Panasonic AW-PS301 User manual
AC Adaptor
AW-PS301
Before attempting to connect or operate this product,
please read these instructions completely.
Warning:
This equipment generates and uses radio frequency ener-
gy and if not installed and used properly, i.e., in strict
accordance with the instruction manual, may cause harmful
interference to radio communications. It has been tested
and found to comply with the limits for a Class A computing
device pursuant to Subpart J of Part 15 of FCC Rules,
which are designed to provide reasonable protection
against such interference when operated in a commercial
environment.
This digital apparatus does not exceed the Class A limits for
radio noise emissions from digital apparatus set out in the
Radio Interference Regulations of the Canadian Department
of Communications.
WARNING:
TO PREVENT FIRE OR ELECTRIC SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOIS
TURE.
The lightning flash with arrowhead sym-
bol, within an equilateral triangle, is
intended to alert the user to the pres-
ence of uninsulated "dangerous voltage"
within the product's enclosure that may
be of sufficient magnitude to constitute a
risk of electric shock to persons.
The exclamation point within an equilat-
eral triangle is intended to alert the user
to the presence of important operating
and maintenance (servicing) instructions
in the literature accompanying the appli-
ance.
The serial number of this product may be found on the bot-
tom of the unit.
You should note the serial number of this unit in the space
provided and retain this book as a permanent record of your
purchase to aid identification in the event of theft.
Model No.
Serial No.
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO
NOT REMOVE COVER (OR BACK). NO USER SER-
VICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PER-
SONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
SA 1965
SA 1966
For U.S.A
For CANADA
-1-
PRECAUTIONS
• Handle the control panel with care.
Dropping the control panel or subjecting it to a strong
shock can cause a failure or an accident.
• Operating temperature range 0°C to +38°C
Avoid using it in a cold place below 0°C or a hot place
above +38°C because low or high temperature will
adversely affect the parts inside.
• Switch power off before power cable connection or
disconnection.
Be sure to switch power off before connecting or dis-
connecting the power cable.
• Avoid outdoor use.
• Install the control panel more than 1 meter away
from the monitors.
• Care
Pull out the power cable plug, and wipe the control
panel clean with a dry cloth. If it is extremely dirty, dip
a cloth into a diluted solution of kitchen detergent,
squeeze it hard, and wipe the product surfaces care-
fully.
• Do not use benzine, paint thinner, or other volatile
liquids.
• When using a chemical duster, carefully read the
caution notes on its use.
Note
FEATURES
• This AC Adapter is for the Pan/tilt Control Panel and Hybrid Control Panel.
Applicable Control Panels: AW-RP301, AW-RP305, AW-RP501, AW-RP505
-2-
CONNECTION
AC Inlet
AC Cord
DC Cord
DC Plug
12V DC Input Connector
(DC Input Terminal)
Cord Clamp
AW-RP301
Control Panel
qPlug the supplied AC cable into the AC Inlet.
wInsert the DC plug into the DC 12V IN
Connector of the control panel.
eFasten the DC cord with the cord clamp on the
control panel to prevent the DC plug from dis-
connecting.
rInsert the AC cable plug into an AC outlet.
tPull out the AC cable from the outlet before
switching power off.
-3-
SPECIFICATIONS
Source Voltage: 120 V AC 60 Hz
Input Capacity: 20W
Power Output: 12V DC, 1.2A
Operating temperature: 0°C to +38°C (32°F to 100°F)
Dimensions: 65(W) x 138(H) x 30(D) mm, DC cable: 2m, AC cable: 3m
2-9/16”(W) x5-7/16”(H) x 1-3/16”(D)
Weight: 260 g(0.57 lbs.) (except for AC cable)
Finish: Black resin forming
Weight and dimensions indicated are approximate.
Specifications are subject to change without notice.
ACCESSORIES
AC Cable ............................................... 1
Broadcast & Television Systems Company
Division of Matsushita Electric Corporation of America
Executive Office: One Panasonic Way 2E-6, Secaucus, NJ 07094
Regional Offices:
EASTERN ZONE: 43 Hartz Way, Secaucus, NJ 07094 (201) 348-7620
CENTRAL ZONE: 1707 North Randall Road, Elgin, IL 60123 (847) 468-5200
SOUTHERN ZONE:
Atlanta Region: 1225 Northbrook Parkway, Suite 1-160, Suwanee, GA 30174
Panazip 11 (770) 338-6841, fax (770) 338-6741
Law Enforcement Video Products: 1225 Northbrook Parkway, Suite 1-160, Suwanee, GA
30174, Panazip 11 (770) 338-6844, fax (770) 338-6721
WESTERN ZONE:
Los Angeles Region: 6550 Katella Ave. 17A-1, Cypress, CA 90630 (714) 373-7271
Government Marketing Department: 52 West Gude Drive, Rockville, MD 20850 (301) 738-3840
PANASONIC CANADA INC.
5770 Ambler Drive, Mississauga, Ontario, L4W 2T3 Canada (905) 624-5010
PANASONIC SALES COMPANY
DIVISION OF MATSUSHITA ELECTRIC OF PUERTO RICO, INC.
San Gabriel Industrial Park, 65th Infantry Ave. KM. 9.5 Carolina, Puerto Rico 00630 (809) 750-4300
N1197-0 7J1A109A Printed in Japan
