Lightolier ProSpec 26075 User manual

Job Information Type:

Job Name:

Cat. No.:

Lamp(s):

Notes:

ProSpec® Track Lighting System 26075

Page 1 of 1 Lytespan to ProSpec Adapter

Lightolier a Genlyte company www.lightolier.com

631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710

We reserve the right to change details of design, materials and finish.

Description

Adapter module that mounts anywhere along the ProSpec track and accepts

most Lytespan luminaires (see luminaire compatibility for exceptions).

Features

1. Adapter Housing: High-temperature impact resistant thermoplastic.

2. Basic Lytespan Track Strip: Die cast aluminum, with high-temperature

impact resistant thermoplastic insulator, supporting electrical contacts.

Accepts Lytespan luminaires.

3. Track Attachment Fitting: High-temperature impact resistant polycarbon-

ate, rotates into track. Adapter module can be flipped 180° to access one or

the other circuit.

4. Clamping Knob: Rotation of clamping knob secures steel clamping toggle

to track.

5. Attachment Lever: Impact resistant polycarbonate. For mechanical/electri-

cal connection to track.

Electrical

Unit is polarized and continuously grounded throughout. 250W load capacity.

Labels

cULus

Ordering Information

Catalog No. Finishes Track Mounting Luminaire Compatibility

26075WH

26075BK

Matte White

Matte Black

Compatible with ProSpec Track Systems.

DO NOT USE with Monopoints.

Compatible with all Lytespan line and low voltage incandescent

luminaires, 250W Max.

Compatible with all Lytespan fluorescent and metal halide

luminaires EXCEPT PowerWash, Lyteflood L39/L40, PowerArc

Modular, SofTech Metal Halide, Lytespot Metal Halide.

DO NOT USE with Power Jack or ProSpec luminaires.

1 1/2

[37.39]

9/16

[15.04]

6 3/8

[162.07]

4 11/16

[118.76]

1 1/2

[38.36]

2 1/16

[51.84]

2 1/16

[51.88]
