Peerless-AV KIP542B User manual

12013-08-09 #:150-9007-3 (2015-05-06)

ENG

BLACK

KIP540B

KIP542B

KIP546B

KIP547B

KIP555B

SILVER

KIP540B-S

KIP542B-S

KIP546B-S

KIP547B-S

KIP555B-S

22013-08-09 #:150-9007-3 (2015-05-06)

ENG - Do not begin to install product until you have read and understood the instructions and warnings

contained in this user guide. Always use an assistant or mechanical lifting equipment to safely lift and position

equipment. This product must be installed onto ﬂat, hard, level surface to prevent tipping. This product is

intended for indoor use only. Use of this product outdoors could lead to product failure or personal injury. To

reduce the risk of electric shock or ﬁre, do not expose product to water or moisture. Be sure power cord is routed

so that it will not be tripped on, stepped on, or pinched by heavy items. Avoid overloading electrical outlets or

extension cords. Always disconnect the power cord from the power outlet when installing, servicing, or not using

the product for an extended period of time. Do not block ventilation slots or fan exhaust on product. Blocking

airﬂow could damage product. Arrange product to allow air to ﬂow freely around product. Keep product away

from direct sunlight or any source of heat. For support please call 800-4-SIGNAGE.

WARNING

Symbols

ENG

WARNING

ENG #

Skip to step.

ENG x3

Screws must get at least three

full turns and ﬁt snug.

ENG

Front of mount.

ENG F

Do not overtighten screws.

ENG

Tools Needed for Assembly.

ENG

7/16"

(11mm)

32013-08-09 #:150-9007-3 (2015-05-06)

Parts (Before beginning, make sure you have all parts shown below).

ENG

A (1)

kiosk

J (2)

key

B (8)

M5 x 12 mm C (8)

M5 x 25 mm

D (8)

M6 x 12 mm E (8)

M6 x 25 mm

M5/M4/M6 washer

H (8)

M8 x 12 mm

F (8) M8 x 25 mm

G (8)

spacer

I (8)

K (1)

t- wrench

L (1)

power strip cable tie

M (6)

42013-08-09 #:150-9007-3 (2015-05-06)

J (2)

52013-08-09 #:150-9007-3 (2015-05-06)

2-1

2-3

2-2

Remove back door.

Remove front door.

Remove cotter pins attached

to the front door.

ENG

Remove

ENG

62013-08-09 #:150-9007-3 (2015-05-06)

7/16"

(11mm)

72013-08-09 #:150-9007-3 (2015-05-06)

E (8)

4VESA PATTERN

B (8)

I (8)

H (8)

G(8) D (8)

H (8)

G (8)

I (8)

200mm

300mm

400mm

600mm

800mm

I (8)

H (8)

F (8)

82013-08-09 #:150-9007-3 (2015-05-06)

7/16"

(11mm)

92013-08-09 #:150-9007-3 (2015-05-06)

K (1)

2 Places

4 Places

10 2013-08-09 #:150-9007-3 (2015-05-06)

7-1

Slot

ENG

Tab

ENG

Slot

ENG

Tab

ENG

J (2)

7-2

Reattach cotter pins to the

front door.

ENG

Reattach

ENG
