MOXA EtherDevice™ Switch

EDS-508 Hardware Installation Guide

Third Edition, March 2005

Moxa Networking Co., Ltd.

Tel: +886-2-2910-1230

Fax: +886-2-2910-1231

Web: www.moxa.com

MOXA Technical Support

Worldwide: [email protected]

The Americas [email protected]

MOXA EtherDeviceTM Switch

EDS-508 Hardware Installation Guide

The software described in this manual is furnished under a license agreement and

may be used only in accordance with the terms of that agreement.

Reproduction without permission is prohibited.

Trademarks

MOXA is a registered trademark of the Moxa Group.

All other trademarks or registered marks in this manual belong to their respective

manufacturers.

Disclaimer

Information in this document is subject to change without notice and does not

represent a commitment on the part of Moxa.

Moxa provides this document “as is,” without warranty of any kind, either

expressed or implied, including, but not limited to, its particular purpose. Moxa

reserves the right to make improvements and/or changes to this manual, or to the

products and/or the programs described in this manual, at any time.

Information provided in this manual is intended to be accurate and reliable.

However, Moxa assumes no responsibility for its use, or for any infringements

on the rights of third parties that may result from its use.

This product might include unintentional technical or typographical errors.

Changes are periodically made to the information herein to correct such errors,

and these changes are incorporated into new editions of the publication.

Table of Contents

Chapter 1 Introduction .................................................................... 1-1

Why EDS-508 is ideal for Industrial Control and Automation .1-2

Advanced Network Control Function............................1-2

Redundant Ethernet Ring Capability .............................1-2

Intelligent Network Management ..................................1-2

Industrial Grade Reliability ........................................... 1-2

Package Checklist .....................................................................1-3

Optional Accessories.................................................................1-3

Features..................................................................................... 1-4

Panel Views of EDS-508...........................................................1-5

Panel Views of EDS-508-MM/SS-SC....................................... 1-6

Panel Views of EDS-508-MM-ST ............................................ 1-7

Chapter 2 Installing MOXA EtherDevice™ Switch ....................... 2-1

Mounting Dimensions...............................................................2-2

DIN-Rail Mounting...................................................................2-3

Wall Mounting (Optional).........................................................2-3

Chapter 3 Wiring MOXA EtherDevice™ Switch............................ 3-1

Wiring Requirements ................................................................ 3-2

Grounding MOXA EDS-508 ....................................................3-4

Wiring the Relay Contact..........................................................3-4

Wiring the Redundant Power Inputs .........................................3-5

Wiring the Digital Inputs...........................................................3-5

Communication Connections....................................................3-6

RS-232 Connection........................................................3-7

10/100BaseTx Ethernet Port Connection.......................3-8

100BaseFx Ethernet Port Connection.......................... 3-10

Chapter 4 Hardware Overview ....................................................... 4-1

Redundant Power Inputs ........................................................... 4-2

Relay Contacts ..........................................................................4-2

LED Indicators.......................................................................... 4-2

Auto MDI/MDI-X Connection ................................................. 4-4

Fiber Ports.................................................................................4-4

Dual Speed Functionality and Switching..................................4-5

Switching, Filtering, and Forwarding ....................................... 4-6

Switching and Address Learning ..............................................4-6

Auto-Negotiation and Speed Sensing .......................................4-6

Specifications............................................................................4-7

Appendix A Service Information .......................................................A-1

MOXA Internet Services.......................................................... A-2

Problem Report Form............................................................... A-3

Return Procedure ..................................................................... A-4

Chapter 1 Introduction

Welcome to MOXA EtherDevice™ Switch EDS-508 series of industrial 8-Port

Managed Redundant Ethernet Switches.

The following topics are covered in this chapter:

Why EDS-508 is ideal for Industrial Control and Automation

¾Advanced Network Control Function

¾Redundant Ethernet Ring Capability

¾Intelligent Network Management

¾Industrial Grade Reliability

Package Checklist

Optional Accessories

Features

Panel Views of EDS-508

Panel Views of EDS-508-MM/SS-SC

Panel Views of EDS-508-MM-ST

EDS-508 Hardware Installation Guide

1-2

Why EDS-508 is ideal for Industrial Control and

Automation

Advanced Network Control Function

¾Multicast traffic management—IGMP Snooping function provides the

ability to manage multicast traffic.

¾Network segment planning—The VLAN function not only helps to

segment your network without being restricted by physical connections, but

is also more secure, and protects against unwanted data transmission.

¾Traffic prioritization capability—Quality of Service (QoS) provides a

traffic prioritization capability to ensure that important data gets delivered

consistently and predictably.

Redundant Ethernet Ring Capability

¾Fast recovery time (< 300 ms)—Ensures that your automation system will

be back to normal in under 300 ms when the network gets disconnected.

¾Ring Coupling for Distributed Applications—To give you more flexibility

to separate one redundant Ethernet ring into several individual rings for

distributed applications.

Intelligent Network Management

¾Automatic relay warning and E-mail warning by user-configured

event—To provide the system manager with real-time and designated alarm

messages.

¾SNMP OPC Server with HMI/SCADA software—To let control engineers

monitor the network from a central location with existing and familiar

visualization and control applications.

¾Prevent unpredictable network traffic—To give you the capability to

restrict unpredictable broadcast and multicast network traffic.

¾Web-based management—To monitor the real-time status of your network,

and better plan your industrial communications system.

Industrial Grade Reliability

¾Extended operating temperature capability—To ensure that your Ethernet

equipment can withstand harsh environmental conditions (-40 to 75°C).

Introduction

1-3

¾Industrial strength safety regulations—To ensure that your Ethernet

equipment can withstand critical industrial applications, such as in hazardous

locations (UL/cUL Class 1 division 2 and ATEX Class1 Zone 2) and comply

with FCC, TÜV, UL, and CE Standards.

¾Long-haul transmit distance of 40 km or 80 km—To extend your

transmission distance to meet fully the application criteria of Transportation

Automation, Power distribution, and Utility Automation.

Package Checklist

MOXA EtherDevice™ Switch is shipped with the following items. If any of

these items is missing or damaged, please contact your customer service

representative for assistance.

y1 MOXA EtherDevice Switch EDS-508

yHardware Installation Guide

yCD-ROM with User’s Manual and Windows Utility

yMoxa Product Warranty

yRJ45 to DB9 Console port cable

yProtective caps for unused ports

yPanel mounting kit (optional—must order separately)

Optional Accessories

yDR-4524—45W/2A DIN-Rail 24 VDC Power Supply with 85 to 264

VAC input

yDR-75-24—75W/3.2A DIN-Rail 24 VDC Power Supply with 85 to 264

VAC input

yDR-120-24—120W/5A DIN-Rail 24 VDC Power Supply with 88 to 132

VAC/176 to 264 VAC input by switch

yEDS-SNMP OPC Server Pro—CD with EDS-SNMP OPC Server

Software and manual

yADP-SCm-STf-M—Multi-mode SC male to ST female duplex adapter,

gray color

yADP-SCm-STf-S—Single-mode SC male to ST female duplex adapter,

blue color

yWK-46—Wall Mounting Kit

EDS-508 Hardware Installation Guide

1-4

Features

¾Advanced Industrial Networking Capability

yRedundant Self-Healing Ethernet Ring Capability (recovery time < 300

ms at full load)

yIGMP Snooping for filtering multicast traffic from industrial Ethernet

Protocols

ySupports IEEE 802.1Q VLAN and GVRP protocol to ease network

planning

ySupports QoS—IEEE 802.1p/1Q and TOS/DiffServ to increase

determinism

yPort Trunking for flexible network bandwidth utilization.

ySNMP V1/V2c/V3 for high security network management.

¾Designed for Industrial Applications

yBandwidth management to prevent unpredictable network status

yLock port for authorized MAC address access only

yPort mirroring for online debugging

yAutomatic warning by exception through email, relay output

yDigital inputs to integrate sensors and alarms with IP networks

yAutomatic recovery of connected device’s IP addresses

yLine-swap fast recovery (patent pending)

yRedundant, dual DC power inputs

y-40 to 75°C operating temperature range

yIP 30, rugged high-strength case

yDIN-Rail or panel mounting ability

yFor hazardous location (UL/cUL Class 1 Div. 2 and ATEX Class 1

Zone 2)

yLong-haul transmission distance of 40 km or 80 km.

¾Useful Utilities and Remote Configuration

yConfigurable by Web browser, Telnet/Serial console, Windows utility,

and SNMP

ySend ping commands to identify network segment integrity

Introduction

1-5

Panel Views of EDS-508

EDS-508

10M

100M

MASTER

COUPLER

PWR1

PWR2

FAULT

DI2

V2-

V2+

DI1

PWR1

V1+

V2-

RELAY2

RELAY1

V1 V2 INPUTS: 24 VDC

P.G.

RS-232

CONSOLE

1. Grounding screw

2. Console port

3. Heat dissipation orifices

4. 6-pin terminal block for DI 1, DI 2, and

PWR 2

5. 6-pin terminal block for PWR1, Relay 1,

and Relay 2

6. 10/100BaseT(X)Port 8

7. 10/100BaseT(X)Port 7

8. PWR 1, power input 1 LED

9. PWR 2, power input 2 LED

10. Fault LED

11. MASTER LED

12. COUPLER LED

13. Turbo Ring inside Mark

14. 10/100BaseT(X) Port

15. TP port’s 100 Mbps LED

16. TP port’s 10 Mbps LED

17. Model Name

18. Screw hole for Wall Mounting Kit

19. DIN-Rail Kit

EDS-508 Hardware Installation Guide

1-6

Panel Views of EDS-508-MM/SS-SC

EDS-508-MM-SC

10M

100M

MASTER

COUPLER

PWR1

PWR2

FAULT

DI2

V2-

V2+

DI1

PWR1

V1+

V2-

RELAY2

RELAY1

V1 V2 INPUTS: 24 VDC

P.G.

RS-232

CONSOLE

NOTE: The appearance of EDS-508-SS-SC is

identical to EDS-508-MM-SC.

1. Grounding screw

2. Console port

3. Heat dissipation orifices

4. 6-pin terminal block for DI 1, DI 2, and

PWR 2

5. 6-pin terminal block for PWR1, Relay 1,

and Relay 2

6. 100BaseFX Port 8

7. 100BaseFX Port 7

8. PWR 1, power input 1 LED

9. PWR 2, power input 2 LED

10. Fault LED

11. MASTER LED

12. COUPLER LED

13. Turbo Ring inside Mark

14. 10/100BaseT(X) Port

15. TP port’s 100 Mbps LED

16. TP port’s 10 Mbps LED

17. Model Name

18. Screw hole for Wall Mounting Kit

19. DIN-Rail Kit

Table of contents

Other Moxa Technologies Network Router manuals

Moxa Technologies

Moxa Technologies E Series User manual

Moxa Technologies

Moxa Technologies ioLogik E2200Series User manual

Moxa Technologies

Moxa Technologies EDR-8010 Series User manual

Moxa Technologies

Moxa Technologies EDS-518E User manual

Moxa Technologies

Moxa Technologies NPort IA5150 series User manual

Moxa Technologies

Moxa Technologies NAT-102 Series User manual

Moxa Technologies

Moxa Technologies ToughNet TN-5308-4 Manual

Moxa Technologies

Moxa Technologies Managed Ethernet Switch/Extender User manual

Moxa Technologies

Moxa Technologies AirWorks AWK-1137C-EU User manual

Moxa Technologies

Moxa Technologies PowerTrans PT-7728 Manual

Moxa Technologies

Moxa Technologies ETHERDEVICE EDS-308 Manual

Moxa Technologies

Moxa Technologies EDS-518E User manual

Moxa Technologies

Moxa Technologies EtherDevice EDR-G903 User manual

Moxa Technologies

Moxa Technologies OnCell G4302-LTE4 Series User manual

Moxa Technologies

Moxa Technologies EtherDevice EDS-P506A-4PoE Series Manual

Moxa Technologies

Moxa Technologies AWK-4121 User manual

Moxa Technologies

Moxa Technologies EDR-G9010 Series User manual

Moxa Technologies

Moxa Technologies EtherDevice EDR-G902 Manual

Moxa Technologies

Moxa Technologies EtherDevice EDR-G903 User manual

Moxa Technologies

Moxa Technologies OnCell 5004-HSPA User manual

Moxa Technologies

Moxa Technologies EDS-210A-1GTX-1GSFP-4SFP User manual

Moxa Technologies

Moxa Technologies EtherDevice EDS-G205A-4PoE Manual

Moxa Technologies

Moxa Technologies PT-7528 User manual

Moxa Technologies

Moxa Technologies EtherDevice EDR-G902-T User manual

Popular Network Router manuals by other brands

Allnet

Allnet ALL0333AU user guide

HomeSeer

HomeSeer HT-SEL Getting started guide

Sercomm

Sercomm Genesis OC3505D Quick installation guide

Billion

Billion BIPAC 5102 Series user manual

TP-Link

TP-Link TD-8817 QIG

Motorola

Motorola MR1900 user guide

Digi

Digi IX14 user guide

Cisco

Cisco NCS 540 Hardware installation guide

XAVi

XAVi X8821e user manual

BEC

BEC 6200WZL Quick installation guide

MikroTik

MikroTik hAP ac3 Series quick start

Korenix

Korenix JetNet 5428G Series user manual

NETGEAR

NETGEAR FS526T - Switch installation guide

Korenix

Korenix JetNet 5710G Series user manual

Automated Logic

Automated Logic ZN551 Technical instructions

Cisco

Cisco ASR 1000 Series Installation and configuration guide

EnGenius

EnGenius ESR-9710 quick start guide

Cisco

Cisco 805 Series Product overview
