Philips Sonicare HX3806 User manual
Cordless
Power Flosser
3000 Series
2000 Series
HX3806
HX3801
1
12
13
10
3
9
8
7
6
5
4
2
11
17
16
15
14
empty page before TOC
English
6English
Introduction
Welcome to Philips! Congratulations on your new
Sonicare Cordless Power Flosser. To fully benefit from the
support that Philips offers, register your product at
philips.com/welcome.
Important safety information
Only use the product for its intended purpose. Read this
important information carefully before you use the
product and its batteries and accessories, and save it for
future reference. Misuse can lead to hazards or serious
injuries.
Any serious incident that has occurred in relation to this
device should be reported to Philips
(www.philips.com/support) and to the competent
authority of the member state in which the user and / or
patient is established.
Note: The accessories and features of different models
vary. For example, some models come with a USB wall
adapter or are equipped with multiple modes.
Warnings
- Use only with Philips WAA1001, WAA2001 or
equivalent approved USB adapter with an output
rating of 5Vdc, 2.5W.
- Keep the charger away from water.
- This appliance can be used by children and persons
with reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they have
been given supervision or instruction concerning use
of the appliance in a safe way and understand the
hazards involved. Cleaning and user maintenance
shall not be made by children without supervision.
- Children shall not play with the appliance.
- Only use original Philips accessories or consumables.
- Do not fill the reservoir with hot water. Hot water may
cause burns.
- Do not exert excessive pressure on the nozzle tip of
the nozzle.
- To avoid physical injury, do not fill the reservoir with
hot water. Do not put foreign objects in the reservoir.
7
English
- Stop using a damaged nozzle. Replace the nozzle
every 6 months or sooner if signs of wear appear.
- This appliance contains no user-serviceable parts. If
the appliance is damaged, stop using it and contact
the Consumer Care Center in your country (see
'Warranty and support').
- Do not charge the product outdoors or near heated
surfaces.
- The maximum altitude of use is 4420 meters.
- Do not clean any part of the product in the
dishwasher.
- This product has only been designed for cleaning
teeth and gums. Do not use it for any other purpose.
(for e.g. eyes, nose and ears).
- Stop using the appliance and consult your
dentist/doctor if excessive bleeding occurs after use, if
bleeding continues to occur after 1 week of use or if
you experience discomfort or pain.
- If you have had oral or gum surgery in the previous 2
months, consult your dentist before you use this
appliance.
- If you have a pacemaker or other implanted device,
contact your doctor or the manufacturer of the
implanted device prior to use.
- If you have medical concerns, consult your doctor
before you use this appliance.
- This appliance is a personal care device and is not
intended for use on multiple patients in a dental
practice or institution.
- Charge and use the product at a temperature
between 5°C and 40°C (41°F and 104°F).
- Keep product and batteries away from fire and do not
expose them to direct sunlight or high temperatures.
- If the product becomes abnormally hot or smelly,
changes color or if charging takes longer than usual,
stop using and charging the product and contact
Philips.
- Do not place products and their batteries in
microwave ovens or on induction cookers.
8English
- Do not open, modify, pierce, damage or dismantle the
product or battery to prevent batteries from heating
up or releasing toxic or hazardous substances. Do not
short-circuit, overcharge or reverse charge batteries.
- If batteries are damaged or leaking, avoid contact
with the skin or eyes. If this occurs, immediately rinse
well with water and seek medical care.
Electromagnetic fields (EMF)
This Philips appliance complies with all applicable
standards and regulations regarding exposure to
electromagnetic fields.
Intended Use
The Philips Sonicare Cordless Power Flosser is an oral
irrigator intended to remove plaque and food debris
between teeth and on the tooth surface in order to
reduce tooth decay and improve and maintain gum
health. This product is intended for consumer home use,
normally used at least once a day. Use by children (ages
6+) should be with adult supervision.
Your Philips Sonicare Power Flosser
1 Nozzle
2 Nozzle rotator
3 Nozzle release button
4 Handle (HX381W, HX386B, HX386W)
5 On/off button
6 Intensity indicator
7 Intensity button
8 Mode indicator (Specific models only)
9 Mode button (Specific models only)
10 Battery indicator light
11 USB-C Charging port
12 In-Reservoir Nozzle storage
13 Reservoir
14 Reservoir fill door
15 Nozzle case (Specific models only)
16 Travel pouch (Specific models only)
17 USB-C Charging cable
9
English
18 USB wall adapter (100-240 , 50/60 Hz, 3.5W)
(Specific models only)
Note: Wall adapter not included. Use only with Philips
WAA1001, WAA2001 or equivalent approved USB
adapter with an output rating of 5Vdc, 2.5W
* Note:The content of the box may vary based on the
model purchased.
The following symbols may appear on the product or
package.
Read Operator’s Manual.
Consult instructions for use.
Nozzles
To see what type of nozzles you have, check the code at
the base of the nozzle. Each nozzle type provides
different benefits.
Nozzle label F1 F2 F3
Nozzle Name Standard nozzle Comfort nozzle Quad Stream
nozzle
10 English
Benefit Standard nozzle
with a single
stream of water
for removing
debris and
plaque.
Soft rubber
nozzle for
comfort and ease
of positioning for
those with
sensitive gums.
Soft rubber
nozzle that
directs water into
a cross-shaped
stream that
gently removes
plaque for an
effortlessly
thorough clean.
Note: The contents of the box may not include all items
shown depending on the product configuration
purchased.
Modes and intensities
Modes (Specific models only)
Depending on your model, your Cordless Power Flosser is
equipped with either one or two different modes. If you
have a device with two modes, press the mode button to
toggle between standard clean mode and deep clean
mode to select your desired mode. If you have a device
with one mode, it is already in the clean mode.
Clean
This mode, with pacer, provides constant water pressure
for a great clean.
15
sec.
15
sec.
15
sec.
15
sec.
The pacer indicates when you are supposed to move to
the next section of your mouth via a short pause in the
waterflow every 15 seconds.
This Cordless Power Flosser comes with the pacer
activated.
To activate or deactivate the pacer
With the Cordless Power Flosser off, press and hold the
intensity selection button for 3 seconds.
- When deactivated, the battery indicator light will
flash amber once
- When activated, the battery indicator light will flash
green twice
This manual suits for next models
