®Atom®Apollo Lake SOC, Pentium and Celeron Processor support Dual/Quad Core (up
to 10W)
With 2MB Cache
GPU
- Intel®Gen 9 Graphics supports DirectX 12, OpenGL 4.2 / OpenCL 2.0
- Video decode HW accelerator
- support for H.264, H.265, MPEG2, VC-1/WMV9, JPEG, VP8 and VP9
BIOS
AMI uEFI BIOS 64MB
System Memory
Dual Channel DDR3L 1866/1600 Non-ECC SO-DIMM up to 8GB
Storage
- 1x SATA III port
- 1x Micro-SD 3.0 socket
- Support Onboard eMMC 5.0 (default 32G / 64G by customize)
Watchdog Timer
Programmable by SIO
H/W statue monitor
- Temperature (CPU & System)
- Voltage (CPU Vcore,12V, 5V, 3.3V, 1.35V)
Expansion Interface
1x M.2 socket (E+A key) support WiFi, BT, 3G & 4G
Serial Port
1x RS-232 connector
USB
- 4x USB 3.0 ports support by stacked connector (Front + Left)
- 2x USB 2.0 ports on board with pitch 2.0 header
Audio
- High Definition Audio integrated in Intel SoC
- Realtek ALC255 HDA codec
WUX-3455/3350/4200
Copyright © Portwell 2017 WUX series User's Guide
9
- Audio jack with MIC In orLine-out
Ethernet
- Realtek RTL8111H
Display Interface
- 1x HDMI (1.4b) port on board connector, up to 3840x2160@30 MHz
- 1x DP(1.2) port on rear I/O, up to 4096x2160@60Mhz
WUX-3455/3350/4200
Copyright © Portwell 2017 WUX series User's Guide
10
2.1 Supported Operating Systems
The WUX-3455/3350/4200/3350/4200 supports the following operating systems.
Windows 10* (64 bit)
Wind River* 8.0 Linux Distribution(64 bit)
Yocto* Tool-based Embedded Linux Distribution (64 bit)
Android* 6.0(64bit)
VxWorks*7.0 (RTOS) (64 bit)
