Operating Instructions
Dolphin PROX2 GYRO Pool Cleaner
Dolphin PROX 2 Gyro Pool Cleaner | Operating Instructions 1
Contents
1. INTRODUCTION .............................................................................3
2. SPECIFICATIONS ............................................................................3
3. WARNINGS AND CAUTIONS........................................................3
3.1. Warnings................................................................................3
3.2. Cautions.................................................................................3
4. POOL CLEANER PARTS..................................................................4
5. USING THE POOL CLEANER.........................................................5
5.1. Setup......................................................................................5
5.2. Putting the Pool Cleaner into the pool...............................6
5.3. Removing the Pool Cleaner from the pool.........................6
5.4. Maintenance..........................................................................7
5.5. Off season storage................................................................8
6. POWER SUPPLY...............................................................................9
7. REMOTE CONTROL UNIT..............................................................10
Dolphin PROX 2 Gyro Robotic Pool Cleaner
Operating Instructions
Dolphin PROX 2 Gyro Pool Cleaner | Operating Instructions 3
Dolphin PROX 2 Gyro Pool Cleaner
Operating Instructions
1. INTRODUCTION
Thank you for purchasing a Maytronics Robotic Pool Cleaner.
We are sure that your Maytronics Robotic Pool Cleaner will provide you with reliable, convenient and
cost effective pool cleaning. Its reliable filtration in all pool conditions and all-surface climbing brush
enhance maximum pool hygiene.
The Robotic Pool Cleaners by Maytronics deliver advanced cleaning technologys, long lasting
performance and easy maintenance.
2. SPECIFICATIONS
Motor protection: IP 68
Minimum depth: 0.80m/2.6ft
Maximum depth: 5m/16.4ft
3. WARNINGS AND CAUTIONS
3.1. Warnings
• Use the originally supplied power supply only
• Ensure the electrical outlet is protected by a ground fault interrupter (GFI) or an earth
leakage interrupter (ELI)
• Keep the power supply out of standing water
• Position the power supply at least 3m/10ft away from the edge of the pool
• Do not enter the pool while the pool cleaner is working
• Unplug the power supply before servicing
3.2. Cautions
When not in use store the Pool Cleaner on the Caddy in a shaded area.
Use the Pool Cleaner in the following water conditions only:
Chlorine Max 4 ppm
pH 7.0 - 7.8
Temperature 6 – 34°C (43-93°F)
NaCl Maximum = 5000 ppm
CAUTION
4Dolphin PROX 2 Gyro Pool Cleaner | Operating Instructions
Bottom lid and filter Bag
Caddy
Power Supply
Unit
Remote Control Unit
Dolphin
PROX 2 Gyro
Wonder Brush
For smooth ceramics.
(optional)
Combined Brush
For rough ceramics.
Surface and mosiac tiles.
Filter bag options:
Fine - default
Ultra fine - extra
4. POOL CLEANER PARTS
Dolphin PROX 2 Gyro Pool Cleaner | Operating Instructions 5
Change diagonal handle position for
water line sideway movement.
To adjust the handle angle:
A. Press the latch down and hold it
in position.
B. Move the handle to the desired
position and release the latch to
hold the handle in place.
GFI/ELI
40°C Max
104°F Max
B
A
A
3
4
1
2
B
5. USING THE POOL CLEANER
5.1. Set Up
6Dolphin PROX 2 Gyro Pool Cleaner | Operating Instructions
Turn the power supply ON
ON
OFF
5.2. Putting the Pool Cleaner into the pool
5.3. Removing the Pool Cleaner from the pool
The robot will perform automatic shut-off at the end
of the cleaning cycle.
Turn Off and unplug the power supply
CAUTION
If Wonder brush/ Wonder rings are dry,
soak them in water until soft.
Dolphin PROX 2 Gyro Pool Cleaner | Operating Instructions 7
Using the floating cable, bring the Pool Cleaner to the pool’s edge.
Clean the filter bag with a hose.
Periodically clean the brushes with a hose.
It is recommended to periodically wash
the filter bag in a washing machine.
Use gentle cycle program.
CAUTION
5.4. Maintenance
DO NOT PULL THE POOL CLEANER FROM THE POOL USING THE CABLE
8Dolphin PROX 2 Gyro Pool Cleaner | Operating Instructions
To remove the
kinks, stretch
the cable out
completely and let
it sit for at least a
day in the sun.
If you notice debris
trapped in the
impeller open
the impeller and
remove the debris.
If the pool cleaner will not be in use for an extended
period, perform the following storage steps:
• Make sure that no water is left in the pool cleaner.
• Thoroughly clean the filter bag and insert in place.
• Roll up the cable so that it has no kinks and place on
the Caddy.
• Store the pool cleaner in a protected area either
on its Caddy or simply upsidedown.
5.5. Off season storage
Cleaning the impeller
Unplug the power supply
Cable
