Panasonic CS-HZ25YKR User manual

Operating Instructions

Air Conditioner

Before operating the unit, please read these operating

instructions thoroughly and keep them for future reference.

Before installation, the installer should:

Read the Installation Instructions, then request the customer

keep them for future reference.

Remove the remote control packed with the indoor unit.

ACXF55-33940

Operating Instructions

Air Conditioner

nanoeX

Model No.

Indoor Unit Outdoor Unit

CS-HZ25YKR

CS-HZ35YKR

CS-HZ50YKR

CS-HZ71YKR

CS-HZ80YKR

CU-HZ25YKR

CU-HZ35YKR

CU-HZ50YKR

CU-HZ71YKR

CU-HZ80YKR

English

A new built-in Network Adaptor that allows you to control

your air conditioner unit operation from anywhere.

Use the remote

control within 8 m

from the remote

control receiver

on the indoor unit.

Quick Guide

Inserting the batteries

1Pull out the back cover

of remote control.

Insert AAA or R03

batteries.

3Close the cover.

AClock setting

1Press

CLOCK

, then

press to set the

time.

• Press CLOCK for

approximately 5

seconds to show

the time as 12-hour

(am/pm) or 24-hour.

Press to conﬁrm.

POWERFUL/

ECO

Table of Contents

How to Use .......................4-6

To Learn More...

................

7-8

Cleaning the

Air Conditioner

.......................

Troubleshooting

.............

10-13

Accessories

• Remote control

• AAA or R03 batteries × 2

• Remote control holder

• Screws for remote control

holder × 2

The illustrations in this manual are for

explanation purposes only and may differ

from the actual unit. They are subject to

change without notice.

BBasic operation

Thank you for purchasing

Panasonic Air Conditioner.

Press

start/stop the

operation.

POWER

• When the unit

is ON,

disappears from

the remote control

display.

3Press TEMP UP, TEMP

DOWN to select the desired

temperature.

Down

Selection range:

16.0 °C ~ 30.0 °C /

60 °F ~ 86 °F.

• Press for approximately

10 seconds to show the

temperature as °C or °F.

2Press to select

the desired mode.

AUTO HEAT COOL

FANiAUTO-X DRY

English

nanoeX

How to Use

FAN SPEED:

• When FAN AUTO is selected, the fan speed is

adjusted automatically according to the operation

mode.

• Select the lowest fan speed to have a low noise

operation.

• When iAUTO-X mode is selected, the fan speed is

automatically set to AUTO. To adjust the fan speed,

cancel iAUTO-X mode.

QUIET:

• This operation reduces airﬂow noise.

To adjust FAN SPEED and QUIET condition

To enjoy fresher and cleaner environment

• This operation provides cleaner air, moisturises your

skin and hair, and deodorises odours in the room.

• Press nanoe™X to activate this operation, either

when the unit is ON or OFF. During nanoe™X

individual operation, the fan speed will follow the

remote control setting.

• If nanoe™X is activated before the unit is turned off,

the nanoe™X operation will resume when the unit is

turned on. This includes when TIMER ON is set.

(swing)

To adjust airﬂow direction

Upper

direction

Lateral

direction

• Do not adjust the ﬂap by hand.

*For details operation, refer “To Learn More....”

Indicators

POWERFUL/

ECO

Not used

in normal

operation.

Press to restore the

remote control to

default setting.

Press to turn

the Wireless

LAN feature

ON or OFF.

See "To Learn More..." for details.

POWERFUL:

To reach the desired temperature quickly

• This operation is automatically stop after 20 minutes.

ECO:

• To reduce power consumption for better energy saving without sacriﬁcing comfort.

• ECO function cannot be activated during iAUTO-X mode.

To switch between POWERFUL/ECO

(exit setting)

• When iAUTO-X mode is turned on, the unit automatically reduces the temperature by 2°C

(4°F) from the set temperature to accelerate the room cooling effect.

• Fan speed is set to AUTO and you cannot change the fan speed.

• After a maximum of 4 hours, the unit returns to the last set temperature. To extend iAUTO-X

operation, press again to reactivate the iAUTO-X.

• When the unit is OFF and you want to reach the desired temperature quickly, press

to turn on the unit in iAUTO-X mode.

To reach the desired temperature quickly

• For Wireless LAN Module operation setup, please refer to additional Setup

Instructions Manual.

To connect to a network

• This operation provides you with a comfortable environment while sleeping. It will

automatically adjust the sleep pattern temperature during the activation period.

• The indoor unit indicator will dim when this operation is activated. This is not applicable if

the indicator brightness has been manually dimmed.

• This operation is incorporated with the activation timer (0.5, 1, 2, 3, 4, 5, 6, 7, 8 or 9 hours).

• This operation can be set together with timer. Sleep operation has the priority over OFF

timer.

• This operation can be cancelled by pressing the respective button until the sleep timer

reaches 0.0h.

To maximise comfort while sleeping

Set temperature

iAUTO-X

-2°C /

-4°F

Max = 4 hours

How to UseEnglish

How to Use

To set the timer

You can set the timer to turn on and off the unit at 2 different preset time.

• To cancel the timer, press or to

select the respective setting or , then

press .

• If the timer has been cancelled manually or

due to power failure, you can restore the

timer again. Press or to select

the respective setting or , then press

• The nearest timer setting is displayed and

will activate in sequence.

• The timer operation follows the clock

setting on the remote control and will

repeat daily when timer has been set.

For clock setting, refer to Quick Guide.

Note

, , ,

• Can be selected at the same time. • POWERFUL, QUIET and FAN SPEED

cannot be selected at the same time.

1Select TIMER ON

or TIMER OFF.

Example:

OFF at 22:00

• Each time pressed:

(exit setting)

2Set the time.

3Conﬁrm the setting.

Energy saving temperature setting

You may save energy when operating the unit within the recommended temperature range.

HEAT : 20.0 °C ~ 24.0 °C / 68 °F ~ 75 °F.

COOL: 26.0 °C ~ 28.0 °C / 79 °F ~ 82 °F.

Air ﬂow direction

In COOL/DRY mode:

The horizontal ﬂap is ﬁxed at middle position setting.

Once the temperature is achieved, the horizontal ﬂap swings up/down automatically.

In iAUTO-X mode:

The horizontal ﬂap swings up/down automatically at a predetermined position.

Once the temperature is achieved, the horizontal ﬂap is ﬁxed at upper position.

In HEAT mode:

The horizontal ﬂap is ﬁxed at a predetermined position.

The vertical ﬂap will swing according to the selection. If the vertical ﬂap is set to auto in Heat mode,

the vertical ﬂap will swings left and right when the temperature rises.

In COOL/DRY/iAUTO-X mode:

The horizontal ﬂap swings up/down automatically.

In HEAT mode:

The horizontal ﬂap is ﬁxed to upper position when discharge air temperature is cold.

The horizontal ﬂap swings up-down automatically when discharge air temperature is warm.

The vertical ﬂap will swing according to the selection.

Auto restart control

When power is resumed after a power failure, the operation will restart automatically with the last

operation mode and airﬂow direction.

• This control is not applicable when TIMER is set.

To Learn More...

Operation mode

• It is possible to operate the indoor units individually or simultaneously. The priority of operation is

placed on the ﬁrst unit that turned on.

• During operation, HEAT and COOL modes cannot activate at the same time for different indoor

units.

• The power indicator blinks to indicate the indoor unit is standing by for different operation mode.

AUTO : The POWER indicator blinks at the initial stage.

• The unit will select an operation mode every 10 minutes depending on the setting

and room temperature.

HEAT : The POWER indicator blinks at the initial stage. The unit will take some time to warm

up.

• If the HEAT mode system has been locked, and other operation mode is selected,

the indoor unit stops and the POWER indicator blinks.

COOL : Provides efﬁcient comfort cooling to suit your needs.

DRY : Operates at low fan speed for a gentle cooling operation.

FAN : To circulate air in the room.

iAUTO-X : Provides fast cooling operation which is ideal on a hot day.

How to Use / To Learn More...English

To Learn More...

Operating conditions

Use this air conditioner in the temperature range indicated in the table.

Temperature

°C (°F)

Indoor Outdoor

DBT WBT DBT WBT

COOL

Max. 32 (89.6) 23 (73.4) 46 (114.8) 26 (78.8)

Min. 16 (60.8) 11 (51.8) -10 (14.0) -

HEAT

Max. 30 (86.0) - 24 (75.2) 18 (64.4)

Min. 16 (60.8) - -15 (5.0) -

DBT: Dry bulb temperature, WBT: Wet bulb temperature

Cleaning the Air Conditioner

nanoeX

Aluminium ﬁnFront panel

Air ﬁlters

Cleaning has to be carried out at regular

intervals to ensure the unit is at optimal

performance. A dirty unit may cause

malfunction and you may retrieve “H 99”

error code. Consult an authorised dealer.

• Before cleaning, switch off the power

supply and unplug the unit.

• Do not touch the aluminium ﬁn as the sharp

parts may cause injury.

• Do not use benzine, thinner or scouring

powder.

• Use soap ( pH 7) or neutral household

detergent only.

• Do not use water hotter than 40 °C / 104 °F.

Air ﬁlters

Once every 2 weeks

• Wash/rinse the ﬁlters gently

with water to avoid damaging

the surface.

• Dry the ﬁlters thoroughly under a shade,

away from ﬁre or direct sunlight.

• Replace any damaged ﬁlters.

Remove air ﬁlter Attach air ﬁlter

Remove from the unit Insert into the unit

Indoor unit

Wipe the unit gently with a soft

and dry cloth.

The coils and fans should be

cleaned periodically by an

authorised dealer.

Outdoor unit

Clean the debris that surround

the unit.

Clear any blockage from the

drain pipe.

Front panel

Wash gently and dry.

How to remove front panel

nanoeX

2Slide the front

panel to right

Aand pull

out B.

1Raise up.

Close it securely

nanoeX

2Match and

push in.

1Hold horizontally.

3Close down.

4Press both ends and center of the front

panel.

To Learn More... / Cleaning the Air Conditioner

Indoor unit

English

Troubleshooting

The following symptoms do not indicate malfunction.

Symptom Cause

POWER indicator blinks before the unit is

switched on.

• This is the preliminary step to prepare for the TIMER

operation after it has been set.

When Timer is set ON, the unit may start earlier (up to

35 minutes) before the actual set time to achieve the

desired temperature on time.

POWER indicator blinks during HEAT mode

with no warm air supply (and ﬂap is closed).

• The unit is in defrost mode (and AIR SWING has been

set to AUTO).

POWER indicator blinks, then stops blinking

during COOL/DRY mode.

• The system has been locked to operate in HEAT mode

only.

TIMER indicator is always ON. • When Timer has been set, the Timer setting repeats

daily.

Operation is delayed a few minutes after

restarting.

• The delay is a protection to the unit’s compressor.

Cooling/heating capacity is reduced during

lowest fan speed setting.

• The lowest fan speed is to have a low noise operation,

so cooling/heating capacity may be reduced depending

on the condition. Increase the fan speed to increase the

capacity.

Indoor fan stops occasionally during heating

operation.

• To avoid unintended cooling effect.

Indoor fan stops occasionally during automatic

fan speed setting.

• This is to help remove the surrounding odour.

Airﬂow continues even after operation has

stopped.

• To extract the remaining heat from the indoor unit

(maximum 30 seconds).

The room has a peculiar odour. • This may be due to damp smell emitted by the wall,

carpet, furniture or clothing.

Cracking sound during operation. • Changes in temperature caused the unit to expand and

contract.

Water ﬂowing sound during operation. • Refrigerant ﬂow inside the unit.

Mist emerges from indoor unit. • During cooling operation, the discharged cold air may

condense to water vapour.

Outdoor unit emits water or steam. • During cooling operation, condensation occurs on

cold pipes and the condensed water may drip from the

outdoor unit.

• During heating operation, frost formed on the outdoor

unit during deice cycle melts and is discharged as

water or steam.

Discoloration of some plastic parts. • Discoloration is subjected to the types of materials

used in plastic parts. It is accelerated when exposed to

heat, sun light, UV light or environmental factors.

Soft buzzing sound from indoor unit during

nanoe™X operation.

• It is normal when the nanoe™X generator is working.

If you are concerned about the sound, cancel the

nanoe™X operation.

Wireless LAN indicator is ON when the unit

is OFF.

• The unit’s wireless LAN connection with the router has

been activated.

This manual suits for next models

Table of contents

Other Panasonic Air Conditioner manuals

Panasonic

Panasonic CS-E18HKR User manual

Panasonic

Panasonic CW-XC103VU User manual

Panasonic

Panasonic CS-E7HKEW User manual

Panasonic

Panasonic CS-CE9LKE User manual

Panasonic

Panasonic CS-YS18TKV User manual

Panasonic

Panasonic CS-RE12NKE User manual

Panasonic

Panasonic CW-1203FR User manual

Panasonic

Panasonic CS-XE12SKUA-1 User manual

Panasonic

Panasonic CS-YZ9WKH-8 User manual

Panasonic

Panasonic CS-XE12EKE User manual

Panasonic

Panasonic CS-FZ25UKE User manual

Panasonic

Panasonic CS-XE9PKUA Installation and user guide

Panasonic

Panasonic CS-C18HKQ User manual

Panasonic

Panasonic CS-E10HB4EA User manual

Panasonic

Panasonic CS-MC12DKV User manual

Panasonic

Panasonic WH-ADC0309H3E5 Operating manual

Panasonic

Panasonic CS-C18FFP User manual

Panasonic

Panasonic CS-RE18NKE User manual

Panasonic

Panasonic CS-C281KR User manual

Panasonic

Panasonic CS-E9GFEW User manual

Panasonic

Panasonic CS-E9SD3RW User manual

Panasonic

Panasonic CU-4E23QBR User manual

Panasonic

Panasonic CS-S9NKV User manual

Panasonic

Panasonic CS-V18RKA User manual

Popular Air Conditioner manuals by other brands

Spheros

Spheros CC 355 instructions

Bosch

Bosch Climate 5000 SCI 24 CAS/ OU- OUE owner's manual

nedis

nedis ACMB1WT7 quick start guide

Samsung

Samsung AR KV Series User & installation manual

Daikin

Daikin FCFV50A Operation manual

Fujitsu

Fujitsu Inverter ASBA30JFC operating manual

Toshiba

Toshiba RAS-M10SMUV-E installation manual

Daikin

Daikin FXLQ20MAVE Operation manual

Hitachi

Hitachi RAS-E24CAK instruction manual

CIAT

CIAT Magister 2 Series Installation, Operation, Commissioning, Maintenance

Bestron

Bestron AAC6000 instruction manual

Hisense

Hisense 7K Use and Installation Instructions

Frigidaire

Frigidaire FFRE0533S1E0 Use & care guide

Samsung

Samsung AS09HM3N user manual

Frigidaire

Frigidaire CRA073PU11 use & care

Soleus Air

Soleus Air GB-PAC-08E4 operating instructions

McQuay

McQuay MCK020A Technical manual

Webasto

Webasto Frigo Top 25 DS Instructions for use
