Multimo A 235 User manual

Assembly Instructions

VIDEO

link

40min.

75 min.

Technical Service

End User

A 235- ECO BUNK

Page 1 Page 2

Accessories List

MNG - 01

46 / piece34 / piece

MNX 02

VTB - 01 (4,8x16) mm

72 / piece

KB - 01

8 / piece

KVL 01

40 / piece

TAP - 01

46 / piece

AVT - 01

6 / piece

A-L

A-R

M-R

M-L

6 / piece

MNX - 03

CT - 05 ( 6x35 ) mm

12 / piece

VD - 02 (3,5x25) mm

12 / piece

Piece T hickness Length Width Piece T hick Height Most

A20,71 10,59 23,62 2 18 269 600

B10,71 83,78 6,69 1 18 2128 170

C10,71 83,78 14,57 1 18 2128 370

D10,71 84,41 40,00 1 18 2144 1016

E10,31 82,95 12,48 1 8 2107 317

F20,71 82,36 11,81 2 18 2092 300

G10,71 13,23 11,89 1 18 336 302

H10,71 13,23 11,89 1 18 336 302

J30,71 11,81 10,94 3 18 300 278

K20,71 20,06 10,83 2 18 509,5 275

L10,71 83,78 23,62 1 18 2128 600

M20,71 56,34 40,94 2 18 1431 1040

O10,71 39,37 5,12 1 18 1000 130

Track Title

(inch)

(mm)

DSE - 02

2 / piece

DSE - 01 (40x90x32) mm

1 / piece

DD - 01 ( R10 )

3 / piece

VD - 01(6X70) mm

3 / piece

PL - 02 (8x22x1) mm

1 / piece

Page 1 Page 2

Accessories List

MNG - 01

46 / piece34 / piece

MNX 02

VTB - 01 (4,8x16) mm

72 / piece

KB - 01

8 / piece

KVL 01

40 / piece

TAP - 01

46 / piece

AVT - 01

6 / piece

A-L

A-R

M-R

M-L

6 / piece

MNX - 03

CT - 05 ( 6x35 ) mm

12 / piece

VD - 02 (3,5x25) mm

12 / piece

Piece T hickness Length Width Piece T hick Height Most

A20,71 10,59 23,62 2 18 269 600

B10,71 83,78 6,69 1 18 2128 170

C10,71 83,78 14,57 1 18 2128 370

D10,71 84,41 40,00 1 18 2144 1016

E10,31 82,95 12,48 1 8 2107 317

F20,71 82,36 11,81 2 18 2092 300

G10,71 13,23 11,89 1 18 336 302

H10,71 13,23 11,89 1 18 336 302

J30,71 11,81 10,94 3 18 300 278

K20,71 20,06 10,83 2 18 509,5 275

L10,71 83,78 23,62 1 18 2128 600

M20,71 56,34 40,94 2 18 1431 1040

O10,71 39,37 5,12 1 18 1000 130

Track Title

(inch)

(mm)

DSE - 02

2 / piece

DSE - 01 (40x90x32) mm

1 / piece

DD - 01 ( R10 )

3 / piece

VD - 01(6X70) mm

3 / piece

PL - 02 (8x22x1) mm

1 / piece

Page 3 Page 4

VIDEO

link

VIDEO

link

STEP 1

MNX - 02

STEP 2

MNG - 01

MNX - 03 x 3

KVL 01

MNX - 03

KVL-01 x 2

M-L/M-R

MNX - 02 x 7

KVL-01 x 4

KVL - 01 x 2

KVL 01

MNX - 02 x 6

KVL - 01 x 4

MNX - 03 x 4

KVL - 01 x 4

Page 3 Page 4

VIDEO

link

VIDEO

link

STEP 1

MNX - 02

STEP 2

MNG - 01

MNX - 03 x 3

KVL 01

MNX - 03

KVL-01 x 2

M-L/M-R

MNX - 02 x 7

KVL-01 x 4

KVL - 01 x 2

KVL 01

MNX - 02 x 6

KVL - 01 x 4

MNX - 03 x 4

KVL - 01 x 4

Page 5 Page 6

VIDEO

link

VIDEO

link

MNG - 01

STEP 3

210°

MNG - 01 x 6

210°

MNG - 01 x 6

MNG - 01

STEP 4

STEP 5

210°

MNG - 01 X 8

VD - 02 x 6

VD - 02 x 3

AVT - 01 x 3

VD - 02 x 3

AVT - 01 x 3

TAP - 01

Page 5 Page 6

VIDEO

link

VIDEO

link

MNG - 01

STEP 3

210°

MNG - 01 x 6

210°

MNG - 01 x 6

MNG - 01

STEP 4

STEP 5

210°

MNG - 01 X 8

VD - 02 x 6

VD - 02 x 3

AVT - 01 x 3

VD - 02 x 3

AVT - 01 x 3

TAP - 01

Page 7 Page 8

VIDEO

link

VIDEO

link

STEP 9

MNG - 01

STEP 6

STEP 8

STEP 7

210°

MNG - 01 X 2

M-R

MNG - 01 X 3

210°

MNG - 01

210°

STEP 10 210°

MNG - 01 X 7

M-L

CT - 05 x 4

STEP 11

CT - 05 x 4

MNG - 01 X 2

Page 7 Page 8

VIDEO

link

VIDEO

link

STEP 9

MNG - 01

STEP 6

STEP 8

STEP 7

210°

MNG - 01 X 2

M-R

MNG - 01 X 3

210°

MNG - 01

210°

STEP 10 210°

MNG - 01 X 7

M-L

CT - 05 x 4

STEP 11

CT - 05 x 4

MNG - 01 X 2

Page 9 Page 10

VIDEO

link

MNG - 01

STEP 12

STEP 13

210°

MNG - 01 X 12

A-R

A-L

STEP 14

CT - 05 x 2

VIDEO

link

CT - 05 x 2

TAP - 01

KB - 01

VTB - 01 x 64

Please adjust the divider piece

according to your mattrasse

length size.
