Maytronics MCC6 User manual

8151890

User Instructions

Robotic Pool Cleaner MCC6/MTC6

MCC6

MTC6

Contents

1. INTRODUCTION ....................................................................... 2

2. SPECIFICATIONS ...................................................................... 2

3. WARNINGS AND CAUTIONS ................................................... 2

3.1. Warnings............................................................................ 2

3.2. Cautions............................................................................. 2

4. POOL CLEANER PARTS ............................................................ 3

5. USING THE POOL CLEANER.................................................... 4

5.1. Setup.................................................................................. 4

5.2. Putting the Pool Cleaner into the pool.............................. 6

5.3. Removing the Pool Cleaner from the pool........................ 7

6. CLEANING THE FILTER BAG OR CARTRIDGES ....................... 8

6.1. Removing and cleaning the ﬁlter bag ................................ 8

6.2. Replacing the ﬁlter bag ..................................................... 9

6.3. Cleaning the ﬁlter cartridges ............................................. 9

6.4. Cleaning the impeller ........................................................ 10

7. OFFSEASON STORAGE............................................................ 11

8. TROUBLESHOOTING................................................................ 12

Robotic Pool Cleaner MCC6/MTC6

User Instructions

2Robotic Pool Cleaner MCC6/MTC6 |User Instructions

Robotic Pool Cleaner MCC6/MTC6

User Instructions

1. INTRODUCTION

Thank you for purchasing a Maytronics Robotic Pool Cleaner.

We are sure that your Maytronics Robotic Pool Cleaner will provide you with reliable, convenient and

cost effective pool cleaning. Its reliable ﬁltration in all pool conditions, active brushing, and all-surface

climbing brush enhance maximum pool hygiene.

The Robotic Pool Cleaners by Maytronics deliver advanced cleaning technologies, long lasting

performance and easy maintenance. You and your family will be free to enjoy your swim with full

conﬁdence that your pool is completely clean.

2. SPECIFICATIONS

Motor protection: IP 68

Minimum depth: 0.4 m (1.33 ft)

Maximum depth: 5 m (16.4 ft)

3. WARNINGS AND CAUTIONS

3.1. Warnings

• Use the originally supplied power supply only

• Ensure the electrical outlet is protected by a ground fault interrupter (GFI) or an earth

leakage interrupter (ELI)

• Keep the power supply out of standing water

• Position the power supply at least 3.5 m (12 ft) away from the edge of the pool

• Do not enter the pool while the Pool Cleaner is working

• Unplug the power supply before servicing

• Keep the Robotic Pool Cleaner out of the reach of children or persons with reduced

physical, sensory, or mental capabilities, or lack of experience and knowledge, unless

they have been given supervision or instruction.

3.2. Cautions

When not in use store the Pool Cleaner on the Caddy in a shaded area.

Use the Pool Cleaner in the following water conditions only:

Chlorine Max 4 ppm

pH 7.0 - 7.8

Temperature 6 °C – 35 °C (43 °F – 95 °F)

NaCl Maximum = 5000 ppm

CAUTION

Robotic Pool Cleaner MCC6/MTC6 |User Instructions 3

4. POOL CLEANER PARTS

Robotic Pool Cleaner Model MCC6

Frame Cartridges and 4 ultra-ﬁne ﬁlters Spring clean-up ﬁlters Bottom lid and ﬁlter Bag

optional

Combined Brush

For rough ceramic

surface and mosiac tiles.

PVC Brush

For concrete, PVC,

ﬁberglass and liner.

Wonder Brush

For smooth ceramics.

Optional Brushes

Wonder Brush

For smooth ceramics.

Combined Brush

For rough ceramic

surface and mosiac tiles.

PVC Brush

For concrete, PVC,

ﬁberglass and liner.

Optional Brushes

Brushes

Filtration

Power supply unit

Robotic Pool Cleaner Model MTC6

4Robotic Pool Cleaner MCC6/MTC6 |User Instructions

5. USING THE POOL CLEANER

The Pool Cleaner is very simple to use. Simply put it into the pool and make sure that it is properly

sitting on the ﬂoor of the pool. Turn it ON and let it get the job done.

5.1. Setup

Before using the Pool Cleaner for the ﬁrst time perform the following steps:

Unwind the cable and stretch it out

completely so that it has no kinks.

Some models arrive with plastic coverings on the brushes.

Remove them before use.

While pushing in the handle buttons turn the ring so that the large projection on the ring lines up with

the projection on the Pool Cleaner body.

Robotic Pool Cleaner MCC6/MTC6 |User Instructions 5

While pushing the button on each

ﬂoat pull it all the way out.

Position the power supply so that it is

approximately in the middle of the long side

of the pool at a distance of 3.5 m (12 ft).

Attach the ﬂoating cable to the power supply

by inserting it with the notch on the connector (1)

lined up with the groove in the socket on the

power supply and turning clockwise (2).

Plug in the power supply and leave it in the OFF position.

Click Click

3.5 m (12 ft)

6Robotic Pool Cleaner MCC6/MTC6 |User Instructions

5.2. Putting the Pool Cleaner into the pool

Holding the Pool Cleaner upside down in

the water gently rock it back and forth with

your ﬁngers holding the plastic doors on

the bottom lid open to release trapped

air. Continue until no more bubbles are

released.

If your Pool Cleaner is equipped with brushes that

contain sponges, dip the brushes in the water and

squeeze them so that they will absorb water the ﬁrst time

you use the Pool Cleaner, or if the brushes have dried out

between uses.

Release the Pool Cleaner and let it sink to the ﬂoor of the

pool.

Make sure that the ﬂoating cable is free of any

obstructions.

To avoid kinks in the ﬂoating cable, place approximately

enough cable in the water for the Pool Cleaner to reach

the farthest corner of the pool.

Turn the power supply ON.

The Pool Cleaner will now operate until it has

reached the end of the cleaning cycle.

Robotic Pool Cleaner MCC6/MTC6 |User Instructions 7

5.3. Removing the Pool Cleaner from the pool

CAUTION

Turn OFF and unplug the power supply

Using the ﬂoating cable, bring the Pool Cleaner to the pool’s edge.

Using the handle remove the Pool Cleaner from the pool.

CAUTION

DO NOT PULL THE POOL CLEANER FROM THE POOL USING THE CABLE.

Place the Pool Cleaner on the edge of the pool and let the

water drain out.

OFF

8Robotic Pool Cleaner MCC6/MTC6 |User Instructions

6. CLEANING THE FILTER BAG OR CARTRIDGES

Depending on the model, your Pool Cleaner may be equipped with a ﬁlter bag or cartridges.

It is recommended to clean the ﬁlter bag or cartridges after each cleaning cycle.

6.1. Removing and cleaning the ﬁlter bag

CAUTION

Unplug the power supply

Turn the Pool Cleaner upside-down.

Open the bottom lid.

Remove the ﬁlter bag.

Clean the ﬁlter bag with a hose.

We recommend that you periodically wash the ﬁlter bag in a

washing machine using the gentle cycle program.

Periodically clean the brushes with a hose.

Click

Robotic Pool Cleaner MCC6/MTC6 |User Instructions 9

6.2. Replacing the ﬁlter bag

Put the ﬁlter bag over the frame so that the strap is

in the middle of the shortest side.

Make sure that ﬁlter bag is positioned

properly on the frame.

6.3. Cleaning the ﬁlter cartridges

Note: Don’t let the ﬁlter cartridges dry out before cleaning.

CAUTION

Unplug the power supply.

With the pool cleaner upside down

open the bottom lid and pull it out.

Open the clips and remove the ﬁlters.

Click
