Noken SQUARE 100141901 User manual

Carretera CV-20 km.2 · 12540 Vila-real · Castellón · Spain

Tel: +34 964 50 64 50 - Fax: +34 964 50 67 93

e-mail: [email protected] · www.noken.com

SQUARE

100141901_N183050314

Rain and cascade shower head

Description

1 100267608_N240550124

2100223164_N240550106

3100223183_N240550105

4100223201_N240550107

- Please read these instructions carefully before starting installation and retain it for future reference.

Please leave this instructions with the end user.

- Remove all packaging and check the product for missing parts and damages before starting the

installation.

- Any alterations made to this product and its ﬁttings may infringe the water regulations and will

invalidate the guarantee.

- We strongly recommend the use of a qualiﬁed and registered plumber.

- In new buildings it is recommended to water ﬁll the traps to ensure toxic gases do not corrode the

surface of the taps. It is recommended that the room is well ventilated.

- Thoroughly ﬂush through all pipe work prior to the installation of terminal appliances, e.g. Shower

heads, taps, inlet valves, etc.

- Periodic cleaning and maintenance should be use to avoid the build up of damaging limestone

deposits.

- Bathroom beauty products such as liquid soap, shampoo or shower gels may damage some

materials.

16"

Drill four holes on the wall

Ø5/16” x 1_3/16”

Insert four plastic spansile

screws.

Fix plate and concealed body

with screws.

Use screws to ﬁx plate to the

wall.

Drill two holes with

diameter of 1_3/16” on

the ceramic tiles.

Make sure the concealed pipes

are at the same level with

ceramic tile,at least not

exceeding the ceramic tile.

Screw water supply

concealed pipes in the wall.

connector into the

Connect the inlet hoses to the

concealed body. Both inlets must

be water supplied independently,

not combined.

910

Aim the shower head at watersupply connector

Screw the nut until the shower head is ﬁxed.

Connect the ﬂexible hoses in the watersupply connector

Install the cover with the screws

Working pressure 7,3 - 72,5 PSI

Optimal pressure 43,5 PSI

Maximum pressure 72,5 PSI

Max. temperature 140ºF

Material Stainless steel

*We recommend the installation of the pressure valves where the high pressure is present

Pressure

(PSI)

FLOW

RATE (gpm)

0,00 0,00

7,25 1,50

14,50 2,10

29,01 2,45

43,51 2,50

58,01 2,50

72,52 2,50

0,0

0,5

1,0

1,5

2,0

2,5

3,0

0 10 20 30 40 50 60 70 80

FLOW RATE (gpm)

PRESSURE (PSI)

Pressure

(PSI)

FLOW

RATE (gpm)

0,00 0,00

7,25 1,00

14,50 1,75

29,01 2,40

43,51 2,50

58,01 2,50

72,52 2,50

0,0

0,5

1,0

1,5

2,0

2,5

3,0

0 10 20 30 40 50 60 70 80

FLOW RATE (gpm)

PRESSURE (PSI)

WATERFALL

RAIN

BRASSWARE AND ACCESSORIES

First of all we thank you for buying our products which are manufactured to the highest standards.

However in common with other products our brassware requires the correct cleaning and periodic

maintenance.

BRASSWARE SURFACES

As stated in the norm DIN EN 248 the materials used to plate brassware are Chrome, Nickel, stainless

steel, brass and others to leave a superior, easy to clean, pleasing ﬁnish. Before cleaning please

check the material used and only use a suitable cleaner.

CLEANING

To clean brassware and accessories please note the following recommendations.

- For regular cleaning only use warm soapy water, if this is not possible use soft non abrasive gels or

similar cleaning products, rinse thoroughly and polish with a soft cloth.

- Please avoid the use of harsh or abrasive products such as scouring powders, those products with

phosphoric acid, hydrochloric acid, formic acid or acetic acid that could badly damage the product.

Please only use PH neutral products.

- Dry the items after each cleaning sesion and after every use to avoid limestone appearance.

WARNING

- Cleaning materials will only worsen already damage product.

- Do not mix cleaning products, the chemical reactions can emit toxic fumes and react badly with

product surfaces.

- Do not use harsh or abrasive cloths, pads or cleaning products.

- Do not use bleach or other chlorine based cleaning products.

- Only use suitable cleaning products as recommended for each product he cleaning products only

make worse the surfaces if those are already damages.

RECOMENDATIONS FOR THE CLEANING AND PRESERVATION OF BRASSWARE AND

ACCESSORIES

- Read the manufacturers instructions.

- To protect the brassware, internal mechanism and to extend the life of the product it is recommended

in line with “best practice“ to install isolation valves and in line ﬁlters.

- Regular cleaning to reduce lime scale and soap residue build up.

- Do not leave these products in contact with the product surface longer than the manufacturer’s

recommendations and rinse thoroughly with clean water.

- Do not spray cleaning products directly onto the product surface, spray onto a soft cloth and then

apply to the product. Spraying directly onto the product can lead to cleaning ﬂuids being drawn into

the products through capillary action causing irreversible damage.

- If a tap is left dripping it may lead to staining and lime scale build up. Please ensure taps are

correctly turned o󰀨 after use.

GUARANTEE CLAUSE

- Failure to comply with the maintenance instructions may invalidate the guarantee.

This manual suits for next models
