Marantz SR5500 Manual

SERV I CE MODE

SR5500

V040624 IU

Month Date Dest.

(Dest. : Destination)

Year

CODE TYPEXXXX

(XXXX is displayed in Hex)

CD01 01020101

SIGDev. TYP Ver.No.

No. : DISP CODE ID Dev. : Device ID SIG. : CODE SIG ID

TYP. : CODE TYPE ID Ver. : Version

V040624 IU

Month Date Dest.

(Dest. : 仕向け)

Year

SOF T TYPE XX

(XX: Hex数字表示)

CODE TYPEXXXX

(XXXX: Hex数字表示)

CD01 01020101

SIGDev. TYP Ver.No.

No. : DISP CODE ID Dev. : Device ID SIG. : CODE SIG ID

TYP. : CODE TYPE ID Ver. : Version

SOF T TYPE XX

(XX is displayed in Hex)

SERV I CE MODE

SR5500

4. SERVICEMODE

Microprocessor(IC28),DSP(IC20)の Version 表示及び FL

点燈を確認するモードです。

1. セットの電源を入れます。MULTI、 EXIT、7.1CHINPUT

のボタンを同時に約 3 秒以上押します。

SERVICEMODEと表示が出ます。更に約 2 秒後に機

種名が表示されます。

4. SERVICE MODE

Microprocessor (IC28), DSP(IC20 )Version and FLD Segment

Check Mode.

1. While the power is on, MULTI, EXIT and 7.1CH INPUT

buttons simultaneously more than 3 seconds.

The FL display shows “SERVICE MODE”for 2 seconds

then shows the model name.

2. Press MULTI button, The software version of the

microprocessor (IC28) is displayed in the format below.

3. Press MULTI button again, The software Type Number is

displayed.

4. Press MULTI button again, The Code Group Type Number

is displayed.

5. Press MULTI button again, The left half, right half and

center of the label area in the FLD light on and off each

other.

6. Press MULTI button again, The segments of the character

area in the FLD flick in checker pattern.

7. Press MULTI button again, All the FL segments turns off.

8. Press MULTI button again. Every time MULTI button is

pressed, DSP code is indicated in turn from NO.1 to NO.10.

2. MULTI ボタンを押します。マイコン（IC28）のバージョ

ンが次のように表示されます。

3. MULTIボタンを押します。マイコン（IC28）のSoftware

Type が表示されます。

4. MULTI ボタンを押します。CodeGroupType が表示さ

れます。

5. MULTIボタンを押します。FL表示の右、左、中央部分が

交互に点燈を繰り返します。

6. MULTI ボタンを押します。FL の Character 部分が点滅

します。

7. MULTI ボタンを押します。FL が全消灯します。

8. MULTIボタンを押します。MULTIボタンを押す度にDSP

CodeID が NO.1 から NO.10 まで順に表示されます。

9. Press MULTI button again to quit this mode. 9. MULTIボタンを押します。サービスモードは解除されま

す。

Note: Step4, 5 is to check if CPU software is capable of DSP

code. “Software Type No”is to show what “DSP Code

Group”CPU is capable of. And vice versa.

Step 8 is to manage the 16 codes for DSP.

•When the unit is once turned into Service Mode, the

unit keeps this mode until the main power is turned

off. (Turning into stand-by mode does not make it quit

from Service Mode.) When the unit quits from Service

Mode, Information in the memory is also cleared and

the unit returns to the status when it is out from the

factory.

Product Reset

To reset the back up memory of the unit into the default status,

follow the procedure below.

1. Turn of the unit and press 7.1CH INPUT and MULTI button

simultaneously more than 1.5 seconds.

2. After “DEFAULT”is displayed on FLD, power is turned off

once and turned of again, EEPROM is cleared to the

default status, µ-com is reset and the unit returns to the

normal status. (Software Serial Number will not be

cleared.)

Note: When the unit is shipped from the factory, the procedure

above must be done to set the unit to initial status after

the tests.

Personal notes:

CHECK DSP

Indication is keep and sound is mute.

CHECK DSP ROM

CHECK ADC

表示状態はそのままで音声は Mute 状態

CHECK E2P I F

CHECK E2P

CHECK 2 3 2C

CHECK POW5

PROTECT

CHECK DSP

CHECK DSP ROM

CHECK ADC

CHECK E2P I F

CHECK E2P

CHECK 2 3 2C

CHECK POW5

PROTECT

5. SYSTEM ERROR

When the microcomputer detects a trouble, the following

information is displayed on the FLD.

•After the error contents indication, Surround Mode is

initialized and returned Factory mode.

•The contents of the ERROR indication are the followings.

1. Trouble in DSP

If communication with DSP is troubled more than 2

seconds.

5.SYSTEMERROR

製品内部での異常発生時に処理、表示を行います。主に各

Device との通信異常を検出します。

･ ERROR 表示後、SurroundMode は初期化され工場出荷

の状態に戻ります。

･ ERROR 表示の内容は下記です。

1. DSP 異常検出表示。

DSP との通信上の不具合を約 2 秒検出した時。

2. Trouble in DSP Code

The trouble of DSP Code was found.

3. Trouble in ADC

When ADC input was chosen and CAL signal continued

High about 2 seconds after the ADC Calibration start.

2. DSPCode異常検出表示。

DSPCode の異常を検出した時。

3. ADC 異常検出表示。

ADC 入力を選択した場合に ADCCalibration 開始後、

CAL 信号が約 2 秒以上 High を持続した時。

4. Trouble in EEP-ROM

If data from EEPROM does not match.

5. Trouble in EEP-ROM IF

If communication with EEPROM is troubled more than 2

seconds.

6. Trouble in RS-232C

If communication of Panja with RS232C is troubled more

than 2 seconds.

7. Trouble in 5V Supply

If 5V supply to DATA DIR is troubled.

8. Trouble in Protection

CPU turns off the speaker output.

4. EEP-ROM 異常検出表示。

EEP-ROMData の不整合を検出した時。

5. EEP-ROMIF 異常検出表示。

EEP-ROM との通信不具合が約 2 秒以上生じた時。

6. RS-232C 異常検出表示。

Panja通信時にRS-232Cとの通信不具合を約2秒以上検

出した時。

7. 5V 異常検出表示。

DATADIR. の異常を検出した時。

8. Protection 信号異常検出表示。

Speaker からを出力を止めます。

6. UPDATE FIRMWARE

Software for CPU and DSP can be updated.

Have update application software. (“UpgradeDSP.exe”and “H8Download.exe”)

There are two mode of download, regarding to the target of software as bellow.

Mode 1: Update DSP’s software to 4M Flash-ROM.

This mode is to update the software for DSP.

The target devise is 4M Flash-ROM (IC20) on CUP11706Z (DSP PCB).

HT-AS2000 needs to be set update condition, by three front keys.

Mode 2: Update CPU’s software to internal Flash-ROM.

This mode is to update the software for DSP.

The target devise is internal flash ROM of CPU (IC28) on CUP11706Z (DSP PCB).

HT-AS2000 needs to be set to writing condition, by pushing internal switch from back-panel.

The following items are required for updating.

RS232C Dsub-9 pin cable (female to female/Straight type)

Windows PC (98, NT, ME, 2000) with RS-232C port.

Update software to CPU.

Update software to DSP.

Use RS232C Dsub-9 pin cable (female to female/Straight type) to connect PC and the unit.

COM port on PC needs to be set by dialog box for each program. COM port can be set from COM1 to COM5.

Download Firmware for DSP (Mode 1)

1. Put the “DSP upgrade”folder into anywhere on your PC’s hard disc.

2. Connect PC and the unit with the RS-232C cable.

3. Turn on the unit.

4. Press ENTER, MUTE and T-MODE buttons simultaneously more than 5 seconds to turn the unit into Loading Mode.

5. “LOADING MODE”will be shown on FLD.

Note: yy_mm_dd is release date of software.

6. Launch “UpgradeDSP.exe”on PC.

7. Click Port setting, and select the COM Port No.

8. Set the Baud Rate to 38400 then click Start communication button.

9. If the connection is made successfully, a dialog box saying “Success to connect”appears and “CONNECTED”is displayed

on FLD.

10. Click Send the DSP codes button on the dialog box. Progress status of updating will be shown on PC and LOADING is

displayed on FLD.

11. If updating is completed successfully, “COMPLETED”is displayed on FLD. And a dialog box saying “Finished the DSP

code transmitting”appears. Click OK and then Application is closed automatically.

12. Turn off the unit.

Download Firmware for CPU (Mode 2)

1. Put the “CPU update”folder into anywhere on your PC’s hard disc.

Hole of rear panel

2. Connect PC and the unit with the RS-232C cable.

3. Insert a thin rot to the hole and push the switch (SW10) inside to turn on the switch.

4. Turn on the power of the unit.

Note: When the unit is into boot mode, stand-by LED is not lights up.

5. Launch “H8Download.exe”on PC.

6. Click Set Ports , and select the COM Port No.

7. Click other files... button in the dialog box to specify the file (SR5500_yymmdd.mot) to be uploading. yymmdd in filename

is release date of software.

8. Click Connect button. If the connection with the H8 µ-P is successfully made, a dialogue box saying “Success to the H8

micro processor connection”appears. If the connection fails, error message will appear.

9. Click Send button to start update.

10. If the firmware is updated successfully, a dialog box saying “Finished the firmware program sending”appears.

11. Click CLOSE button to close the application.

12. Disconnect Mains power cord.

13. Turn off the internal switch that has been turned on at step 3.

14. Turn on the unit.

Firmware Version Check

To check the versions of the firmware, see “Microprocessor (CPU), DSP Version and FLD Segment Check Mode”in “SERVICE

MODE”section.
