Panasonic CQ-C8352N User manual

ORDER NO. ACED060608C3

AUTOMOTIVE AFTERMARKET

CQ-C8352N / CQ-C7302N

WMA MP3 CD Player/Receiver with Full Dot Matrix Display

SPECIFICATIONS

Specifications*

General

Power Supply DC 12V (11V - 16V),

Test Voltage 14.4V

Negative Ground

Tone Controls (Bass/

Treble)

Bass: ±12dB at 60Hz / Treble: ±

12dB at 16kHz

Equalizer Center Frequency 60, 160, 400, 1k, 3k, 6k, 16k (Hz)

Variable Range of Equalizer -12dB to 12dB (2dB step)

Current Consumption Less than 2.2A / (CD mode; 0.5W × 4

-speaker)

Maximum Power Output 50W × 4(at 4 )

Speaker Impedance 4 - 8

Pre-amp Output Voltage

<CQ-C8352N> 5V

<CQ-C7302N> 2.5V(CD mode)

Subwoofer Output Voltage

<CQ-C8352N> 5V

<CQ-C7302N> 2.5V(CD mode)

Pre-amp Output Impedance

<CQ-C8352N> 60

<CQ-C7302N> 200

Subwoofer Output

Impedance

<CQ-C8352N> 60

<CQ-C7302N> 200

CD Player

Sampling Frequency 8 Times Oversampling

Pick-up Type Astigma 3-Beam

Light Source Semiconductor Laser

Wave Length 790 nm

Frequency Response 20Hz-20kHz (±1dB)

Signal to Noise Ratio 96dB

Total Harmonic Distortion 0.01% (1kHz)

Wow and Flutter Below Measurable Limits

Channel Separation 75dB

FM Stereo Radio

Frequency Range 87.5MHz - 108MHz

Usable Sensitivity 6dB/ V (S/N 30dB)

Stereo Separation 35dB (at 1kHz)

AM Radio(MW)

Frequency Range 531kHz - 1,602kHz

Usable Sensitivity 28dB/ V (S/N 20dB)

AM Radio(LW)

Frequency Range 153kHz - 279kHz

Usable Sensitivity 32dB/ V (S/N 20dB)

Dimensions (W×H×D)** 178×50×155mm

Weight** 1.6 kg

* Specifications and the design are subject to possible

modification without notice due to improvements.

** Dimensions and Weight shown are approximate.

** Above specifications comply with EIA standards.

Unauthorized copying and distribution is a violation of law.

1. ABOUT LEAD FREE SOLDER (PbF)

Distinction of PbF PCB:

PCBs (manufactured) using lead free solder will have a PbF stamp on the PCB.

Caution :

- Pb free solder has a higher melting point than standard solder; Typically

the melting point is 50 - 70°F (30 - 40°C) higher. Please use a soldering

iron with temperature control and adjust it to 700 ± 20°F (370 ± 10°C). In

case of using high temperature soldering iron, please be careful not to

heat too long.

- Pb free solder will tend to splash when heated too high (about 1100°F/

600°C)

- This lead free solder will be used for the products after serial No.

1,000,001.

2. FEATURES

- MP3/WMA Playback from CD-R/RW

- Fully Motorized Front Panel

- Innovated APM (Auto Preset Memory) method

- Six Preset Modes (FLAT, ROCK, POP, VOCAL, JAZZ, CLUB)

- SQ7 (7 Bands Sound Quality)

- CD Changer Control

- DVD Changer Control

- Customize the Display (Customize Function)

- Delightful sound space thanks to system buildup

- The difference among 2 models’ are mentioned below.

3. REPLACEING THE FUSE

Use fuses of the same specified rating 15 amps. Using different substitutes or fuses with higher ratings,

or connecting the unit directly without a fuse, could cause fire or damage to the stereo unit.

4. MAINTENANCE

Your products is designed and manufactured to ensure a minimum of maintenance. Use a soft cloth for

routine exterior cleaning. Never use benzine, thinner or other solvent.

5. NOTES

[RADIO BLOCK]

Do not align the AM/FM package block. When the package block is necessary, it will be supplied already

aligned at the factory.

[CD DECK BLOCK]

This model has no servo alignment points because microcomputer controls the servo circuit

6. DIMENSIONS

7. LASER PRODUCTS

8. WIRING CONNECTION

8.1. CQ-C8352N

8.2. CQ-C7302N

9. DISASSEMBLY INSTRUCTIONS

9.1. How to Remove the Flexible PCB(AP2)

9.2. How to Install the Main P.C.B. of the Electric Display

10. TERMINALS DESCRIPTION

10.1. Main Block

IC601 : C2CBKG000018

No.

Port Description (I/

(V)

FM AM CD

1 PANEL

OPEN

PANEL OPEN

detection

I 0 5.2 5.2

2 PANEL

PANEL CLOSE

detection

I 0 0 5.2

3 NC No Connection - - - -

4 BATT BATT detection I 4.8 5 5

5 ACC ACC detection I 4.8 5 5

6 SDA Electronic VOL

data

I/O 4.9 4.9 4.9

7 SCK Electronic VOL

clock

O 4.9 4.9 4.9

8 NC No Connection - - - -

9 Vss Power supply GND I 0 0 0

10 ST FM ST detection I 5.1 5.2 5.2

11 PLL DI(MO) PLL data output O 0.6 0 0

12 PLL DO(MI) PLL data input I 5.2 5.2 5.2

13 PLL CLK PLL clock output O 4.9 4.9 4.9

14 PLL CE PLL chip enable

output

O 0 0 0

15 CD RST CD deck reset

output

O 4.9 4.9 4.9

16 SUB SI SUB u-com Data

trans

SO 0.6 0.6 0.8

17 NC No Connection - - - -

18 SUB SO SUB u-com data

recept

SI 4.4 4.4 4.4

19 CH DATA CD Data recept/

FLASH W SO

SI 1.6 1.6 1.6

20 CH CLK CD clock transmit/

FLASH W CLK

SCK 4.9 4.9 4.9

21 Vdd Power supply I 4.9 4.9 4.9

22 XM SI CD Data transmit/

FLASH W SI

S0 0 0 0

23 SD SI - - - - -

24 CD SCK Clock recept from

Changer

SCK 0 0.4 0

25 CONDENSOR

Capacitor for

power supply

- 3.3 3.3 3.3

26 CD SO Data recept from

Changer

SI 0 0 0

27 CH STB Changer stororb

signal input

INT 0 0 0

28 CD IN DISC in detect I 4.9 4.9 0.4

29 DECK V

CONT

DECK power

supply control

output

O 4.9 4.9 4.9

30 CD FS Strobe signal for

CD communication

O 3.7 3.7 3.7

No.

Port Description (I/

(V)

FM AM CD

31 NC No Connection - - - -

32 Avdd Power supply of D/

A converter

I 5.1 5.1 5.1

33 AVREF Reference voltage

for D/A converter

I 5.1 5.1 5.1

34 AVGND Reference GND for

D/A converter

I 0 0 0

35 AVSS Grand for A/D and

D/A converter

I 0 0 0

36 SD FM/AM signal

meter signal input

0.2 0 0.3

37 INIT A Initializ A (CQ-

C7401U)

0 0 0

38 INIT B Initializ B A/

0 0 0

39 A IN SPE.ANA A.IN A/

0 0 0

40 Vss GND I 0 0 0

41 CD MUTE CD deck mute

detection

I 0 0 5.1

42 NC No Connection - - - -

43 NC No Connection - - - -

44 NC No Connection - - - -

45 CD SW1 CD disc in

detection

I - - -

46 CD SW2 CD disc in

detection

I - - -

47 MOD0 Operating mode

input 0

I 5.1 5.1 5.1

48 MOD1 Operating mode

input 1

I 5.1 5.1 5.1

49 MOD2 Operating mode

input 2

I 0 0 0

50 H

STANDBY

External standby

input

I 5 5 5

51 NC No Connection - - - -

52 FP

MOTOR1

Front open/close

control 1

O 4.9 5 4.9

53 FP

MOTOR2

Front open/close

control 2

O 4.9 5 4.9

54 V CNT1 Panel driving

voltage control 1

O 0 0 5

55 V

CNT2(NC)

No Connection - - - -

56 SA CLK Control for Speana

acquisition

O 5 5 4.9

57 EXT MUTE TEL/NAVI MUTE

input

I 5.3 5.2 5.2

No.

Port Description (I/

(V)

FM AM CD

58 AMP CONT External AMP

control

O 4.9 5 4.9

59 BZ-OUT Buzzer output PPG 0 0 0

60 ANT CONT Motor antenna

control

O 4.9 5 0

61 DIM1 Dimmer control

output 1

O 0 0 0

62 DIM2 Dimmer control

output 2

O 0 0 0

63 CDC REM

OUT

Remote control

code output to

Changer

O 5 5 5

64 CDC SENS CDC 1/2 detection I 5.1 5.1 5.1

65 CDC 1/2 CDC 1/2 change

output

O 0 0 0

66 NC No Connection - - - -

67 M W UP MAIN.WAKE.UP.REQ

input

I 5 4.9 5

68 NC No Connection - - - -

69 RDS CLK

70 NC No Connection - - - -

71 RDS DATA - - - -

72 MAIN

CONT

MAIN power

supply control

output

O 4.9 4.9 4.9

73 INV CONT INV power supply

control output

O 5 5 5

74 AF MUTE Tr-MUTE control O/I 5 5 5

75 RESET Reset input I 5 5 5

76 NC No Connection - - - -

77 NC No Connection - - - -

78 NC GND I 0 0 0

79 Vss GND I 0 0 0

80 X1 Crystal oscillator

input

I 2 2 2

81 X2 Crystal oscillator

output

O 2.5 2.5 2.5

82 Vdd Power supply I 5 5 5

83 P00 Pldaun port for

writing

I 0 0 0

84 P01 Pull-up port for

writing

I 5.1 5 5.1

85 VOFF DET PWR-IC OFFSET

detection

I 0 0 0

86 STBY PWR-IC STBY

control output

O 5 5 5

87 AMP MUTE PWR-IC MUTE

control output

O 0 0 0
