Montpellier MVSD7W User manual

Freestanding Vented Tumble Dryer

MVSD7W - White - 7kg - Sensor Dry

Please read these instructions carefully before attempting to install or use this appliance.

We recommend that you keep these instructions in a safe place for future reference.

Installation and Operating Instructions

THE PERFECT BALANCE OF FUNCTION AND STYLE

LAUNDRY - DISHWASHING - COOKING - COOLING

Thank you for choosing this Montpellier Tumble Dryer.

Our Dryers have been designed to provide you with the best combination of style, reliability and performance to

give you years of trouble-free use.

You may be familiar with a similar product, but please take time to read these instructions carefully before installing

or using your Dryer to ensure you get the most from your purchase.

We recommend that you keep this manual in a safe place for future reference.

Your Vented Tumble Dryer is covered by a comprehensive two year parts &

labour guarantee. In the unlikely event that you experience a problem with

your Dryer, you can rest assured that you are fully protected against the cost

of repairs for the first 24 months . Please note that any claim must be

accompanied by the model reference number, serial number and proof of

purchase.

To activate your guarantee, you will need your product serial number. This can

be found on the rear of the machine.

There are two ways to register your Guarantee:

•

Online: Visit the Support page on our website and complete the online Product

Registration form. www.montpellier-appliances.com

By Post: Simply detach and fill in the form provided, attach a stamp and send it

in the post. Don’t forget to include your e-mail address so that we can send

confirmation through to you.

Welcome

Note: We are unable to take registrations over the phone.

ACROSS ALL OUR MODELS

YEAR

GUARANTEE

PA R T S & L A B O U R

www.montpellier-appliances.com

SAFETY INSTRUCTIONS

Safety Instructions ..................................................

INSTALLATION

Product Description ................................................

Installation ...........................................................

OPERATIONS

Quick Start .............................................................

Before Each Drying ..................................................

Control Panel .........................................................

Drying Programmes Table .....................................

MAINTENANCE

Cleaning And Care .................................................

Trouble Shooting ....................................................

Technical Specifications .........................................

Product Fiches ........................................................

CONTENTS

SAFETY INSTRUCTIONS

Safety Instructions

• The appliance is not intended for use by persons (including

children) with reduced physical, sensory or mental capabilities,

or lack of experience and knowledge, unless they have been

given supervision or instruction concerning use of the

appliance by a person responsible for their safety.

• Children should be supervised to ensure that they do not play

with the appliance.

• If the power cable is damaged, it must be replaced by the

manufacturer, its service agent or similarly qualified persons in

order to avoid a hazard.

•In EN standard countries, this appliance can be used by

children from 8 years and above and persons with reduced

physical, sensory or mental capabilities or lack of experience

and knowledge if they have been given supervision or

instruction concerning use of the appliance in a safe way and

understand the hazards involved.

• Children shall not play with the appliance, cleaning and user

maintenance shall not be made by children without supervision.

• The tumble dryer is not to be used if industrial chemicals have

been used for cleaning.

• The lint trap has to be cleaned frequently.

• Lint must not to be allowed to accumulate around the tumble

dryer.

• Do not dry unwashed items in the tumble dryer.

• Items that have been soiled with substance such as

cooking oil,acetone, alcohol, petrol, kerosene, spot

removers, turpentine, waxes and wax removers should be

washed in hot water with a extra amount of detergent

before being dried in the tumble dryer.

SAFETY INSTRUCTIONS

• Items such as foam rubber (latex form), shower caps,

waterproof textiles, rubber backed articles and clothes or

pillows fitted with foam rubber pads should not be dried

in the tumble dryer.

• Fabric softeners, or similar products, should be used as

specified by the fabric softener instructions.

• The exhaust air must not be discharged into a flue which

is used for exhausting fumes from appliance burning gas

or other fuels.

• The appliance must not be install behind a lockable door

a sliding door or a door with a hinge on the opposite side ,

to that of the tumble dryer. In such a way that a full

opening of the tumble dryer door is restricted.

• Oil-affected items can ignite spontaneously, especially

when exposed to heat sources such as in a tumble dryer.

The items become warm, causing an oxidation reaction in

the oil.Oxidation creates heat. If the heat cannot escape,

the items can become hot enough to catch fire. Piling,

stacking or storing oil-affected items can prevent heat

from escaping and so create a fire hazard.

• The appliance should not be overturned during normal

use or maintenance.

• Remove all objects from pockets such as lighters and

matches.

Never stop a tumble dryer before the end of the drying

cycle unless all items are quickly removed and spread

out so that the heat is dissipated.

Warning!

SAFETY INSTRUCTIONS

Correct Disposal of this product:

This marking indicates that this product should not

be disposed with other household wastes throughout

the EU. To prevent possible harm to the environment

or human health from uncontrolled waste disposal,

recycle it responsibly to promote the sustainable

reuse of material resources. To return your used

device, please use the return and collection systems

or contact the retailer where the product was

purchased. They can take this product for

environmental safe recycling.

Model Rated capacity

7.0kg

MVSD7W

• For appliances with ventilation openings in the base, that

a carpet must not obstruct the openings.

• Children of less than 3 years should be kept away unless

continuously supervised.

• Plug must be accessible after installation.

• Warning: The appliance must not be supplied through an

external switching device, such as a timer, or connected to

a circuit that is regularly switched on and off by a utility.

• Remove all packages before using the appliance.

Otherwise,serious damage may result.

SAFETY INSTRUCTIONS

Power supply and grounding•

Grounding

The dryer employs alternative current with the rated voltage and frequency. When the

voltage fluctuates between 6% of rated voltage, the dryer can work normally.

A special power socket with a capacity 10A for the dryer had better be set beside the

dryer for convenience and safety. The method of connection of the

socket is as the figure below.

To be safe, please make improvements as soon as possible

according to the rules and suggestions mentioned above.

The socket and the grounding wire must be installed by an electrician to prevent

incorrect installation or use of the socket and to guarantee the safety of use of

electricity. No connection of the grounding wire and the neutral wire, otherwise the

cabinet will be charged, which is likely to cause the danger of electric shock.

• Precautions

Install or store where it will not be exposed

to temperatures below freezing or exposed

to water or weather, which could cause

permanent damage and invalidate the

warranty.

Keep area around the exhaust opening and

adjacent surrounding areas free from the

accumulation of lint, dust and dirt. An

obstructed port might reduce the airflow.

Thoroughly spin the laundry in washing

machine. High spin speed can reduce the

drying time and save energy consumption.

Make sure combustible sprayer will not be

close to dryer when it is working, and once

the gas leaks, do not touch plug or

start/pause on it.

≥

Warning!

！

CONTENTS

Do not wash or dry articles that have been

cleaned in, washed in, soaked in or spotted

with combustible or explosive substances

( such as wax, oil, paint, gasoline, degreasers,

dry-cleaning solvents, kerosene, etc.).

Never attempt to operate this appliance if it

is damaged, malfunctioning, partially

disassembled,or has missing or broken parts,

including a damaged cord or plug.

Do not allow children on or in the appliance.

Close supervision of children is necessary

when the appliance is used near children.

Please do not use the machine when your

foot or hand with water.

Do not store plastic, paper or clothing that

may burn or melt on top of the dryer during

operation.

The exhaust air must not be discharged into

a flue which is used for exhausting fumes

from appliance burning gas or other fuels.

Do not dry articles containing rubber, plastic

or similar materials such as padded bras,

tennis shoes, galoshes, bath mats, rugs, bibs,

baby pants, raincoat plastic bags or pillows

that may melt or burn. Some rubber

materials, when heated, can under certain

circumstances produce fire by spontaneous

combustion.

The door can be opened only after the

programme of the drying machine is

completed.Do not open the door before the

programme finished to avoid the human

skin from being scalded by hot steam or over

heated drying machine.

Top board

Control panel

Door

Front panel

Side panel

Filter

Flexible duct

Power plug

Switch

Tumble Door

>10cm

INSTALLATION

Product Description

Installation

Note: Please see the products you purchased in kind prevail.

Dryer should be placed in a ventilated area with

than 10cm distance from the wall. It is suggested there

are no obstacles within 1.5m in front of dryer and keep

ventilated.

not less

•Installation Position Selection

INSTALLATION

the dryer will work unbalanced or stop working sometimes.

if dryer could not be placed horizontally (the lean angle is no more than 2°,

Notice when installing:

• Do not install the dryer in the open air or place easily

damaged by rain;

• Do not place the back of dryer near curtain or something

in the wind;

• Do not place the dryer near gas or flammable area.

•

• Connect one end of flex tube with whorl to the back vent, then fix it deasilly till tight.

• The other end of flex tube will be extended to outdoor, please refer the right

assemble way to the below pictures.

Flex tube fixing:

Note!

•Level Adjusting

Once in its permanent operating position,

check that the dryer is absolutely level with the aid

of a spirit level. If it is not, adjust the feet with a tool.

Other manuals for MVSD7W

Table of contents

Other montpellier Dryer manuals

montpellier

montpellier MHP8SDW User manual

montpellier

montpellier MVSD7W User manual

montpellier

montpellier TCS8 User manual

montpellier

montpellier MHP10SDW User manual

montpellier

montpellier MTDSC8W User manual

montpellier

montpellier MTDI7S User manual

montpellier

montpellier MSD2800W User manual

montpellier

montpellier MIHP75 User manual

montpellier

montpellier MCSD7K User manual

montpellier

montpellier MCD7W User manual

montpellier

montpellier MTDC8SDW User manual

montpellier

montpellier MTD30P User manual

montpellier

montpellier MTDSC7W User manual

montpellier

montpellier MTD30P User manual

montpellier

montpellier MTDAD3P User manual

montpellier

montpellier MTD30P User manual

Popular Dryer manuals by other brands

Bosch

Bosch WTA79200GB Installation and operating instructions

Amana

Amana W10233410A Use and care guide

Miele

Miele TWH 780 WP operating instructions

Asko

Asko T760 user guide

Alliance Laundry Systems

Alliance Laundry Systems 25 Series Original instructions

Bosch

Bosch Logixx 10 WTB76556GB Instruction manual and installation instructions

STIEBEL ELTRON

STIEBEL ELTRON Ultronic S Operation and installation

Electrolux

Electrolux EW2H328R2 user manual

Beko

Beko DS8433RX1M user manual

Dawlance

Dawlance Spinner DS 6000 C owner's manual

Electrolux

Electrolux TP5080TW user manual

AEG

AEG TR838P4OB user manual

Indesit

Indesit IDV 75 instruction manual

Infiniton

Infiniton SD-DG85C manual

BOMANN

BOMANN WT 5019 instruction manual

Alliance Laundry Systems

Alliance Laundry Systems TMB795C Installation

Asko

Asko T793C operating instructions

Kenmore

Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer installation instructions
