OCZ ONYX 2 Series User manual
©2010 OCZ Technology Group, Inc. OCZ reserves the right
to change prices, products, or specifications without notice.
Designed to offer the best of both worlds, the
SandForce-driven Onyx 2 delivers 275MB/s
read, 265MB/s write, and up to 10,000
random write IOPS (4k aligned), without the
higher costs normally associated with similar
multi-level cell (MLC)-based solutions. The
Onyx 2 SSD delivers an enhanced computing
experience for netbooks, laptops, and home
desktops with faster application loading, snappier
data access, shorter boot-ups, and longer
battery life and feature TRIM support as the
ultimate Windows 7 upgrade. OCZ Onyx 2
SSDs feature a durable yet lightweight housing,
and because they have no moving parts are
more rugged than conventional hard discs.
Available in ample 120GB and 240GB
capacities, the Onyx 2 is an ideal hard drive
replacement for first-time SSD upgraders in
need of primary laptop storage or a spacious
application and OS boot drive.
D e s i g n & T e c h n o l o g y :
Desktop PCs
Notebooks
Netbooks
A p p l i c a t i o n s
M e c h a n i c a l S p e c i f i c a t i o n s :
O C Z O n y x 2 S e r i e s
S A T A I I 2 . 5 i n S o l i d - S t a t e D r i v e s
©2010 OCZ Technology Group, Inc. OCZ reserves the right
to change prices, products, or specifications without notice.
P E R F O R M A N C E
Max Read¹
up to 275 MB/s
Max Write¹
up to 265 MB/s
Sustained Write²
up to 240 MB/s
4KB Random Write³
10,000 IOPS
Seek Time
0.1 ms
P H Y S I C A L
Usable Capacities (IDEMA)
120GB, 240GB
NAND Components
Multi-Level Cell (MLC)
Interface
SATA II / 3Gbps
Form Factor
2.5 Inch
Controller
SandForce 1222
Dimensions (L x W x H)
99.8 x 69.63 x 9.3 mm
Weight
77g
E N V I R O N M E N T A L
Power Consumption
Idle: 0.5 Watts Active: 2 Watts
Operating Temperature
0°C ~ +70°C
Storage Temperature
-45°C ~ +85°C
Shock Resistance
1500G
Certifications
RoHS, CE, FCC
R E L I A B I L I T Y
MTBF
1.5 million hours
ECC Recovery
Up to 24 bytes correctable per 512-byte sector
Product Health Monitoring
Self-Monitoring, Analysis and Reporting Technology (SMART)
C O M P A T I B I L I T Y
Serial ATA (SATA)
Fully compliant with Serial ATA International Organization: Serial ATA Revision 2.6. Fully compliant with
ATA/ATAPI-7 Standard Native Command Queuing (NCQ)
Operating System
Windows XP 32-Bit and 64-Bit; Windows Vista 32-Bit & 64 Bit; Windows 7 32-Bit and 64-Bit;
Linux, Mac OSX (Qualified at Apple Labs)
Power Requirements
Standard SATA Power Connector
A D D I T I O N A L F E A T U R E S
Performance Optimization
TRIM (requires OS support)
Service & Support
2-Year Warranty, Toll-Free Tech Support, 24 Hour Forum Support, Firmware Updates
¹ Maximum Sequential Speeds are determined using ATTO
² Sustained transfer rate is measured using Iometer 2008, Queue Depth 32, 128KB
³ Small file I/O performance is measured using Iometer 2008, Queue Depth 32, 4KB Aligned
S p e c i f i c a t i o n s :
P A R T N U M B E R S
U P C
Onyx 2 120GB
OCZSSD2-2ONX120G
842024021193
Onyx 2 240GB
OCZSSD2-2ONX240G
842024021186
O C Z O n y x 2 S e r i e s
S A T A I I 2 . 5 i n S o l i d - S t a t e D r i v e s
