Panasonic CF-51 Series User manual

Personal Computer

Reference Manual

Model No. CF-51 Series

XP We recommend that this Reference Manual be printed.

Read Me First

zSome of the illustrations in this manual may differ slightly in shape from the actual items in

order to make the explanation easier to understand.

zIf the user has logged on without the administrator authority, some functions may not be

executable, and some screens may be not displayed as shown in this manual.

If this happens, log on with the administrator authority to enable these functions.

zConfirm the latest information on optional products in catalogs, etc.

zIn this manual, the following software packages are described as follows:

"WinDVD™ 5 (OEM Version)" as "WinDVD"

"B's Recorder GOLD7 BASIC" as "B's Recorder"

"B's CLiP 5" as "B's CLiP"

zThe following drives may be described as "CD/DVD drive".

DVD-ROM & CD-R/RW drive, DVD MULTI drive

zCircular media such as DVD-ROM and CD-ROM are described as "discs".

Illustrations and Terminology in this Reference Manual

NOTE NOTE provides a useful fact or helpful information.

CAUTION CAUTION indicates a condition that may result in

minor or moderate injury.

Enter

This illustration means to press the [Enter] key.

This illustration means to press and hold the [Fn] key,

then press the [F5] key.

[start] - [Run] This illustration means to click [start], then to click

[Run]. For some applications, you may need to double-

click.

Îor ⇒These symbols indicated related pages.

Î: Refer to the page in this Reference Manual

⇒: Refer to the Operating Instructions

Orange*1 If *1 is selected, it will jump to a related explanatory

note.

Key Combinations

CAUTION

zDo not press the following key combinations repeatedly in (quick) succession. Also, do

not press different key combinations quickly one after another.

zDo not press the following key combinations while using the touch pad (external

mouse) or other keys.

NOTE

zDo not press the following key combinations until you log on to Windows and the hard

disk drive indicator turns off. Note, however, that the key combinations

and

are operable in the Setup Utility.

zThe key combinations below may not work while some applications are running.

Besides, the popup window may not be displayed depending on the state of the

application you are using (e.g., when [Command Prompt] is set to "Full Screen").

Key Functions Popup Window

(Displayed after logging

on to Windows)

LCD brightness control (down)

LCD brightness control (up)

Pressing this key combination adjusts the

brightness of LCD.

The brightness setting is stored in memory

separately under the condition the AC adaptor is

connected and under the condition the AC adaptor

is not connected.

Key Combinations

Display change

(When the external display is connected)

By pressing this key combination, you can select

either an external display, internal LCD or

simultaneous. (Îpage 61)

CAUTION

zDo not press another key until the display

destination has been completely switched.

zDo not press this key combination in the

following conditions.

• When a video such as a DVD video or an

MPEG file is playing.

• When the Dualview is being utilized.

• When a game such as pinball is dis-

played.

NOTE

zWhen switching to a different user with the

Fast User Switching function, this key

operation may not work. In this case, log off

all users and restart the computer.

Key Functions Popup Window

(Displayed after logging

on to Windows)

Key Combinations

Speaker on/off switch

Pressing this key combination turns on/off audio

from the internal speakers and headphone jack.

NOTE

zDisabling the speakers will also disable the

warning beep.

zSpeakers connected to the USB port

cannot be muted.

OFF

(MUTE)

Volume control (down)

Volume control (up)

Pressing this key combination adjusts the volume

of the internal speaker and headphone jack.

NOTE

zThis key combination cannot be used to

adjust the volume of the warning beep or

speakers connected to the USB port.

Power off using the standby function

Pressing this key combination causes the current

status of the computer to be saved to memory, and

powers off the computer. (Îpage 13)

Key Functions Popup Window

(Displayed after logging

on to Windows)

Key Combinations

Remaining capacity of the battery pack

Pressing this key combination displays the

remaining battery capacity on the screen.

When the battery pack is

inserted in the computer

(example)

When the battery pack is

not inserted in the

computer

F10

Power off using the hibernation function

Pressing this key combination causes the current

status of the computer to be saved to the hard disk,

and powers off the computer. (Îpage 13)

Key Functions Popup Window

(Displayed after logging

on to Windows)

Key Combinations

There are two Fn key functions as follows:

zFn key lock function

After

is pressed once, it stays in the "pressed" position until another key is pressed.

This is convenient when it is difficult to press two buttons simultaneously.

zPopup windows display ON/OFF

1Run the Hotkey Settings.

Select [start] - [All Programs] - [Panasonic] - [Hotkey Settings].

2Set the parameters.

A. Use Fn key lock

Add the check mark if you want to enable the Fn key lock function. The following

Fn key lock function will then be enabled.

zTo use

only once:

APress

once. (Locked)

BPress another key for combination. (Lock released)

zTo use

successively:

APress

twice. (Locked)

BPress another key for combination.

Fn key remains locked until

is pressed once more.

B. Notification

This setting is only available when [Use Fn key lock] is checked.

[Make sounds when Fn key is pressed]*1

Notifies the user with a sound when

is locked or released.

[Show status on screen]:

Displays the Fn key status on the taskbar.

is locked

is not locked

C. Disable popup

Add the check mark if you want to turn the popup window display function OFF.

The full-screen display of [Command Prompt] screen or MPEG files may change

to a window display if

*2 keys are pressed. To prevent this, turn the popup

window display function OFF.

Hotkey Settings

Key Combinations

3Select [OK].

NOTE

zEach user can select separate settings for whether or not to use the Hotkey settings.

*1 If MUTE is set, you will not hear a beep.

*2 "

" indicates any function key from

F10

LED Indicators

Power status zNot lit

Power off / Hibernation mode

zGreen

Power on

zBlinking green

Standby mode

zBlinking green rapidly

Due to extremely low temperatures, power

cannot be turned on, or computer cannot

resume from standby mode.

Battery pack status Îpage 28

Caps Lock This indicator lights green when

CapsLock

pressed. Subsequent non-shifted input is

capitalized.

NumLk

(Numeric key)

This indicator lights green when

NumLk

pressed. This causes a portion of the keyboard

to function as a numeric keypad. The [Enter] key

functions differently depending on the

application.

(If an external

keyboard or ten-

keyboard is

connected to the

external keyboard/

mouse port, the

numeric keypad of

the internal

keyboard will not

operate.)

ScrLk

(Scroll lock)

This indicator lights green when

ScrLk

pressed. Scroll lock functions differently

depending on the application.

Hard disk drive status This indicator lights when the hard disk drive is

accessed.

LED Indicators

*1 MP is the abbreviation for Multimedia Pocket.

*1 Multimedia pocket device

status

zThis indicator lights when the multimedia

pocket device (floppy disk drive, DVD-ROM &

CD-R/RW drive, DVD MULTI drive etc.) is

accessed.

zThis indicator shows the status of a second

battery pack when a second battery pack is

installed in the multimedia pocket. The details

of the status display are the same as for the

main battery pack status (Îpage 28).
