Lorex CVC8011 Manual

Printed in KOREA

Instruction Guide

Super DNR High Resolution

Color Camera

Model : CVC8011

Super DNR High Resolution Color Camera

Model : CVC8011

Lorex Technologies Inc.

INFORMATION - This equipment has been tested and found to comply with

limits for a Class A digital device, pursuant to part 15 of the FCC Rules & CE Rules.

These limits are designed to provide reasonable protection against harmful

interference when the equipment is operated in a commercial environment.

This equipment generates, uses, and can radiate radio frequency energy and, if

not installed and used in accordance with the instruction manual, may cause

harmful interference to radio communications.

Operation of this equipment in a residential area is likely to cause harmful

interference in which case the user will be required to correct the interference at

his own expense.

◆

Do NOT use power sources other than those specified.

◆

Do NOT expose this appliance to rain or moisture.

This installation should be made by a qualified service person and

should conform to all local codes.

The lightning flash with an arrowhead symbol, within an equilateral

triangle is intended to alert the user to the presence of uninsulated

dangerous voltage within the product's enclosure that may be of

sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert

the user to the presence of important operating and maintenance

(servicing) instructions in the literature accompanying the appliance.

WARNING - Changes or modifications not expressly approved by the

manufacturer could void the user's authority to operate the equipment.

CAUTION : To prevent electric shock and risk of fire hazards:

Super DNR High Resolution Color Camera

Super DNR High Resolution Color Camera Super DNR High Resolution Color Camera

■Contents

Features

Warnings and Precautions

Names and Functions of Parts

Installation

■Front

■Top

■Rear

■Lens

ㆍWhen using a CS-Mount lens (included)

ㆍWhen using a C-Mount lens

■Connecting to a monitor

■Connecting to power

Components 8

Camera Operation 15

■Settings 16

ㆍLENS 17

ㆍEXPOSURE 19

ㆍWHITE BALANCE 22

ㆍ DAY/NIGHT 23

ㆍ3DNR 25

ㆍSPECIAL 26

ㆍADJUST 30

ㆍRESET 30

ㆍEXIT 30

- CAM TITLE

- D-EFFECT

- MOTION

- PRIVACY

- SYNC

- LANGUAGE

- RETURN

Specifications 33

Limited Warranty 34

Troubleshooting 31

1/3”Super-HAD

™

II CCD

High Resolution : 560 TV Lines

Min. illumination 0.0006Lux (F1.2, 40 IRE, Sens-Up 256x)

OSD menu control

Internal / Linelock (phase control) function

Electronic day / night function, Sens-Up function (256x)

Motion adaptive digital noise reduction (3D-DNR)

Back light compensation (BLC)

Xtended Dynamic Range (XDR)

8-Zone privacy masking function (polygonal mosaic)

32x digital zoom

Remote OSD menu control (requires optional OSD remote)

Horizontal & vertical image mirroring

Auto sensing DC12V / AC24V

The camera requires periodic inspection.

Contact an authorised technician to carry out the inspection.

Stop using your camera when you find it malfunctioning.

If the camera emits smoke or is unusually hot for a long period,

a fire may be caused.

Do not Install the camera on a surface that can not support it.

If the camera is installed on an inappropriate surface, it may fall

and cause injury.

Do not hold plug with wet hands.

It could cause an electric shock.

Do not dis-assemble the camera.

It may result in an electric shock or other hazards.

Do not use the camera close to a gas or oil leak.

It may result in a fire or other hazards.

Super DNR High Resolution Color Camera Super DNR High Resolution Color Camera

■Features

Warning ■

Super DNR High Resolution Color Camera Super DNR High Resolution Color Camera

■Precautions

Only use the camera under conditions

where temperatures are between

-10¡C and +50¡C. Be especially

careful to provide ventilation when

operating under high temperatures.

It can cause the image quality to be

poor.

Severe lighting change or flicker can

cause the camera to work improperly.

This is one of the most important parts of

the camera. Be careful not to leave

fingerprints on the lens cover.

Do not install the camera in

extreme temperature conditions.

Do not install or use the camera in an

environment where the humidity is high.

Do not install the camera under

unstable lighting conditions.

Do not touch the front lens of the

camera.

It can cause malfunctions to occur.

If it gets wet, wipe it dry immediately.

Liquids can contain minerals that

corrode the electronic components.

If exposed to radioactivity the CCD

will fail.

It can damage the CCD.

Do not expose the camera to rain

or spill beverage on it.

Do not expose the camera to

radioactivity.

Never keep the camera pointed

directly at strong light.

Do not drop the camera and protect

it to physical shocks.

Note

ㆍIf the camera is exposed to spotlight or object reflecting strong light,

smear or blooming may occur.

ㆍPlease check that the power satisfies the normal specification before

connecting the camera.

Super DNR High Resolution Color Camera Super DNR High Resolution Color Camera

■Components

Names and Functions of Parts ■

Front

①Lens protection cap

Cover the lens when not in use.

②CS-Mount lens adaptor

Attach the CS-Mount lens here.

③Back Focus clamp screw

Loosen the clamp screw with a screwdriver before adjusting the Back

Focal length.

1. COLOR BOX CAMERA

2. L-WRENCH

3. C-MOUNT ADAPTOR

9. INSTRUCTION GUIDE

4. LENS

5. MOUNTING BRACKET

6. CABLE

8. ADAPTOR

3.0~8.0mm Auto Iris DC Lens-CS Type

65ft BNC Extension Cable

12V DC 300mA Regulated Power Supply

7. BNC TO RCA ADAPTOR

①

② ③

Super DNR High Resolution Color Camera Super DNR High Resolution Color Camera

■Names and Functions of Parts

Names and Functions of Parts ■

IRIS JACKOSD EXTRA

POWER

VIDEO SET

VIDEO OUT

AC24V IN

DC12V IN

⑪

⑤ ⑥ ⑦⑧

⑨⑩

Rear

⑤

Auto iris lens connector

Connection terminal for an auto iris lens.

⑥

Auto iris lens selection switch

Used to change between DC or Video depending upon the type of auto

iris in use.

⑦

OSD Extra

Connect to remote controller (optional -model # ACCRC01) to do camera

set up from the ground instead of on the ladder. Also includes BNC spot

video out to connect to a service monitor.

⑧

Video output terminal

Sends video signals and connects to the video input terminal of the monitor.

⑨

Power lamp

Lights up when the correct power is supplied to the camera.

⑩

Setting button

●

SET button : Used for the menu display. This button can be used to

confirm settings after changing the value of the selected function or

current conditions.

●

UP & DOWN buttons : Used for selecting items by moving the cursor

up or down on the menu screen.

●

LEFT & RIGHT buttons : Used when changing item values, by moving

the cursor to the left or right on the menu screen.

⑪

Power input terminalLow voltage power connection.

Top

④Mounting Bracket

Use the screw holes provided when fixing the

camera onto a mounting bracket. Use the clamp

screw as shown in the picture.

※

The mounting bracket can be attached to either

the bottom or the top of the camera.

Be careful not to tighten the screws more than

5mm into the body, otherwise serious damage

can occur.

④

Super DNR High Resolution Color Camera Super DNR High Resolution Color Camera

■Installation

Installation ■

The camera is supplied with a DC varifocal lens. Lenses, such as

auto iris, CS-Mount and C-Mount, are compatible with this camera.

■

Lens

Note

ㆍUsing a DC auto iris lens is recommended to achieve the best

possible results from the camera.

ㆍPlease keep the lens clean.

ㆍForeign objects or fingerprints on the lens will result in inferior image

quality, especially in low light level conditions.

1. Insert the connection plug connected to the auto iris lens cable into

the auto lens connector jack, which is located on the rear of the camera.

2. Set the lens selection switch, located on

the rear of the camera, to either DC or VIDEO,

depending on the type of auto iris lens being

used.

IRIS JACK OSD EXTRA

POWER

VIDEO SET

VIDEO OUT

AC24V IN

DC12V IN

Remove the lens protection cap and attach

the CS-Mount lens to the camera by screwing it in

clockwise.

Note

ㆍUse the specified lens connection parts as shown in the picture below.

Using of the wrong sized parts may cause damage

to the inside of the camera or result in poor fitting.

ㆍ

Using a lens which is too heavy affects the balance

of the camera and may cause a malfunction. Please

use a lens that weighs less than 450g.

ㆍSelect Av mode, if possible, when adjusting

the automatic light control (ALC) of an auto lens.

Use of PK mode may cause hunting.

When using a CS-Mount lens (included)

1. Remove the lens protection cap and

attach the C-mount adaptor.

2. Attach the C-Mount lens to the

camera by screwing it in clockwise.

When using a C-Mount lens

■Installation Camera Operation ■

Super DNR High Resolution Color Camera Super DNR High Resolution Color Camera

AC24V IN

DC12V IN

Connect the video output terminal located on the rear of the camera

to the monitor.

ㆍThe connection method varies depending on the type of monitor and

accessories. Please refer to the monitor user manual.

ㆍTurn off the power when connecting.

■

Connecting to a monitor

Check the standard power requirement before connecting to power.

■

Connecting to power

IRIS JACK OSD EXTRA

POWER

VIDEO SET

VIDEO OUT

AC24V IN

DC12V IN

AC24V IN

DC12V IN

IRIS JACK OSD EXTRA

POWER

VIDEO SET

VIDEO OUT

AC24V IN

DC12V IN

POWER

Dual Power Type

(AC 24V/DC 12V, AC 24V Class2)

DC Power Type (DC 12V, 300mA)

IRIS JACK OSD EXTRA

POWER

VIDEO SET

VIDEO OUT

AC24V IN

DC12V IN

POWER

■

SETUP menu

LENS (selection)

EXIT

ㆍMANUAL ㆍDC/VIDEO

EXPOSURE

ㆍSHUTTER ㆍAGC ㆍSENS-UP

ㆍBLC ㆍHSBLC ㆍD-WDR

WHITE BAL

ㆍATW ㆍAWB ㆍAWC ㆍMANUAL

DAY NIGHT

ㆍCOLOR ㆍAUTO ㆍEXT ㆍB/W

3DNR

ㆍON ㆍOFF

SPECIAL

ㆍCAMTITLE ㆍD-EFFECT ㆍRS-485

ㆍMOTION ㆍPRIVACYㆍLANGUAGE

ㆍSYNC

ㆍFACTORY RESET

RESET

ADJUST

ㆍSHARPNESS ㆍBLUE ㆍRED

SETUP

LENS DC

EXPOSURE

WHITE BAL

ㅡㅡㅡ

SETUP

LENS DC

EXPOSURE

WHITE BAL ㅡㅡㅡ

DAY NIGHT

3DNR

SPECIAL

ADJUST

RESET

EXIT

B/W

3. Set up a selected item by using the Left and Right buttons.

4. To finish and save the settings, select 'EXIT' and press the SET button.

This function is used to adjust the brightness of the screen.

When the SETUP menu screen is displayed on the screen, position

the cursor to point to LENS using the Up and Down buttons.

2. Select the type of lens using the Left and Right buttons.

Select the desired menu

item by using the UP and

DOWN buttons.

Modes can be changed

using the LEFT and

RIGHT buttons.

LENS

Note

•An item with the icon also has sub-menus. To select a sub-menu,

press the SET button.

• An item with the - - - icon has no sub-menus available for selection.

Super DNR High Resolution Color Camera Super DNR High Resolution Color Camera

■How to Use the Camera

Settings can be made using the 5 buttons located on the rear of the camera

■

Settings

IRIS JACK OSD EXTRA

POWER

VIDEO

SET

VIDEO OUT

AC24V IN

DC12V IN

SET

1. Press the SET button

ㆍThe Setup menu is displayed on the monitor screen.

2. Select a menu item using the Up and Down buttons.

ㆍPlace the cursor over a desired item.

SETUP

LENS DC

EXPOSURE

WHITE BAL ㅡㅡㅡ

DAY NIGHT

3DNR

SPECIAL

ADJUST

RESET

EXIT

B/W

Table of contents

Other Lorex Security Camera manuals

Popular Security Camera manuals by other brands

Okina USA

Okina USA SIR36-870VF650LP user manual

Divio

Divio NDR155PA user manual

Canon

Canon VB-C500D Specifications

Easy Access

Easy Access EasyGuard user manual

Vivotek

Vivotek FD9389-EHV-v2 Quick installation guide

TUYA

TUYA COSMO W2 manual

Eusso

Eusso UNC7500-IR Advanced installation guide

urmet domus

urmet domus 1096/204 user manual

VC VC20 series operating manual

Axis

Axis Q1614 installation guide

ieGeek

ieGeek DD201 manual

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Installation and user guide

Vicon

Vicon V662-D-1 Installation and operation guide

Grundig

Grundig GCH-K0274P owner's manual

4xem

4xem WPT Specifications

Samsung

Samsung SCV-3082 Specifications

Vitek

Vitek VTC-C544 Specifications

Lumens

Lumens VC-A50PNW installation guide
